福建省地表温度与植被覆盖度的相关性分析

doi:10.12082/dqxxkx.2019.180316

地球信息科学学报 ›› 2019, Vol. 21 ›› Issue (3): 445-454.doi: 10.12082/dqxxkx.2019.180316

福建省地表温度与植被覆盖度的相关性分析

李娅丽¹(), 汪小钦^1,^*(), 陈芸芝¹, 王苗苗²

1. 福州大学空间数据挖掘和信息共享教育部重点实验室,卫星空间信息技术综合应用国家地方联合工程研究中心,福州 350108
2. 中国科学院地理科学与资源研究所,北京 100101

收稿日期:2018-07-04 修回日期:2019-01-02 出版日期:2019-03-15 发布日期:2019-03-15
作者简介:
作者简介：李娅丽（1992- ）,女,山东菏泽人,硕士生,研究方向为遥感信息处理与应用技术。E-mail: luckyliyali@163.com
基金资助:
国家重点研发计划项目(2017YFB0504203);中央引导地方发展专项(2017L3012);海西政务大数据应用协同创新中心资助项目

The Correlation Analysis of Land Surface Temperature and Fractional Vegetation Coverage in Fujian Province

Yali LI¹(), Xiaoqin WANG¹(), Yunzhi CHEN¹, Miaomiao WANG²

1. Key Laboratory of Spatial Data Mining & Information Sharing of Ministry of Education, National & Local Joint Engineering Research Center of Satellite Geospatial Information Technology, Fuzhou University, Fuzhou 350108, China
2. Institude of Geographic Sciences and Natural Resources Research, Chinese Academy of Sciences, Beijing 100101, China

Received:2018-07-04 Revised:2019-01-02 Online:2019-03-15 Published:2019-03-15
Supported by:
National Key Research and Development Program of China, No.2017YFB0504203;Central Guide Local Science and Technology Development Project, No.2017L3012;Program of Fujian Collaborative Innovation Center for Big Data Applications in Governments.

摘要/Abstract

摘要：

地表温度（Land surface Tenperature, LST）和植被覆盖度（Fractional Vegetation Coverage, FVC)是生态环境变化的重要指标因子,研究两者的时空变化及相互关系对评价区域生态环境建设、改善区域生态环境具有重要意义。本文以福建省为研究区域,利用2001-2015年MODIS 11A2 LST和13Q1 NDVI数据,在时序数据重构的基础上对福建省LST时空变化及LST与FVC的相互关系进行分析。结果表明：①2001-2015年福建省LST总体呈轻微下降趋势,尤其是2010年之后其LST明显降低。LST与FVC的空间分布具有较好的负相关一致性：在FVC较高的区域,LST值较低;在FVC较低的区域,LST较高。② LST与FVC、DEM和纬度均成负相关关系,且负相关性在一年之中随着月份的变化而呈规律性增加或降低。夏季FVC对LST的负相关性最大为0.7,冬季FVC对LST的负相关性降低为0.4。③LST随着FVC增加而降低的趋势呈现分段线性关系,存在“FVC拐点”。“FVC拐点”前后随着FVC增加LST的降低速率在夏季 “先慢后快”,而在冬季则“先快后慢”。春秋两季,LST随着FVC增加而降低的速率在“FVC拐点”前后差异变小。在夏季,当FVC大于0.4时,FVC每增加0.1可降低LST约0.77 °C,降温效果大约是FVC小于0.4时的2倍。因此如果要有效地降低夏季地表高温,要使地表植被覆盖大于40%,才能较好的发挥植被的降温的作用。④在1-8月份,FVC对LST的负相关作用存在滞后性,FVC变化对滞后一个月的LST时空分布影响更大。研究成果对福建省生态环境建设与评估具有一定的意义,对于发挥植被对区域高温抑制作用提供了重要的参考依据。

关键词: 地表温度（LST）, 植被覆盖度（FVC）, 时空变化, LST与FVC相互关系, 福建省

Abstract:

