城市社区养老设施配置空间均衡研究

doi:10.12082/dqxxkx.2021.200208

摘要/Abstract

摘要：

我国人口老龄化增速势头不减,存在养老服务业发展不平衡、老龄服务供给不足的矛盾。北京是较早进入老龄化的城市,提出了以居家为主的“9064”养老模式以解决养老资源缺口问题。为促进社区养老服务供给的便利化,提高老年群体对养老服务的“获得感”,本文以北京市海淀区老年人口密度较大的17个街道为研究区,采用百度POI、小区户数、高德地图和遥感影像等多源数据,对老年人口统计数据进行空间网格化,比较国家、省（市）社区养老设施的服务半径及调查所得老年人日常出行特征,引入北京市居住公共服务设施配置指标作为评价标准,应用改进型两步移动搜索算法并构建空间均衡系数,从服务覆盖率、供需比和医疗资源易获性3个方面对社区养老设施进行空间均衡研究。结果表明,研究区内社区养老驿站的数量仍有不足,不同半径下的服务覆盖率和供需比差异显著,500 m半径内的覆盖率仅为23.3%,空间分布不合理是超八成社区养老驿站供需比偏低的主要原因,基层社区卫生机构对医疗资源的易获性有积极作用;社区养老服务发展不均衡,需要进一步优化配置。

关键词: 海淀区, 多源地理信息, 老龄化, 社区养老设施, 均衡系数, 改进型两步移动搜索法, 精细化人口格网, 空间不均衡

Abstract:

With China's rapidly aging population, the contradiction between inadequate elderly service supply and the demands of aging people becomes more serious. Beijing is one of the first cities that has entered the aging society. The "9064" pension model has been suggested to systematically address the shortage of pension resources. In order to provide the convenience of elderly care service and promote the satisfaction of elderly people, 17 communities which have much higher elderly population density in Haidian District are selected as the study area in this study. Based on multi-source data such as Baidu POI, community households, and remote sensing imagery, the statistical data of elderly population are gridded spatially. After the comparison between the national and provincial (municipal) community pension facilities’ service radius and the daily travel characteristics of the elderly people surveyed, residential service facility allocation indicators are chosen as the evaluation criteria. The Modified Two-Step Floating Catchment Area Method and the constructed spatial equilibrium coefficient are used to study the equilibrium of community pension facilities in three aspects: service coverage, facility capacity, and availability of medical resources. The results show that there are shortages of community care stations. The differences of service coverage and capacity are significant under different service radius. The service coverage of community care stations is only 23.3% within a 500-meter radius. The main reason of the low capacity of most elderly care stations is their uneven distribution in space. Local community health care facilities have positive effects on the availability of medical resources. As there exists nonequilibrium development of the elderly care service, further optimization of their allocation would be needed.

Key words: Haidian district, multi-source geographic information, population aging trend, community elderly care facilities, equilibrium coefficient, modified two-step floating catchment area method, refined population grid, spatial inequity

李海萍, 梁子豪. 城市社区养老设施配置空间均衡研究[J]. 地球信息科学学报, 2021, 23(3): 467-478.DOI:10.12082/dqxxkx.2021.200208

LI Haiping, LIANG Zihao. Research on Spatial Equilibrium of Urban Community Elderly Care Facilities and its Configuration[J]. Journal of Geo-information Science, 2021, 23(3): 467-478.DOI:10.12082/dqxxkx.2021.200208

