居民出行视角下的北京市双枢纽机场可达性研究

doi:10.12082/dqxxkx.2022.210515

地球信息科学学报 ›› 2022, Vol. 24 ›› Issue (5): 914-924.doi: 10.12082/dqxxkx.2022.210515

• 地理空间分析综合应用 • 上一篇下一篇

居民出行视角下的北京市双枢纽机场可达性研究

黄洁¹^,^*(), 石雯茜², 陈娱³

1. 中国科学院地理科学与资源研究所区域可持续发展分析与模拟重点实验室,北京100101
2. 兰州大学资源环境学院,兰州730000
3. 南京师范大学地理科学学院,南京210023

收稿日期:2021-08-27 修回日期:2021-12-27 出版日期:2022-05-25 发布日期:2022-07-25
作者简介:黄洁（1988— ）,女,广西桂林人,博士,副研究员,主要从事交通地理、大数据与城市交通、居民出行分析等研究。 E-mail: huangjie@igsnrr.ac.cn
基金资助:
国家社会科学基金重大项目(20&ZD099)

Accessibility of Beijing Dual Hub Airports from the Perspective of Residential Travel

HUANG Jie¹^,^*(), SHI Wenqian², CHEN Yu³

1. Key Laboratory of Regional Sustainable Development Modeling/Institute of Geographic Sciences and Natural Resources Research, Chinese Academy of Sciences, Beijing 100101, China
2. College of Earth and Environmental Sciences, Lanzhou University,Lanzhou 730000,China
3. School of Geography, Nanjing Normal University, Nanjing 210023, China

Received:2021-08-27 Revised:2021-12-27 Online:2022-05-25 Published:2022-07-25
Contact: * HUANG Jie, E-mail: huangjie@igsnrr.ac.cn
Supported by:
Major Program from National Social Science Foundation of China(20&ZD099)

摘要/Abstract

摘要：

相较于传统的网络分析,利用在线地图API可以更加准确地获取实时出行时间数据。本文基于高德地图API,在居民出行视角下解析北京首都国际机场（“PEK”,简称“首都机场”）和北京大兴国际机场（“PKX”,简称“大兴机场”）在驾车和公共交通2种出行模式下的可达性空间格局,尝试对双枢纽机场可达性以及城市的“民航+城市交通”一体化发展提出建议。结果表明：① 大兴机场的投用使北京市民航服务在空间分布上趋于“南北均衡”,两机场分别在驾车出行0.5 h和公共交通出行1 h的覆盖范围形成互补,有效提升了城市内部腹地的覆盖;② 在以北京为起止点的出行视角下,驾车出行的1 h覆盖范围开始出现重叠;而公共交通出行模式的1.5 h范围呈现重叠;③ 驾车出行模式下的机场可达性高于公共交通出行模式,且在公共交通出行模式下,北京市两机场1 h服务面积和人口数量均有待提高,亟需打造“1 h公共交通服务圈”;④ 在以北京为中转点的视角下,首都机场到各火车站的可达性高于大兴机场;未来应重点提升大兴机场-城市交通枢纽的可达性,以提升城市内部中转能力。本研究有助于为双枢纽机场城市的“民航+城市交通”一体化发展提供科学依据。

关键词: 居民出行, 双枢纽机场城市, 城市交通, 可达性, 空间格局, 出行规划, 北京

Abstract:

For a city with dual hub airports, the relationship between two airports is important for its integrated transport system. Since 2019 Beijing has been a city with dual hub airports, namely Beijing Capital International Airport (PEK, hereinafter referred as “Capital Airport”) and Beijing Daxing International Airport (PKX, hereinafter referred as “Daxing Airport”). Based on the Gaode Map API, which can obtain real-time data precisely, this paper obtains real-travel-time data in both auto mode and public transport mode. It investigates the accessibility spatial pattern of two airports under the two travel modes from the perspective of residential travel so that we can offer suggestions on the integration development of “civil aviation-urban transportation” system. The results show that: ① The use of Daxing Airport has effectively improved the spatial accessibility to airports in Beijing, especially from the south area, making civil aviation service in Beijing tend to be a “north-south equilibrium”. The coverage of the two airports is complementary in 0.5-hour service area by driving and 1 hour service area by public transport, which effectively improves the efficiency of aviation service in Beijing. ② In Beijing, accessibility by auto is higher than that by public transport and accessibility from Capital Airport is higher than Daxing Airport in both travel modes. Under the auto mode, the two airports begin to compete in the coverage within 1 hour journeys. For public transport mode, there is competition within 1.5 hour. ③ Under the public transport mode, the service area and population of the two airports in Beijing need to be improved, as the two airports only serve 1.4% of urban area and 7% of total population in Beijing. So it is important to construct 1 hour service area for residents to access the airports. ④ In the view of intra-urban transfer, accessibility from train stations to the Capital Airport is higher than that of Daxing Airport. Hence, accessibility between Daxing Airport and train stations should be enhanced to support the integration of aviation and high-speed rail travel. Last, we offer suggestions in order to promote the effective integration of airport and urban traffic system in double hub airport cities.