Land surface temperature (LST) and fractional vegetation coverage （FVC） are important indicators of ecological environment changes. Studying the temporal and spatial variations of LST and FVC as well as their interaction in Fujian Province are of great significance to the evaluation of ecological environment construction and improvement of regional ecological environment. In this study, the temporal and spatial variations of LST in Fujian Province and the interaction between LST and FVC are analyzed, based on the reconstruction time series data of MODIS 11A2 LST and 13Q1 NDVI from 2001-2015. The results showed that: (1) The overall LST in Fujian Province presented a slight downward trend from 2001 to 2015, and the downward trend of LST is more pronounced after 2010. The spatial distribution of LST and FVC had a good negative correlation consistency, which implies the LST value is lower in the higher area while the LST is higher in the lower FVC area. (2) LST is negatively correlated with FVC, DEM and latitude. And their negative correlation was increased or decreased regularly with the change of months in a year .The negative correlation between FVC and LST was higher in summer and became lower in winter with the correlation coefficient reduced from 0.7 to 0.4. (3) The decreasing trend of LST with the increase of FVC is piecewise linear and has an obvious "FVC inflection point". In front and behind "FVC inflection point", the decreasing trends of LST with the increase of FVC are "slowly first and fast afterwards" in summer and "fast followed by slow "in winter. Moreover, the difference of LST decreasing rate with the increase of FVC becomes smaller in spring and autumn. In summer, when FVC is greater than 0.4, the LST can reduce about 0.77 °C with FVC value increase 0.1, and the cooling effect is about twice as much as that when FVC is less than 0.4. Therefore, if we want to effectively reduce LST in summer, we should make the surface vegetation cover more than 40%。Only in this way can vegetation play a better role in cooling. (4) From January to August, the negative correlation of FVC on LST has a lag, and vegetation change has a greater impact on the spatial and temporal distribution of the next month's LST. This study has a certain significance for the construction and evaluation of ecological environment in Fujian Province, and provide an important reference for the development of vegetation to suppress regional high temperature.

Key words: Land surface temperature (LST), Fractional vegetation coverage (FVC), Temporal and spatial variation, Interrelationship between LST and FVC, Fujian province

李娅丽, 汪小钦, 陈芸芝, 王苗苗. 福建省地表温度与植被覆盖度的相关性分析[J]. 地球信息科学学报, 2019, 21(3): 445-454.DOI:10.12082/dqxxkx.2019.180316

Yali LI, Xiaoqin WANG, Yunzhi CHEN, Miaomiao WANG. The Correlation Analysis of Land Surface Temperature and Fractional Vegetation Coverage in Fujian Province[J]. Journal of Geo-information Science, 2019, 21(3): 445-454.DOI:10.12082/dqxxkx.2019.180316

