粤港澳大湾区建设用地扩张与城市热岛扩张耦合态势研究

doi:10.12082/dqxxkx.2018.180242

地球信息科学学报 ›› 2018, Vol. 20 ›› Issue (11): 1592-1603.doi: 10.12082/dqxxkx.2018.180242

所属专题：粤港澳大湾区

• 地理空间分析综合应用 • 上一篇下一篇

粤港澳大湾区建设用地扩张与城市热岛扩张耦合态势研究

杨智威^1,²(), 陈颖彪^1,^2,^*(), 吴志峰^1,², 郑子豪^1,²

1. 广州大学地理科学学院,广州 510006
2. 广东省地理国情监测与综合分析工程技术研究中心,广州 510006

收稿日期:2018-05-15 修回日期:2018-09-11 出版日期:2018-11-20 发布日期:2018-11-20
作者简介:
作者简介：杨智威（1996-）,男,硕士生,研究方向为遥感和地理信息系统应用。E-mail: yangzw9615@163.com
基金资助:
国家自然科学基金项目（41771127）;广东省前沿与关键技术创新专项资金（省重大科技专项）项目（2017B010117004）;广东省自然科学基金项目（2016A030313551）

The Coupling Between Construction Land Expansion and Urban Heat Island Expansion in Guangdong-Hong Kong-Macao Greater Bay

YANG Zhiwei^1,²(), CHEN Yingbiao^1,^2,^*(), WU Zhifeng^1,², ZHENG Zihao^1,²

1. School of Geographical Sciences, Guangzhou University, Guangzhou 510006, China
2. Guangdong provincial geographical condition monitoring and comprehensive analysis engineering technology research center, Guangzhou 510006, China

Received:2018-05-15 Revised:2018-09-11 Online:2018-11-20 Published:2018-11-20
Contact: CHEN Yingbiao
Supported by:
National Natural Science Foundation of China, No.41771127;Guangdong Provincial Frontier and Key Technology Innovation Special Funds (Major Science and Technology Projects), No.2017B010117004;Natural Science Foundation of Guangdong, No.2016A030313551.

摘要/Abstract

摘要：

深入研究粤港澳大湾区建设用地扩张与城市热岛扩张的耦合态势,对改善大湾区生态环境、实现城市化的健康发展,具有重要的意义和科学价值。本文以粤港澳大湾区为研究区域,选取2000、2008和2016年的遥感影像数据和地表温度数据,提取大湾区的建设用地、划分城市热岛强度等级、识别城市热岛区域;在此基础上,使用总体耦合态势和空间耦合特征两种模型揭示大湾区在不同时期建设用地扩张和城市热岛扩张的耦合关系。结果表明：① 2000-2016年,粤港澳大湾区的建设用地扩张和城市热岛扩张趋势具有同步性;② 城市热岛区域面积不断增加,在珠江口两岸逐步形成了连接中山-佛山-广州-东莞-深圳-香港,大范围分布的倒“U”形城市热岛条带;③ 大湾区建设用地与城市热岛的总体耦合态势处于不断加强的过程,至2016年,两类指标的重心距离达到研究期内的最小距离,此时的总体耦合态势最强;④ 研究期内,大湾区未出现建设用地扩张和城市热岛扩张严重失调情况,建设用地扩张和城市热岛扩张耦合类型以耦合型、基本耦合型以及轻度不耦合型为主,空间耦合程度高。

关键词: 建设用地, 城市热岛, 扩张, 耦合态势, 粤港澳大湾区

Abstract:

To study the coupling between construction land expansion and urban heat island（UHI）expansion in Guangdong-Hong Kong-Macao Greater Bay, it is of great significance and scientific value to improve the ecological environment of the Greater Bay and realize the healthy development of urbanization. In this paper, the Guangdong-Hong Kong-Macao Greater Bay was used as the research area. We selected remote sensing image data and surface temperature data in 2000, 2008 and 2016 to extract construction land in the Greater Bay, classify heat island intensity level and identify UHI regions. Then this paper used overall coupling model and spatial coupling model to reveal the coupling relationship between the construction land expansion and UHI expansion of the Greater Bay in different periods. The overall coupling situation was reflected by measuring the spatial overlap and change track consistency of land expansion and UHI expansion. And the spatial coupling relationship between the land expansion and UHI expansion was studied by using the revised coordination coefficient model. The results showed that: (1) From 2000 to 2016, the trend of construction land expansion and UHI expansion in the Greater Bay was synchronous. And the expansion rate between 2008 and 2016 was faster than that from 2000 to 2008; (2) The area of UHI increased constantly, and multiple UHI centers appeared. On the two sides of the Pearl River Estuary, an inverted "U" shaped UHI belt has been formed, which linked Zhongshan, Foshan, Guangzhou, Dongguan, Shenzhen and Hongkong; (3) The overall coupling situation of the construction land expansion and UHI in the Greater Bay was constantly strengthening. By 2016, the distance between the gravity center of the two types of indexes reached the nearest distance in the study period, and the overall coupling situation was also the greatest at this time. (4) During the research period, there was no serious imbalance of construction land expansion and UHI expansion in the Greater Bay. In the two types of index coupling types in the Greater Bay area, the space coupling categories of construction land expansion and UHI expansion were mainly coupling category, approximate coupling category and slightly uncoupling category. The degree of space coupling was high. And there was little change in the number of each category, but the number of "double high" coupled units was greatly increased.