Key words: residential travel, double hub airport city, urban transportation, accessibility, spatial pattern, mobility planning, Beijing

黄洁, 石雯茜, 陈娱. 居民出行视角下的北京市双枢纽机场可达性研究[J]. 地球信息科学学报, 2022, 24(5): 914-924.DOI:10.12082/dqxxkx.2022.210515

HUANG Jie, SHI Wenqian, CHEN Yu. Accessibility of Beijing Dual Hub Airports from the Perspective of Residential Travel[J]. Journal of Geo-information Science, 2022, 24(5): 914-924.DOI:10.12082/dqxxkx.2022.210515

图/表 11

图1

表1

图2

图3

图4

图5

图6

图7

图8

表2

表3

参考文献 37

[1]	Teitz M B. Toward a theory of urban public facility location[J]. Papers in Regional Science, 1968, 21(1):35. DOI: 10.1007/BF01952720 doi: 10.1007/BF01952720
[2]	DeVerteuil G. Reconsidering the legacy of urban public facility location theory in human geography[J]. Progress in Human Geography, 2000, 24(1):47-69. DOI: 10.1191/030913200668094045 doi: 10.1191/030913200668094045
[3]	方远平, 闫小培. 西方城市公共服务设施区位研究进展[J]. 城市问题, 2008(9):87-91.
	[ Fang Y P, Yan X P. Research progress on location of public service facilities in western cities[J]. Urban Problems, 2008(9):87-91. ] DOI: 10.13239/j.bjsshkxy.cswt.2008.09.012 doi: 10.13239/j.bjsshkxy.cswt.2008.09.012
[4]	宋正娜, 陈雯, 袁丰, 等. 公共设施区位理论及其相关研究述评[J]. 地理科学进展, 2010, 29(12):1499-1508. doi: 10.11820/dlkxjz.2010.12.005
	[ Song Z N, Chen W, Yuan F, et al. Formulation of public facility location theory framework and literature review[J]. Progress in Geography, 2010, 29(12):1499-1508. ] DOI: 10.11820/dlkxjz.2010.12.005 doi: 10.11820/dlkxjz.2010.12.005
[5]	叶嘉安, 宋小冬, 钮心毅, 等. 地理信息与规划支持系统[M]. 北京: 科学出版社, 2008.
	[ Ye J A, Song X D, Niu X Y, et al. Geographic information and planning support system[M]. Beijing: Science Press, 2008. ]
[6]	Tsou K W, Hung Y T, Chang Y L. An accessibility-based integrated measure of relative spatial equity in urban public facilities[J]. Cities, 2005, 22(6):424-435. DOI: 10.1016/j.cities.2005.07.004 doi: 10.1016/j.cities.2005.07.004
[7]	Walter G, Hansen. How accessibility shapes land use[J]. Journal of the American Planning Association, 1959, 25(2). DOI: 10.1080/01944365908978307 doi: 10.1080/01944365908978307
[8]	张志学, 李同升. 基于GIS的县级尺度交通可达性研究——以陕西省为例[J]. 人文地理, 2010, 25(1):100-104.
	[ Zhang Z X, Li T S. Study on traffic accessibility at county level based on GIS: A case study of Shaanxi Province[J]. Human Geography, 2010, 25(1):100-104. ] DOI: 10.3969/j.issn.1003-2398.2010.01.021 doi: 10.3969/j.issn.1003-2398.2010.01.021
[9]	王兰, 周楷宸, 汪子涵. 健康公平理念下社区养老设施的空间分布研究——以上海市中心城区为例[J]. 人文地理, 2021, 36(1):48-55.
	[ Wang L, Zhou K C, Wang Z H. The spatial distribution of community pension facilities under the concept of health equity: A case study of central urban area in Shanghai[J]. Human Geography, 2021, 36(1):48-55. ] DOI: 10.13959/j.issn.1003-2398.2021.01.007 doi: 10.13959/j.issn.1003-2398.2021.01.007
[10]	宗会明, 黄言. 高速铁路对成渝城市群区域可达性和城市相互作用格局的影响[J]. 人文地理, 2019, 34(3):99-107,127.
	[ Zong H M, Huang Y. Influence of high speed railway on regional accessibility and urban interaction pattern of Chengdu-Chongqing urban agglomeration[J]. Human Geography, 2019, 34(3):99-107,127. ] DOI: 10.13959/j.issn.1003-2398.2019.03.014 doi: 10.13959/j.issn.1003-2398.2019.03.014
[11]	董小刚, 乔庆华, 翟亮, 等. 基于改进引力模型的广场公园可达性研究[J]. 地球信息科学学报, 2019, 21(10):1518-1526. doi: 10.12082/dqxxkx.2019.180622