图/表 14

图1

表1

图2

图3

表2

图4

图5

图6

图7

图8

图9

图10

表3

图11

参考文献 35

[1]	He J J, Yu Y, Yu L J, et al.Impacts of uncertainty in land surface information on simulated surface temperature and precipitation over China[J]. International Journal of Climatology, 2017,37(7-8):829-837. doi: 10.1002/joc.5041
[2]	Jia H J.Analysis of the ecological environment changes in land surface temperature, and NDVI based on MODIS remote sensing data[J]. Remote Sensing Information, 2014,2014(3):855-856.
[3]	Roşca C F, Harpa G V, Croitoru A E, et al.The impact of climatic and non-climatic factors on land surface temperature in southwestern Romania[J]. Theoretical & Applied Climatology, 2016,130(3-4):775-790. doi: 10.1007/s00704-016-1923-6
[4]	时忠杰,高吉喜,徐丽宏,等.内蒙古地区近25年植被对气温和降水变化的影响[J].生态环境学报,2011,20(11):1594-1601. doi: 10.3969/j.issn.1674-5906.2011.11.002
	[ Shi Z J,Gao J X,Xu L H, et al.Effect of vegetation on changes of temperature and precipitation in inner Mongolia, China[J]. Ecology and Environmental Sciences, 2011,20(11):1594-1601. ] doi: 10.3969/j.issn.1674-5906.2011.11.002
[5]	Estoque R C, Murayama Y, Myint S W.Effects of landscape composition and pattern on land surface temperature: An urban heat island study in the megacities of Southeast Asia[J]. Science of the Total Environment, 2017,577:349-359. doi: 10.1016/j.scitotenv.2016.10.195 pmid: 27832866
[6]	Deng Y, Wang S, Bai X, et al.Relationship among land surface temperature and LUCC, NDVI in typical karst area[J]. Scientific Reports, 2018,8(1):641-653. doi: 10.1038/s41598-017-19088-x
[7]	刘建文,周玉科.站点尺度的青藏高原时序NDVI重构方法比较与应用[J].地理科学进展,2018,37(3):427-437. doi: 10.18306/dlkxjz.2018.03.013
	[ Liu J W, Zhou Y K.Comparison and application of NDVI time-series reconstruction methods at site scale on the Tibetan Plateau[J]. Progress in Geography, 2018,37(3):427-437. ] doi: 10.18306/dlkxjz.2018.03.013
[8]	Cai Z, Jönsson P, Jin H, et al.Performance of smoothing methods for reconstructing NDVI time-series and estimating vegetation phenology from MODIS data[J]. Remote Sensing, 2017,9(12):1271-1289. doi: 10.3390/rs9121271
[9]	臧琳,宋冬梅,单新建,等.基于被动微波与时空联合算法的云下像元LST重建[J].遥感技术与应用,2016,31(4):764-772. doi: 10.11873/j.issn.1004-0323.2016.4.0764
	[ Zang L, Song D M, Shan X J, et al.Reconstruction of LST under the cloud based on passive microwave remote sensing and spatio-temporal domain algorithm[J]. 2016,31(4):764-772. ] doi: 10.11873/j.issn.1004-0323.2016.4.0764
[10]	Romshoo S A, Rafiq M, Rashid I.Spatio-temporal variation of land surface temperature and temperature lapse rate over mountainous Kashmir Himalaya[J]. Journal of Mountain Science, 2018,15(3):563-576. doi: 10.1007/s11629-017-4566-x
[11]	慈晖,张强.新疆NDVI时空特征及气候变化影响研究[J].地球信息科学学报,2017,19(5):662-671. doi: 10.3969/j.issn.1560-8999.2017.05.010
	[ Ci H, Zhang Q.Spatio-temporal patterns of NDVI variations and possible relations with climate changes in Xinjiang province[J]. Journal of Geo-information Science, 2017,19(5):662-671. ] doi: 10.3969/j.issn.1560-8999.2017.05.010
[12]	郭金停,胡远满,熊在平,等.中国东北多年冻土区植被生长季NDVI时空变化及其对气候变化的响应[J].应用生态学报,2017(8):2413-2422. doi: 10.13287/j.1001-9332.201708.005
	[ Guo J T, Hu Y M, Xiong Z P, et al.Spatiotemporal variations of growing-season NDVI and response to climate change in permafrost zone of northeast china[J]. Chinese Journal of Applied Ecology, 2017(8):2413-2422. ] doi: 10.13287/j.1001-9332.201708.005
[13]	屈创,殷嘉霖,张海筱.基于MODIS数据的中国热环境时空变化研究[J].干旱区资源与环境,2013,27(8):45-51.
	[ Qu C, Yin J L, Zhang H X.Spatio-temporal thermal environment in china based on MODIS data[J]. Journal of Arid Land Resources & Environment, 2013,27(8):45-51. ]
[14]	Khan J, Wang P, Xie Y, et al.Mapping MODIS LST NDVI imagery for drought monitoring in Punjab Pakistan[J]. IEEE Access, 2018,99:19898-19911. doi: 10.1109/ACCESS.2018.2821717
[15]	Mühlbauer S, Costa A C, Caetano M.A spatiotemporal analysis of droughts and the influence of north Atlantic Oscillation in the Iberian Peninsula based on MODIS imagery[J]. Theoretical & Applied Climatology, 2016,124(3-4):703-721. doi: 10.1007/s00704-015-1451-9
[16]	Li P, Peng C, Wang M, et al. Dynamics of vegetation autumn phenology and its response to multiple environmental factors from 1982 to 2012 on Qinghai-Tibetan Plateau in China[J]. Science of the Total Environment, 2018,637-638:855-864. doi: 10.1016/j.scitotenv.2018.05.031 pmid: 29763866
[17]	Sun J, Qin X.Precipitation and temperature regulate the seasonal changes of NDVI across the Tibetan Plateau[J]. Environmental Earth Sciences, 2016,75(4):1-9. doi: 10.1007/s12665-015-4873-x
