基于BiLSTM-CRF的中文层级地址分词

doi:10.12082/dqxxkx.2019.180654

摘要/Abstract

摘要：

中文地址分词是中文地址标准化的基础工作和地理编码的重要手段,同时也是中文分词和地理研究领域中关注的热点问题之一。针对当前中文地址分词方法缺乏地址层级切分和过多依赖词典和特征的问题,本研究结合四词位标注集和中文层级地址特点,构建针对中文层级地址分词的地址标注体系,并提出融合双向长短时记忆网络和条件随机场(BiLSTM-CRF)的中文层级地址分词模型。该模型既考虑了BiLSTM模型能够记忆上下文地址的特性,也保留了CRF算法可以通过转移概率矩阵控制地址标注输出的能力。针对该地址标注体系标注的训练地址样本,分别使用CRF、LSTM、BiLSTM与BiLSTM-CRF模型进行训练对比。结果表明：① 基于中文地址标注体系的模型分词效果更佳,地址标注更为精细,符合实际地址分布情况;② BiLSTM-CRF模型精确度达到93.4%,高于CRF（90.4%）、LSTM（89.3%）和BiLSTM（91.2%）,其整体地址分词性能和各层级地址分词效果相对于其他模型更突出;③ 各模型分词性能与地址层级保持一致,即地址层级越高,分词效果越好。本研究提出的中文地址标注体系和分词模型为开展中文地址标准化工作提供了方法参考,同时也为进一步提升地理编码技术的精准度提供了可能。

关键词: 中文分词, 地址标注, 中文层级地址分词, 长短时记忆网络(LSTM), 双向长短时记忆和条件随机场模型(BiLSTM-CRF)

Abstract:

Chinese word segmentation is a basic step in Chinese text processing and Chinese natural language processing. As a branch of Chinese word segmentation, Chinese address segmentation, which has become one of the hottest issues in Chinese word segmentation and geography research, is an important method to standardize Chinese address and conduct geocoding. Existing studies on Chinese address segmentation are mainly based on Statistical Machine Learning (SML) and Recurrent Neural Network (RNN). However, either of them cannot combine the advantages of the other. Furthermore, the current Chinese address segmentation methods lack address level segmentation and are too dependent on dictionaries and features. Therefore, this paper combined the four-word-position tagging set and Chinese hierarchical address characteristics to construct an address tagging system, and proposed a Chinese hierarchical address segmentation model (BiLSTM-CRF) which combines bidirectional long-term memory networks and conditional random fields algorithm. The proposed model utilizes the BiLSTM model to remember the characteristics of context address, while retaining the ability of the CRF algorithm to control the address tagging output by transferring probability matrix. In so doing, it has more powerful capability than the traditional statistical machine learning algorithms and RNN in the field of sequence labeling and word segmentation. To test the performance of BiLSTM-CRF on address samples marked by the address tagging system, CRF, LSTM, and BiLSTM were used to compare with BiLSTM-CRF and were respectively applied for training under the same condition as BiLSTM-CRF. We found that: (1) The segmentation effect of BiLSTM-CRF which is based on the Chinese address tagging system was better than the models for comparison, and the address tagging was more elaborate, in line with the actual address distribution. (2) The BiLSTM-CRF model had an accuracy of 93.4%, which was higher than the CRF (90.4%), LSTM (89.3%) and BiLSTM (91.2%) models. The overall address word segmentation performance and the effect of BiLSTM-CRF on each level address segmentation were more prominent than the other models. (3) The word segmentation performance of each model was correlated with the address level positively, i.e., the higher the address level, the better the word segmentation effect. The Chinese address tagging system and word segmentation model proposed in this study give a reference for the standardization of Chinese address, and provide the possibility to further improve the accuracy of geocoding technology. Future study can focus on fine-tuning the model to improve the model accuracy.

Key words: Chinese word segmentation, address tagging, hierarchical word segmentation, Long Short-Term Memory (LSTM), Bidirectional Long Short-Term Memory-Conditional Random Field (BiLSTM-CRF)

程博, 李卫红, 童昊昕. 基于BiLSTM-CRF的中文层级地址分词[J]. 地球信息科学学报, 2019, 21(8): 1143-1151.DOI:10.12082/dqxxkx.2019.180654

CHENG Bo, LI Weihong, TONG Haoxin. Chinese Address Segmentation based on BiLSTM-CRF[J]. Journal of Geo-information Science, 2019, 21(8): 1143-1151.DOI:10.12082/dqxxkx.2019.180654