图/表 12

图1

图2

图3

图4

表1

图5

图6

图7

图8

图9

图10

图11

参考文献 34

[1]	杨菊华, 王苏苏, 刘轶锋. 新中国70年:人口老龄化发展趋势分析[J]. 中国人口科学, 2019(4):30-42,126.
	[ Yang J H, Wang S S, Liu Y F. 70 Years of China: Analysis on the trend of population aging[J]. Chinese Journal of Population Science, 2019(4):30-42,126. ]
[2]	北京市老龄工作委员会办公室. 北京市老龄事业发展和养老体系建设白皮书(2017)[M]. 北京: 社会科学文献出版社, 2018.
	[ Office of the Beijing Municipal Committee on Aging. Beijing white paper on the development of aged care and the construction of the pension system (2017)[M]. Beijing: Social Sciences Academic Press, 2018. ]
[3]	北京市老龄工作委员会办公室. 北京市老龄事业发展报告(2018)[M]. 北京: 社会科学文献出版社, 2019.
	[ Office of the Beijing Municipal Committee on Aging. Beijing aged career development report (2018)[M]. Beijing: Social Sciences Academic Press, 2019. ]
[4]	高晓路, 颜秉秋, 季珏. 北京城市居民的养老模式选择及其合理性分析[J]. 地理科学进展, 2012,31(10):1274-1281.
	[ Gao X L, Yan B Q, Ji Y. Urban elders' desirable caring patterns and its rationality: A decision tree analysis[J]. Progress in Geography, 2012,31(10):1274-1281. ]
[5]	李玮玲, 杜雪平, 董建琴. 北京市西城区老年人养老模式影响因素[J]. 中国老年学杂志, 2016,36(19):4887-4889.
	[ Li W L, Du X P, Dong J Q. Influencing factors of the old-age care model for the elderly in Xicheng District of Beijing[J]. Chinese Journal of Gerontology, 2016,36(19):4887-4889. ]
[6]	张文娟, 魏蒙. 城市老年人的机构养老意愿及影响因素研究-以北京市西城区为例[J]. 人口与经济, 2014(6):22-34.
	[ Zhang W J, Wei M. A study on the factors associated with preferences for institutional care of the elderly in urban China: Evidences from Xicheng district of Beijing[J]. Population & Economics, 2014(6):22-34. ]
[7]	邵磊, 张婧, 徐秉钧, 等. 北京城市养老设施空间分布与中心城区设施建设供给数据分析[J]. 建筑学报, 2017(10):4-8.
	[ Shao L, Zhang J, Xu B J, et al. An analysis of the spatial distribution and demand-supply relation of care facilities for the elderly in the central urban area of Beijing[J]. Architectural Journal, 2017(10):4-8. ]
[8]	周尚意, 罗梦婷. 北京养老院床位数有效需求的空间差异分析[J]. 北京规划建设, 2017(5):32-35.
	[ Zhou S Y, Luo M T. Analysis of spatial difference of effective demand for number of beds in nursing homes in Beijing[J]. Beijing Planning Review, 2017(5):32-35. ]
[9]	叶文娟. 基于地理国情数据的养老设施资源均等化配置和分析-以上海市静安区为例[D]. 武汉:武汉大学, 2018.
	[ Ye W J. Research on equity allocation and analysis of elderly care facilities based on Geographical National Conditions Data: A case study of Jing'an, Shanghai[D]. Wuhan: Wuhan University, 2018. ]
[10]	丁秋贤, 朱丽霞, 罗静. 武汉市养老设施空间可达性分析[J]. 人文地理, 2016,31(2):36-42.
	[ Ding Q X, Zhu L X, Luo J. Analyzing spatial accessibility to residential care facilities in Wuhan[J]. Human Geography, 2016,31(2):36-42. ]
[11]	陶涛, 丛聪. 老年人养老方式选择的影响因素分析——以北京市西城区为例[J]. 人口与经济, 2014(3):15-22.
	[ Tao T, Cong C. An analysis of influencing factors on elder's preference for patterns of Old-age support: Some empirical evidence from Beijing Xicheng District[J]. Population & Economics, 2014(3):15-22. ]
[12]	余杰, Rosenberg M W, 程杨. 北京市老年人居家养老满意度与机构养老意愿研究[J]. 地理科学进展, 2015,34(12):1577-1585.
	[ Yu J, Rosenberg M W, Cheng Y. Aging at home and the intent to relocate in Beijing[J]. Progress in Geography, 2015,34(12):1577-1585. ]