[18]	李磊磊,范建容,张茜彧,等.西藏自治区植被与气候变化的关系[J].山地学报,2017,35(1):9-15. doi: 10.16089/j.cnki.1008-2786.000190
	[ Li L L, Fan J R, Zhang X Y, et al.Relationships between NDVI and climate changes in Tibet, China[J]. Mountain Research, 2017,35(1):9-15. ] doi: 10.16089/j.cnki.1008-2786.000190
[19]	周婷,张寅生,高海峰,等.青藏高原高寒草地植被指数变化与地表温度的相互关系[J].冰川冻土,2015,37(1):58-69. doi: 10.7522/j.issn.1000-0240.2015.0006
	[ Zhou T, Zhang Y S, Gao H F, et al.Relationship between vegetation index and ground surface temperature on the Tibetan Plateau alpine grassland[J]. Journal of Glaciology & Geocryology, 2015,37(1):58-69. ] doi: 10.7522/j.issn.1000-0240.2015.0006
[20]	王蕾,张树文,姚允龙.绿地景观对城市热环境的影响——以长春市建成区为例[J].地理研究,2014,33(11):2095-2104. doi: 10.11821/dlyj201411009
	[ Wang L, Zhang S W, Yao Y L.The impacts of green landscape on urban thermal environment: A case study in Changchun city[J]. Geographical Research, 2014,33(11):2095-2104. ] doi: 10.11821/dlyj201411009
[21]	沙莎,郭铌,李耀辉,等.温度植被干旱指数(TVDI)在陇东土壤水分监测中的适用性[J].中国沙漠,2017,37(1):132-139. doi: 10.7522/j.issn.1000-694X.2015.00181
	[ Sha S, Guo N, Li Y H, et al.Applicability of TVDI in monitoring drought in Longdong area of Gansu,China[J]. Journal of Desert Research, 2017,37(1):132-139. ] doi: 10.7522/j.issn.1000-694X.2015.00181
[22]	Cao X, Feng Y, Wang J.An improvement of the Ts-NDVI space drought monitoring method and its applications in the Mongolian Plateau with MODIS, 2000-2012[J]. Arabian Journal of Geosciences, 2016,9(6):433-447. doi: 10.1007/s12517-016-2451-5
[23]	Marzban F, Sodoudi S, Preusker R.The influence of land-cover type on the relationship between NDVI-LST and LST-Tair[J]. International Journal of Remote Sensing, 2018,39(5):1377-1398. doi: 10.1080/01431161.2017.1402386
[24]	李斌,王慧敏,秦明周,等. NDVI、NDMI与地表温度关系的对比研究[J].地理科学进展,2017,36(5):585-596. doi: 10.18306/dlkxjz.2017.05.006
	[ Li B, W H M, Qin M Z, et al. Comparative study on the correlations between NDVI, NDMI and LST[J]. Progress in Geography, 2017,36(5):585-596. ] doi: 10.18306/dlkxjz.2017.05.006
[25]	Park H S, Sohn B J.Recent trends in changes of vegetation over east Asia coupled with temperature and rainfall variations[J]. Journal of Geophysical Research Atmospheres, 2010,115(D14):14101-14113 doi: 10.1029/2009JD012752
[26]	Kawabata A, Ichii K, Yamaguchi Y.Global monitoring of interannual changes in vegetation activities using NDVI and its relationships to temperature and precipitation[J]. International Journal of Remote Sensing, 2001,22(7):1377-1382. doi: 10.1080/01431160119381
[27]	Peng S S, Piao S, Zeng Z, et al.Afforestation in China cools local land surface temperature[C]. Proceedings of the National Academy of Sciences, 2014,111(8):2915-2919.
[28]	[ , 2016-06-29. ]
[29]	福建省森林资源管理总站.福建省第八次全国森林资源清查及森林资源状况调查报告[J].福建林业,2014(2):9-10. doi: 10.3969/j.issn.1003-4382.2014.02.004
	[ Fujian forest resource management general station, Report on the eighth national forest inventory and forest resources survey of Fujian province[J]. Forestry in Fujian, 2014(2):9-10. ] doi: 10.3969/j.issn.1003-4382.2014.02.004
[30]	Krishnan S R, Seelamantula C S.On the selection of optimum Savitzky-Golay filters[J]. IEEE Transactions on Signal Processing, 2013,61(2):380-391. doi: 10.1109/TSP.2012.2225055
[31]	边金虎,李爱农,宋孟强,等. MODIS植被指数时间序列Savitzky-Golay滤波算法重构[J].遥感学报,2010,14(4):725-741. doi: 10.3724/SP.J.1011.2010.01138
	[ Bian J H, Li A N, Song M Q, et al.Reconstruction of NDVI time-series datasets of MODIS based on Savitzky-Golay filter[J]. Journal of Remote Sensing, 2010.14(4):725-741. ] doi: 10.3724/SP.J.1011.2010.01138
[32]	顾祝军,曾志远,史学正,等.基于ETM+图像的植被覆盖度遥感估算模型[J].生态环境学报,2008,17(2):771-776. doi: 10.3969/j.issn.1674-5906.2008.02.063
	[ Gu Z J, Zeng Z Y, Shi X Z, et al, A model calculating vegetation fractional coverage from ETM+imagery[J]. Ecology and enVironmeflt. 2008,17(2):771-776. ] doi: 10.3969/j.issn.1674-5906.2008.02.063
[33]	Cai Y, Chen G, Wang Y, et al.Impacts of land vover and seasonal variation on maximum air temperature estimation using MODIS imagery[J]. Remote Sensing, 2017,9(3):233-247. doi: 10.3390/rs9030233
[34]	Zeng L, Wardlow B D, Tadesse T, et al.Estimation of daily air temperature based on MODIS land surface temperature products over the corn belt in the US[J]. Remote Sensing, 2015,7(1):951-970. doi: 10.3390/rs70100951
[35]	林金煌,陈文惠,祁新华,等.闽三角城市群生态系统格局演变及其驱动机制[J].生态学杂志,2018,37(1):203-210. doi: 10.13292/j.1000-4890.201801.036
	[ Lin J H, Chen W H, Qi X H, et al.Evolution pattern of ecosystem and its driving mechanism in urban agglomeration in Fujian delta region[J]. Chinese Journal of Ecology, 2018,37(1):203-210. ] doi: 10.13292/j.1000-4890.201801.036