Key words: construction land, urban heat island, expansion, coupling, Guangdong-Hong Kong-Macao Greater Bay

杨智威, 陈颖彪, 吴志峰, 郑子豪. 粤港澳大湾区建设用地扩张与城市热岛扩张耦合态势研究[J]. 地球信息科学学报, 2018, 20(11): 1592-1603.DOI:10.12082/dqxxkx.2018.180242

YANG Zhiwei,CHEN Yingbiao,WU Zhifeng,ZHENG Zihao. The Coupling Between Construction Land Expansion and Urban Heat Island Expansion in Guangdong-Hong Kong-Macao Greater Bay[J]. Journal of Geo-information Science, 2018, 20(11): 1592-1603.DOI:10.12082/dqxxkx.2018.180242

图/表 10

图1

表1

建设用地扩张与城市热岛扩张耦合类别及关系界定

$O LT$	类别划分	$L R i$ 与 $T R i$ 的关系
$0.9, 1$	耦合
$0.8, 0.9$	基本耦合	$L R i > T R i$	$L R i$ 超前于 $T R i$ 扩展
$0.7, 0.8$	轻度不耦合	$L R i ≈ T R i$	$L R i$ 协同于 $T R i$ 扩展
$0.5, 0.7$	中度不耦合	$L R i < T R i$	$L R i$ 滞后于 $T R i$ 扩展
$0, 0.5$	高度不耦合