图/表 11

表1

表2

地址要素类型	标注	含义	示例
省、自治区	B_PRO	省级地址词首	广\|B_PRO 东\|E_PRO 省\|S_PRO-A
	M_PRO	省级地址词中
	E_PRO	省级地址词尾
	S_PRO-A	省级地址后缀单字词
市、自治州、盟	B_CITY	市级地址词首	惠\|B_CITY 州\|E_CITY 市\|S_CITY-A
	M_CITY	市级地址词中
	E_CITY	市级地址词尾
	S_CITY-A	市级地址后缀单字词
区、县	B_COUNTY	区、县级地址词首	仲\|B_COUNTY 恺\|E_COUNTY 区\|S_COUNTY-A
	M_COUNTY	区、县级地址词中
	E_COUNTY	区、县级地址词尾
	S_COUNTY-A	区、县级地址后缀单字词
乡、镇、街道、派出所	B_STREET	乡镇级地址词首	淡\|B_STREET 水\|E_STREET 街\|B_STREET-A 道\|M_STREET-A 办\|E_STREET-A
	M_STREET	乡镇级地址词中
	E_STREET	乡镇级地址词尾
	S_ STREET -A	乡镇级地址后缀单字词
	B_STREET-A	乡镇级地址后缀词首
	M_STREET-A	乡镇级地址后缀词中
	E_STREET-A	乡镇级地址后缀词尾
村、社区	B_COM	村级地址词首	河\|B_COM 背\|E_COM 村\|B_COM-A 民\|M_COM-A 委\|M_COM-A 员\|M_COM-A 会\|E_COM-A
	M_COM	村级地址词中
	E_COM	村级地址词尾
	S_COM-A	村级地址后缀单字词
	B_COM-A	村级地址后缀词首
	M_COM-A	村级地址后缀词中
	E_COM-A	村级地址后缀词尾
街、路、巷	B_ROAD	街路巷地址词首	先\|B_ROAD 烈\|M_ROAD 东\|E_ROAD 路\|S_ROAD-A
	M_ROAD	街路巷地址词中
	E_ROAD	街路巷地址词尾
	S_ROAD-A	街路巷地址后缀单字词
门楼牌	B_ML	门楼牌地址词首	20\|B_ML 号\|E_ML
	M_ML	门楼牌地址词中
	E_ML	门楼牌地址词尾
建筑物	B_BUILD	建筑物地址词首	国\|B_BUILD 际\|M_BUILD 大\|M_BUILD 厦\|E_BUILD
	M_BUILD	建筑物地址词中
	E_BUILD	建筑物地址词尾
单元	B_UNIT	单元地址词首	12\|B_UNIT 单\|M_UNIT 元\|E_UNIT
	M_UNIT	单元地址词中
	E_UNIT	单元地址词尾
房间	B_ROOM	房间地址词首	208\|B_ROOM 房\|M_ROOM 间\|E_ROOM
	M_ROOM	房间地址词中
	E_ROOM	房间地址词尾
兴趣点	B_POI	POI地址词首	人\|B_POI 民\|M_POI 医\|M_POI 院\|E_POI
	M_POI	POI地址词中
	E_POI	POI地址词尾
方位	B_ORI	方位地址词首	附\|B_ORI 近\|E_ORI 前\|B_ORI 方\|E_ORI 旁\|S_ORI
	M_ORI	方位地址词中
	E_ORI	方位地址词尾
	S_ORI	方位地址单字词