数据类型	数据来源	时间长度	时间精度	空间精度
LST	MODIS11A2	2001-2015年	8 d	1000 m
NDVI	MODIS13Q1	2001-2015年	16 d	250 m
DEM	SRTM数据			90 m
气温	气象站点观测	2001-2015年	逐月

站点编号	站点名	相关系数	站点编号	站点名	相关系数	站点编号	站点名	相关系数
58725	邵武	0.956	58911	长汀	0.946	59134	厦门	0.957
58730	武夷山	0.963	58918	上杭	0.930	59321	东山	0.934
58731	浦城	0.962	58921	永安	0.945	58744	寿宁	0.936
58737	建瓯	0.961	58926	漳平	0.872	58818	宁化	0.935
58754	福鼎	0.939	58931	九仙山	0.923	58837	尤溪	0.931
58820	泰宁	0.948	58933	屏南	0.937	58843	霞浦	0.936
58834	南平	0.965	58944	平潭	0.934	9113	永定	0.934
58846	宁德	0.954	59126	漳州	0.929	58927	龙岩	0.810
58847	福州	0.946	59133	崇武	0.949	58734	建阳	0.959

月份	FVC拐点	拐点之前		拐点之后
月份	FVC拐点	方程式	R²	方程式	R²
1	0.25	y=-7.26x+19.22	0.953	y=-4.61x+18.79	0.990
2	0.25	y=-6.50x+21.00	0.950	y=-4.46x+20.58	0.996
3	0.30	y=-4.24x+24.14	0.956	y=-4.79x+24.27	0.996
4	0.30	y=-3.06x+27.01	0.845	y=-5.04x+27.67	0.984
5	0.35	y=-2.64x+29.39	0.889	y=-5.69x+30.60	0.983
6	0.35	y=-2.44x+31.43	0.770	y=-6.72x+33.07	0.994
7	0.40	y=-3.18x+32.51	0.928	y=-7.71x+34.49	0.996
8	0.40	y=-3.80x+32.32	0.902	y=-7.75x+34.09	0.995
9	0.35	y=-4.27x+30.54	0.941	y=-6.65x+31.42	0.994
10	0.30	y=-5.52x+27.70	0.956	y=-5.34x+27.73	0.988
11	0.25	y=-6.23x+23.56	0.936	y=-5.11x+23.40	0.990
12	0.25	y=-6.85x+19.70	0.922	y=-4.94x+19.36	0.988