表1

图2

表2

图3

图4

图5

图6

表3

图7

参考文献 32

[1]	刘钰,詹晨霄,张鹏岩,等.建设用地与城市人口的空间失调特征及其驱动机制分析——以台湾海峡西岸地区为例[J].资源科学,2017,39(8):1497-1510. doi: 10.18402/resci.2017.08.07
	[ Liu Y, Zhan C X, Zhang P Y, et al.Characteristics and driving forces of the spatial imbalance between construction land and urban populations[J]. Resources Science, 2017,39(8):1497-1510. ] doi: 10.18402/resci.2017.08.07
[2]	Xiong Y, Huang S, Chen F, et al.The impacts of rapid urbanization on the thermal environment: A remote sensing study of Guangzhou, South China[J]. Remote Sensing, 2012,4(7):2033-2056. doi: 10.3390/rs4072033
[3]	Mohan M, Kandya A.Impact of urbanization and land-use/land-cover change on diurnal temperature range: A case study of tropical urban airshed of India using remote sensing data[J]. Science of the Total Environment, 2015,506:453-465. doi: 10.1016/j.scitotenv.2014.11.006 pmid: 25437763
[4]	Fan H, Sailor D J.Modeling the impacts of anthropogenic heating on the urban climate of Philadelphia: A comparison of implementations in two PBL schemes[J]. Atmospheric Environment, 2005,39(1):73-84. doi: 10.1016/j.atmosenv.2004.09.031
[5]	Voogt J A, Oke T R.Thermal remote sensing of urban climates[J]. Remote Sensing of Environment, 2003,86(3):370-384. doi: 10.1016/S0034-4257(03)00079-8
[6]	Li D, Sun T, Liu M, et al.Contrasting responses of urban and rural surface energy budgets to heat waves explain synergies between urban heat islands and heat waves[J]. Environmental Research Letters, 2015,10(5):054009. doi: 10.1088/1748-9326/10/5/054009
[7]	张硕,刘勇洪,黄宏涛.珠三角城市群热岛时空分布及定量评估研究[J].生态环境学报, 2017,26(7):1157-1166. doi: 10.16258/j.cnki.1674-5906.2017.07.010
	[Zhang S, Liu Y H, Huang H T. Research on quantitative evaluations and spatial and temporal distribution of heat islands for the Pearl River Delta agglomeration[J]. Ecology and Environmental Sciences, 2017,26(7):1157-1166. ] doi: 10.16258/j.cnki.1674-5906.2017.07.010
[8]	侯浩然,丁凤,黎勤生.近20年来福州城市热环境变化遥感分析[J].地球信息科学学报, 2018,20(3):385-395.
	[Hou H R, Ding F, Li Q S. Remote sensing analysis of changes of urban thermal environment of Fuzhou city in China in the past 20 years[J]. Journal of Geo-information Science, 2018,20(3):385-395. ]
[9]	Bonafoni S, Baldinelli G, Verducci P.Sustainable strategies for smart cities: Analysis of the town development effect on surface urban heat island through remote sensing methodologies[J]. Sustainable Cities & Society, 2017,29:211-218. doi: 10.1016/j.scs.2016.11.005
[10]	祝新明,王旭红,周永芳,等.建成区扩张下的西安市热环境空间分异性[J].生态学杂志, 2017,36(12):3574-3583.
	[Zhu X M, Wang X H, Zhou Y F, et al. Spatial variability of thermal environment in Xi'an under the build-up area expansion[J]. Chinese Journal of Ecology, 2017,36(12):3574-3583. ]
[11]	Guattari C, Evangelisti L, Balaras C A.On the assessment of urban heat island phenomenon and its effects on building energy performance: A case study of Rome (Italy)[J]. Energy & Buildings, 2017,158:605-615.
[12]	张羽,朱学超.广东省雷暴特征及其对城市热岛的响应[J].生态学杂志,2017,36(12):3584-3593.
	[ Zhang Y, Zhu X C.The characteristics of thunderstorms in Guangdong province and their responses to urban heat island effect[J]. Chinese Journal of Ecology, 2017,36(12):3584-3593. ]
[13]	Shen H, Huang L, Zhang L, et al.Long-term and fine-scale satellite monitoring of the urban heat island effect by the fusion of multi-temporal and multi-sensor remote sensed data: A 26-year case study of the city of Wuhan in China[J]. Remote Sensing of Environment, 2016,172:109-125. doi: 10.1016/j.rse.2015.11.005
[14]	Grover A, Singh R.Analysis of urban heat island (UHI) in relation to normalized difference vegetation index (NDVI): A comparative study of Delhi and Mumbai[J]. Environments, 2015,2(2):125-138. doi: 10.3390/environments2020125
[15]	袁振,吴相利,臧淑英,等.基于TM影像的哈尔滨市主城区绿地降温作用研究[J].地理科学,2017,37(10):1600-1608.
	[ Yuan Z, Wu X L, Zang S Y, et al.Cooling effect of green patche based on TM image in Harbin downtown city[J]. Scientia Geographica Sinica, 2017,37(10):1600-1608. ]
[16]	Fan C, Myint S, Kaplan S, et al.Understanding the impact of urbanization on surface urban heat islands: A longitudinal analysis of the oasis effect in subtropical desert cities[J]. Remote Sensing, 2017,9(7):672. doi: 10.3390/rs9070672
[17]	贺丽琴,杨鹏,景欣,等.基于MODIS影像及不透水面积的珠江三角洲热岛效应时空分析[J].国土资源遥感,2017,29(4):140-146.
	[ He L Q, Yang P, Jing X, et al.Analysis of temporal-spatial variation of heat island effect in Pearl River Delta using MODIS images and impermeable surface area[J]. Remote Sensing for Land & Resources, 2017,29(4):140-146. ]
[18]	于琛,胡德勇,曹诗颂,等. 2005-2016年北京中心城区热岛时空格局及影响因子多元建模[J].地球信息科学学报,2017,19(11):1485-1494. doi: 10.3724/SP.J.1047.2017.01485