图1

图2

图3

图4

表4

表5

表6

表7

参考文献 30

[1]	张文豪, 卢山, 程光 . 基于LSTM网络的中文地址分词法的设计与实现[J]. 计算机应用研究, 2018,35(12):1-2.
	[ Zhang W H, Lu S, Cheng G . Design and implementation of chinese address segmentation method based on LSTM networks[J]. Application Research of Computers, 2018,35(12):1-2. ]
[2]	郭正斌, 张仰森 . 基于定长序列的双向LSTM分词优化方法[J]. 郑州大学学报(理学版), 2018,50(2):97-101.
	[ Guo Z B, Zhang Y S . A optimization method of bidirectional LSTM based on fixed length sequence for word segmentation[J]. Journal of Zhengzhou University (Natural Science Edition), 2018,50(2):97-101. ]
[3]	莫建文, 郑阳, 首照宇 , 等. 改进的基于词典的中文分词方法[J]. 计算机工程与设计, 2013,34(5):1802-1807.
	[ Mo J W, Zheng Y, Shou Z Y . Improved chinese word segmentation method based on dictionary[J]. Computer Engineering and Design, 2013,34(5):1802-1807. ]
[4]	褚颖娜, 廖敏, 宋继华 . 一种基于统计的分词标注一体化方法[J]. 计算机系统应用, 2009,18(12):55-58.
	[ Chu Y N, Liao M, Song J H . Integrated chinese words segmentation and labeling based on Statistic Method[J]. Computer Systems & Applications, 2009,18(12):55-58. ]
[5]	Che J L, Tang L W, Deng S J , et al. Chinese word segmentation based on bidirectional GRU-CRF model[J]. International Journal of Performability Engineering, 2018,14(12):3066-3075.
[6]	蒋建洪, 赵嵩正, 罗玫 . 词典与统计方法结合的中文分词模型研究及应用[J]. 计算机工程与设计, 2012,33(1):387-391.
	[ Jiang J H, Zhao H Z, Luo M . Analysis and application of chinese word segmentation model which consist of dictionary and statistics method[J]. China Computer Federation Magazine, 2012,33(1):387-391. ]
[7]	Dong C H, Zhang J J ,Zong C Q, el al. Character-based LSTM-CRF with radical-level features for chinese named entity recognition[C].Natural Language Understanding and Intelligent Applications. Springer, Cham, 2016(10102):239-250.
[8]	Xue N W . Chinese word segmentation as character tagging[J]. Computational Linguistics and Chinese Language Processing, 2003,8(1):29-48.
[9]	Tseng H, Chang P, Andrew G, et al. A conditional random field word segmenter for sighan bakeoff 2005 [C]. Proceeding of the Fourth SIGHAN Workshop on Chinese Language Processing, Jeju Island, Korea, 2005: 168-171.
[10]	Zhao H, Huang C N, Li M. An improved chinese word segmentation system with conditional random field [C].Proceedings of the Fifth SIGHAN Workshop on Chinese Language Processing, Sydney, Australia , 2006: 162-165.
[11]	Kneser R, Ney H. Improved backing-off for m-gram language modeling [C]. 1995 International Conference on Acoustics, Speech, and Signal Processing, Michigan, USA, 1995.
[12]	Lilleberg J, Zhu Y, Zhang Y. Support vector machines and Word2vec for text classification with semantic features [C]. 2015 IEEE 14 ^th International Conference on Cognitive Informatics & Cognitive Computing (ICCI*CC). IEEE , 2015.
[13]	Collobert R, Weston J, Bottou L , et al. Natural language processing (almost) from scratch[J]. Journal of Machine Learning Research, 2011,12(8):2493-2537.
[14]	Zheng X, Chen H, Xu T. Deep learning for Chinese word segmentation and POS tagging [C]. Proceedings of the 2013 Conference on Empirical Methods in Natural Language Processing, Washington, USA, 2013: 647-657.
[15]	Pei W, Ge T, Chang B. Max-margin tensor neural network for chinese word segmentation [C]. Proceedings of the 52 ^nd Annual Meeting of the Association for Computational Linguistics, Baltimore, Maryland , 2014: 293-303.
[16]	Chen X, Qiu X, Zhu C, et al. Long short-term memory neural networks for chinese word segmentation [C]. Proceedings of the 2015 Conference on Empirical Methods in Natural Language Processing, Lisbon, Portugal, 2015: 1197-1206.
[17]	Chen X, Qiu X, Zhu C, et al. Gated recursive neural network for chinese word segmentation [C]. Proceedings of the 53 ^rd Annual Meeting of the Association for Computational Linguistics and the 7 ^th International Joint Conference on Natural Language Processing, Beijing, China , 2015,1:1744-1753.
[18]	张雪英, 闾国年, 李伯秋 , 等. 基于规则的中文地址要素解析方法[J]. 地球信息科学学报, 2010,12(1):9-16.
	[ Zhang X Y, Lv G N, Li B Q, Chen W J . Rule-based approach to semantic resolution of chinese addresses[J]. Journal of Geo-information Science, 2010,12(1):9-16. ]
[19]	余靖毅, 邬伦, 高勇 . 基于Storm的地理编码引擎[J]. 地球信息科学学报, 2015,17(12):1431-1441.
	[ Yu J Y, Wu L, Gao Y . A geocoding engine based on storm[J]. Journal of Geo-information Science, 2015,17(12):1431-1441. ]
[20]	赵阳阳, 王亮, 仇阿根 . 地址要素识别机制的地名地址分词算法[J]. 测绘科学, 2013,38(5):74-76.
	[ Zhao Y Y, Wang L, Qiu A G . An improved algorithm for address segmentation[J]. Science of Surveying and Mapping, 2013,38(5):74-76. ]
[21]	应申, 李威阳, 贺彪 , 等 .统计决策树下的城市地址集中文分词[J].武汉大学学报·信息科学版, 2018(12):1-9.
	[ Ying S, Li W Y, He B, et al. Chinese segmentation of city address set based on the statistical decision tree[J]. Geomatics and Information Science of Wuhan University, 2018(12):1-9. ]
[22]	谢婷婷, 严柯 . 基于统计的中文地址位置语义解析方法研究[J]. 软件导刊, 2017,16(10):19-21.
	[ Xie T T, Yan K . The method of semantic resolution of chinese addresses based on statistics[J]. Software Guide, 2017,16(10):19-21. ]
[23]	李一, 刘纪平, 罗安 . 深度学习的中文地址切分算法[J]. 测绘科学, 2018,43(10):107-111.
	[ Li Y, Liu J P, Luo A . Chinese address segmentation algorithm based on depth learning[J]. Science of Surveying and Mapping, 2018,43(10):107-111. ]
[24]	Yao Y, Huang Z. Bi-directional LSTM recurrent neural network for chinese word segmentation [C]. International Conference on Neural Information Processing, Kyoto, Japan, 2016: 345-353.
[25]	Zhang M, Yu N, Fu G . A simple and effective neural model for Joint word segmentation and POS tagging[J]. IEEE/ACM Transactions on Audio, Speech, and Language Processing, 2018,26(9):1528-1538.
[26]	金宸, 李维华, 姬晨 , 等. 基于双向LSTM神经网络模型的中文分词[J]. 中文信息学报, 2018,32(2):29-37.
	[ Jin C, Li W H, Ji C , et al. Bi-directional long short-term memory neural networks for chinese word segmentation[J]. Journal of Chinese Information Processing, 2018,32(2):29-37. ]
[27]	GB/T 23075-2009数字城市地理信息公共平台地名/地址编码规则.
	[ GB/T 23075-2009 The rules of coding for address in the common platform for geospatial information service of digital city. ]
[28]	Rumelhart D E, Hinton G E, Williams R J . Learning representations by back-propagating errors[J]. Nature, 1986,323(6088):533.
[29]	Hochreiter S, Schmidhuber J . Long short-term memory[J]. Neural computation, 1997,9(8):1735-1780.
[30]	Kingma D P, Ba J. Adam: A method for stochastic optimization [C]. International Conference on Learning Representations (ICLR), San Diego, United States, 2015,3:1-13.