[13]	王毅, 靳诚, 朱英明, 等. 浙江省公共服务水平的空间不均衡及其影响因素研究[J]. 南京师大学报(自然科学版), 2019,42(1):113-123.
	[ Wang Y, Jin C, Zhu Y M, et al. Evaluation of the spatial inequity of public service level and its influencing factors in Zhejiang province[J]. Journal of Nanjing Normal University(Natural Science Edition), 2019,42(1):113-123. ]
[14]	张录法, 李林青. 上海市不同层级医疗资源空间配置均衡性研究[J]. 城市发展研究, 2019,26(6):1-6.
	[ Zhang L F, Li L Q. Study on the equilibrium of spatial allocation of medical resources at different levels in Shanghai[J]. Urban Development Studies, 2019,26(6):1-6. ]
[15]	钟少颖, 杨鑫, 陈锐. 层级性公共服务设施空间可达性研究-以北京市综合性医疗设施为例[J]. 地理研究, 2016,35(4):731-744.
	[ Zhong S Y, Yang X, Chen R. The accessibility measurement of hierarchy public service facilities based on multi-mode network dataset and the two-step 2SFCA: A case study of Beijing's medical facilities[J]. Geographical Research, 2016,35(4):731-744. ]
[16]	丁愫, 陈报章. 城市医疗设施空间分布合理性评估[J]. 地球信息科学学报, 2017,19(2):185-196.
	[ Ding S, Chen B Z. Rationality assessment of the spatial distributions of urban medical facility[J]. Journal of Geo-information Science, 2017,19(2):185-196. ]
[17]	宋雪茜, 邓伟, 周鹏, 等. 两层级公共医疗资源空间均衡性及其影响机制——以分级诊疗改革为背景[J]. 地理学报, 2019,74(6):1178-1189.
	[ Song X Q, Deng W, Zhou P, et al. Spatial equity and influences of two-level public healthcare resources: A background to hierarchical diagnosis and treatment reform in China[J]. Acta Geographica Sinica, 2019,74(6):1178-1189. ]
[18]	国务院人口普查办公室, 国家统计局人口和就业统计司. 中国2010年人口普查分乡、镇、街道资料[M]. 北京: 中国统计出版社, 2012.
	[ Population Census Office under the State Council, Department of Population and Employment Statistics National Bureau of Statistics. Tabulation on the 2010 population census of The People's Republic Of China by township[M]. Beijing: China Statistics Press, 2012. ]
[19]	侯冰. 城市老年人社区居家养老服务需求层次及其满足策略研究[D]. 上海:华东师范大学, 2018.
	[ Hou B. Research on the demand level and satisfaction strategy of community home-based care service for urban elderly[D]. Shanghai: East China Normal University, 2018. ]
[20]	住房城乡建设部关于发布国家标准《城镇老年人设施规划规范》局部修订的公告2018年第334号[J]. 工程建设标准化, 2019(2):38-39.
	[ Announcement of the Ministry of Housing and Urban-Rural Development on the partial revision of the national standard "Code for planning of city and town facilities for the aged" 2018 No. 334[J]. Standardization of Engineering Construction, 2019(2):38-39. ]
[21]	北京市建筑设计研究院有限公司, 等. 社区养老服务设施设计标准:DB11/1309-2015.[S/OL]. 北京:北京市规划委员会,(2015-12-30)[2020-02-27]. http://ghzrzyw.beijing.gov.cn/biaozhunguanli/bz/jzsj/202002/t20200221_1665938.html.
	[ Beijing Institute of Architectural Design, et al. Design standard community-based elderly care facilities:DB11/1309-2015.[S/OL]. Beijing: Beijing Municipal Bureau of Urban Planning, (2015-12-30)[2020-02-27], http://ghzrzyw.beijing.gov.cn/biaozhunguanli/bz/jzsj/202002/t20200221_1665938.html]
[22]	北京市人民政府关于印发《北京市居住公共服务设施配置指标》和《北京市居住公共服务设施配置指标实施意见》的通知[J]. 北京市人民政府公报 2015(11):5-44.
	[ Notice of The People's Government Beijing Municipal on Issuing the "Beijing Residential Public Service Facilities Configuration Index" and the "Beijing Residential Public Service Facilities Configuration Index Implementation Opinions"[J]. Gazette of the People's Government of Beijing Municipality, 2015(11):5-44. ]