	[ Yu C, Hu D Y, Cao S S, et al.Spatio-temporal pattern of heat island and multivariate modeling of impact factors of Beijing downtown from 2005 to 2016[J]. Journal of Geo-information Science, 2017,19(11):1485-1494. ] doi: 10.3724/SP.J.1047.2017.01485
[19]	Liu C, Li Y, Rosen M A.Spatio-temporal features of urban heat island and its relationship with land use/cover in mountainous city: A case study in Chongqing[J]. Sustainability, 2018,10(1943).
[20]	刘航,申格,黄青.近10a武汉市城市热岛效应演变及其与土地利用变化的关系[J].长江流域资源与环境,2017,26(9):1466-1475. doi: 10.11870/cjlyzyyhj201709019
	[ Liu H, Shen G, Huang Q.Evolution of urban heat island effect and its relationship with land use change in Wuhan city in recent 10 years[J]. Resources and Environment in the Yangtze Basin, 2017,26(9):1466-1475. ] doi: 10.11870/cjlyzyyhj201709019
[21]	Peng J, Jia J, Liu Y, et al.Seasonal contrast of the dominant factors for spatial distribution of land surface temperature in urban areas[J]. Remote Sensing of Environment, 2018,215:255-267. doi: 10.1016/j.rse.2018.06.010
[22]	Yao R, Wang L C, Gui X, et al.Urbanization effects on vegetation and surface urban heat islands in China's Yangtze River Basin[J]. Remote Sensing, 2017,9:540. doi: 10.3390/rs9060540
[23]	Wan Z.New refinements and validation of the collection-6 MODIS land-surface temperature/emissivity product[J]. Remote Sensing of Environment, 2012,112(1):59-74.
[24]	Schwarz N, Lautenbach S, Seppelt R.Exploring indicators for quantifying surface urban heat islands of european cities with MODIS land surface temperatures[J]. Remote Sensing of Environment, 2011,115(12):3175-3186. doi: 10.1016/j.rse.2011.07.003
[25]	Hove L Wav, Jacobs C M J, Heusinkveld B G, et al. Temporal and spatial variability of urban heat island and thermal comfort within the Rotterdam agglomeration[J]. Building & Environment, 2015,83:91-103. doi: 10.1016/j.buildenv.2014.08.029
[26]	陈康林,龚建周,陈晓越.广州市热岛强度的空间格局及其分异特征[J].生态学杂志,2017,36(3):792-799. doi: 10.13292/j.1000-4890.201703.018
	[ Chen K L, Gong J Z, Chen X Y.Spatial pattern and differentiation characteristics of urban heat island intensity in Guangzhou City[J]. Chinese Journal of Ecology, 2017,36(3):792-799. ] doi: 10.13292/j.1000-4890.201703.018
[27]	樊杰,陶岸君,吕晨.中国经济与人口重心的耦合态势及其对区域发展的影响[J].地理科学进展,2010,29(1):87-95. doi: 10.3760/j.issn:1001-7097.2007.07.012
	[ Fan J, Tao A J, Lv C.The coupling mechanism of the centroids of economic gravity and population gravity and its effect on the regional gap in China[J]. Progress in Geography, 2010,29(1):87-95. ] doi: 10.3760/j.issn:1001-7097.2007.07.012
[28]	周艳,黄贤金,徐国良,等.长三角城市土地扩张与人口增长耦合态势及其驱动机制[J].地理研究,2016,35(2):313-324. doi: 10.11821/dlyj201602009
	[ Zhou Y, Huang X J, Xu G L,et al.The coupling and driving forces between urban land expansion and population growth in Yangtze River Delta[J]. Geographical Research, 2016,35(2):313-324. ] doi: 10.11821/dlyj201602009
[29]	淳阳,朱晚秋,潘洪义,等.重心转移视角下新型城镇化与生态足迹时空差异及其耦合关系研究——以四川省为例[J].长江流域资源与环境,2018,27(2):306-317.
	[ Chun Y, Zhu W Q, Pan H Y, et al.Spatio-temporal differences and coupling relationship between new urbanization and ecological footprint from the perspective of gravity transfer: A case study of Sichuan Province[J]. Resources and Environment in the Yangtze Basin, 2018,27(2):306-317. ]
[30]	丁萌萌,曹卫东,张大鹏,等.安徽省公路交通与经济发展水平测度及协调性研究[J].长江流域资源与环境,2018,27(3):503-513.
	[ Ding M M, Cao W D, Zhang D P, et al.Study on the measurement and coordination of road traffic and economic development in Anhui province[J]. Resources and Environment in the Yangtze Basin, 2018,27(3):503-513. ]
[31]	张宇,曹卫东,梁双波,等.西部欠发达区人口城镇化与产业城镇化演化进程对比研究——以青海省为例[J].经济地理,2017,37(2):61-67. doi: 10.15957/j.cnki.jjdl.2017.02.009
	[ Zhang Y, Cao W D, Liang S B,et al.A comparative study on the evolution process of urbanization and industrialization in the underdeveloped areas of Western China: A case study of Qinghai province[J]. Economic Geography, 2017,37(2):61-67. ] doi: 10.15957/j.cnki.jjdl.2017.02.009
[32]	张新乐,张树文,李颖,等.城市热环境与土地利用类型格局的相关性分析——以长春市为例[J].资源科学,2008,30(10):1564-1570.
	[ Zhang X L, Zhang S W, Li Y, et al.Correlation between urban thermal environment effect and land use pattern in Changchun[J]. Resources Science, 2008,30(10):1564-1570. ]

	面积/km²	2000-2008年		2008-2016年
	面积/km²	扩张面积/km²	扩张速度/（km²/a）	扩张面积/km²	扩张速度/（km²/a）
2000年	4486	-	-	-	-
2008年	4913	427	53.38	-	-
2016年	6442	-	-	1529	191.13

	2000年	2008年	2016年	2000-2008年	2008-2016年
建设用地重心距离	-	-	-	6.27	5.21
城市热岛重心距离	-	-	-	5.59	4.43
两类重心空间距离	14.64	13.97	11.72	-0.67	-2.25
变动一致性指数	-	-	-	0.962	0.775