样本编号	原始地址	地址层级关系
1	广东省惠州市仲恺区淡水街道办	省-市-区-街道
2	惠州市仲恺区沥林镇英光村民委员会	市-区-乡镇-村
3	广东省惠州市淡水爱民路基顿酒店	省-市-街道-街路巷-兴趣点
4	惠州市罗阳富力广场门口	市-兴趣点-方位

参数	值
CPU	Intel(R) Core(TM) i7-7700HQ@2.80GHZ 16G
GPU	NVIDIA GeForce GTX 1050 4G
操作系统	window 10 64 bits
编程语言	python
深度学习框架	Tensorflow

模型参数	值
词向量维度	200
批处理大小（batch_size）	128
神经网络隐藏单元数	100
Dropout率	0.5
神经网络层数	1
初始学习率	0.1
优化算法	Adam
epoch	40

模型	精确率P	召回率R	均值F₁
CRF	0.904	0.898	0.901
LSTM	0.893	0.887	0.890
BiLSTM	0.912	0.907	0.909
BiLSTM-CRF	0.934	0.929	0.931

地址层级	均值F₁
地址层级	CRF	LSTM	BiLSTM	BiLSTM-CRF
省	0.977	0.968	0.986	0.993
市	0.971	0.961	0.983	0.997
区县	0.950	0.936	0.958	0.960
乡镇街道	0.936	0.925	0.932	0.942
村	0.915	0.906	0.914	0.922
街路巷	0.896	0.888	0.902	0.907
门楼牌	0.902	0.893	0.900	0.913
建筑物	0.897	0.879	0.911	0.918
单元	0.928	0.925	0.931	0.935
房间	0.918	0.910	0.915	0.919
兴趣点	0.873	0.857	0.877	0.905
方位	0.921	0.913	0.932	0.961