[23]	赵思宇, 曹昱, 雷燕妮, 等. 2013-2017年北京市120院前急救患者疾病谱特征分析[J]. 中华疾病控制杂志, 2019(4):474-479.
	[ Zhao S Y, Cao Y, Lei Y N, et al. Analysis of the disease spectrum of Beijing 120 prehospital emergency patients from 2013 to 2017[J]. Chinese Journal of Disease Control & Prevention, 2019(4):474-479. ]
[24]	李智红, 于海玲. 2010年北京市120院前急救成人患者流行病学研究[J]. 实用心脑肺血管病杂志, 2013,21(11):43-44.
	[ Li Z H, Yu H L. Epidemiology of Beijing 120 adult patients with pre-hospital Care in 2010[J]. Practical Journal of Cardiac Cerebral Pneumal and Vascular Disease, 2013,21(11):43-44. ]
[25]	Radke J, Mu L. Spatial decomposition, modeling and mapping service regions to predict access to social programs[J]. Geographic Information Sciences, 2000,6(2):105-112.
[26]	Luo W, Wang F. Measures of spatial accessibility to health care in a GIS environment: Synjournal and a case study in the Chicago region[J]. Environment and Planning B: Planning and Design, 2003,30(6):865-884.
[27]	Launay L. Methodology for building a geographical accessibility health index throughout metropolitan France[J]. PLoS One, 2019,14(8):1-15.
[28]	陶卓霖, 程杨, 戴特奇. 北京市养老设施空间可达性评价[J]. 地理科学进展, 2014,33(5):616-624.
	[ Tao Z L, Cheng Y, Dai T Q. Measuring spatial accessibility to residential care facilities in Beijing[J]. Progress in Geography, 2014,33(5):616-624. ]
[29]	卢永华, 李爽. 改进G2SFCA的深圳市室内应急避难场所空间可达性研究[J]. 武汉大学学报·信息科学版, 2019,44(9):1391-1398.
	[ Lu Y H, Li S. Spatial accessibility of indoor emergency shelters based on improved G2SFCA in Shenzhen city[J]. Geomatics and Information Science of Wuhan University, 2019,44(9):1391-1398. ]
[30]	Wan N, Bin Z, Troy Sternberg. A Three-Step Floating Catchment Area Method for analyzing spatial access to health services[J]. International Journal of Geographical Information Science, 2012,26(6):1073-89.
[31]	Delamater, Paul L. Spatial accessibility in Sub-optimally configured health care systems: A Modified Two-Step Floating Catchment Area (M2SFCA) Metric[J]. Health and Place, 2013,24:30-43. pmid: 24021921
[32]	夏帆, 陈莹, 窦明, 等. 水资源空间均衡系数计算方法及其应用[J]. 水资源保护, 2020,36(1):52-57.
	[ Xia F, Chen Y, Dou M, et al. Calculation method and application of spatial equilibrium coefficient of water resources[J]. Water Resources Protection, 2020,36(1):52-57. ]
[33]	张建华. 一种简便易用的基尼系数计算方法[J]. 山西农业大学学报(社会科学版), 2007(3):275-278,283.
	[ Zhang J H. An convenient method to calculate Gini Coefficient[J]. Journal of Shanxi Agricultural University (Social Science Edition), 2007(3):275-278,283. ]
[34]	北京市民政局. 关于印发《北京市社区养老服务驿站建设规划(2016年-2020年)》的通知[EB/OL]. http://mzj.beijing.gov.cn/art/2017/4/25/art_5008_9224.html, (2017-04-17)[2020-02-27].
	[ Beijing Municipal Civil Affairs Bureau. Notice on the issuance of the "Beijing Community Elderly Service Station Construction Plan(2016-2020)"[EB/OL]. http://mzj.beijing.gov.cn/art/2017/4/25/art_5008_9224.html, (2017-04-17)[2020-02-27].

年龄/岁	日平均出行频率/次	出行模式		平均单次出行距离/km
年龄/岁	日平均出行频率/次	步行/%	公共交通/%	平均单次出行距离/km
60~69	2.5	40	60	1.50
70~79	2.3	65	35	0.98
80及以上	0.9	97	3	0.62
