关键词: Ripley’s K函数, 分布式计算, Apache Spark, 高性能地理计算, Hilbert曲线, Geohash编码, 点模式分析, 空间填充曲线

Abstract:

As a second-order analysis method of spatial point patterns, Ripley's K function (K function for short) uses distance as an independent variable to detect the distribution patterns of points under different spatial scales, which has been widely used in distinct fields such as ecology, economics, and geography. However, the applications of K function are limited due to the sharply increased computational cost of nested traversals on the point-pair distance measurements in both estimation and simulation phases when the point size getting larger. Therefore, the optimization of algorithm workflow and parallel acceleration have become the key technologies for tackling the performance bottleneck and computability problem of K function. Among these solutions, hash-based partitioning has been widely adopted in parallel computing frameworks for enabling data decomposition, while R-tree indexes have been proposed to reduce the computational cost of point-pair distance measurements by using spatial query instead. However, default hash-based partitioning methods ignore the spatial proximity of data distributions, while R-tree indexes fail to save query time of neighboring points under large spatial distance threshold comparing with pointwise distance calculation. In order to address these issues, this paper proposes an acceleration method for K function based on the space filling curves. Specifically, the Hilbert curve is adopted to achieve spatial partitioning, which reduces the data tilt and communication cost between partitions by better considering the spatial proximity. Upon the partition result, local indexing based on Geohash code is further developed to improve the spatial indexing strategy, which embeds spatial information in codes for achieving quick distance filtering, in turn accelerates the pointwise distance measurements. To verify the effectiveness of the proposed method, it is compared with two optimization methods adopted in previous studies, i.e., default partition without indexing, and KDB-tree partition with R-tree indexing, by analyzing the calculation time of K function for point of interests (POIs) of enterprise registration data in Hubei province, China under different data sizes, spatial distance thresholds, and computing nodes in a computing cluster. Experimental results indicate that the time cost of the proposed method is about 1/4 of that for default partition without indexing under the data scale of 300 000 points. Besides, the speedup ratio is larger than 3.6 times under 9 nodes. Therefore, the proposed method can improve performance of K function effectively in a distributed environment and has a promising scalability and could provide a reference for accelerating other spatial patterns analysis algorithms as well.

Key words: Ripley's K function, distributed computing, Apache Spark, high performance geocomputation, Hilbert curve, Geohash, point pattern analysis, spatial filling curves