	[ Dong X G, Qiao Q H, Zhai L, et al. Evaluating the accessibility of plaza park using the gravity model[J]. Journal of Geo-information Science, 2019, 21(10):1518-1526. ] DOI: 10.12082/dqxxkx.2019.180622 doi: 10.12082/dqxxkx.2019.180622
[12]	陈洁, 陆锋, 程昌秀. 可达性度量方法及应用研究进展评述. 地理科学进展, 2007, 26(5):100-110.
	[ Chen J, Lu F, Cheng C X. Advance in accessibility evaluation approaches and applications[J]. Progress in Geography, 2007, 26(5):100-110. ] DOI: 10.11820/dlkxjz.2007.05.011 doi: 10.11820/dlkxjz.2007.05.011
[13]	John Radke, Lan Mu. Spatial decompositions, modeling and mapping service regions to predict access to social programs[J]. Geographic Information Sciences, 6: 2, 105-112. DOI: 10.1080/10824000009480538 doi: 10.1080/10824000009480538
[14]	Yang Duck-Hye, Goerge Robert, Mullner Ross. Comparing GIS-based methods of measuring spatial accessibility to health services.[J]. Journal of medical systems, 2006, 30(1):23-32. DOI: 10.1007/s10916-006-7400-5 doi: 10.1007/s10916-006-7400-5 pmid: 16548411
[15]	刘贤腾. 空间可达性研究综述[J]. 城市交通, 2007(6):36-43.
	[ Liu X T. A review of spatial accessibility[J]. Urban Transport of China, 2007(6):36-43. ] DOI: 10.13813/j.cn11-5141/u.2007.06.010 doi: 10.13813/j.cn11-5141/u.2007.06.010
[16]	Luo W, Wang F H. Measures of spatial accessibility to health care in a GIS environment: Synjournal and a case study in the Chicago Region[J]. Environment and Planning B: Planning and Design, 2003, 30(6):865-884. DOI: 10.1068/b29120 doi: 10.1068/b29120
[17]	Mark F Guagliardo. Spatial accessibility of primary care: concepts, methods and challenges[J]. Int J Health Geogr 3,3(2004). DOI: 10.1186/1476-072X-3-3 doi: 10.1186/1476-072X-3-3
[18]	Naess P. Accessibility, activity participation and location of activities: Exploring the links between residential location and travel behaviour[J]. Urban Studies, 2006, 43(3):627-652. DOI: 10.1080/00420980500534677 doi: 10.1080/00420980500534677
[19]	Ribeiro A, Antunes A P. A GIS-based decision-support tool for public facility planning. Environment & Planning B, 2002, 29(4):553-569. DOI: 10.1068/b1281 doi: 10.1068/b1281
[20]	王姣娥, 莫辉辉. 民航机场布局方法探讨[J]. 中国民航飞行学院学报, 2009, 20(6):7-10.
	[ Wang J E, Mo H H. Discussion on the layout method of civil aviation airport[J]. Journal of Civil Aviation Flight University of China, 2009, 20(6):7-10. ] DOI: 10.3969/j.issn.1009-4288.2009.06.003 doi: 10.3969/j.issn.1009-4288.2009.06.003
[21]	吴威, 曹有挥, 梁双波, 等. 民用机场区域服务能力的结构与空间格局——以长江经济带民用机场体系为例[J]. 地理研究, 2019, 38(6):1512-1526. doi: 10.11821/dlyj020170970
	[ Wu W, Cao Y H, Liang S B, et al. Structure and spatial pattern of regional service capability of civil airports-a case study of civil airport system in Yangtze river economic belt[J]. Geographical Research, 2019, 38(6):1512-1526. ] DOI: 10.11821/dlyj020170970 doi: 10.11821/dlyj020170970
[22]	许幸, 杨绪彪. 浅谈机场与区域经济的互动关系[J]. 物流科技, 2020, 43(10):118-120.
	[ Xu X, Yang X B. On the Interaction between Airport and Regional Economy. Logistics Sci-Tech, 2020, 43(10):118-120. ] DOI: 10.13714/j.cnki.1002-3100.2020.10.029 doi: 10.13714/j.cnki.1002-3100.2020.10.029
[23]	黄洁, 王姣娥. 枢纽机场的航班波体系结构及其喂给航线的空间格局研究[J]. 地理科学, 2018, 38(11):1750-1758. doi: 10.13249/j.cnki.sgs.2018.11.002
	[ Huang J, Wang J E. Wave-system structures of airport hubs and spatial patterns of possible indirect connections[J]. Scientia Geographica Sinica, 2018, 38(11):1750-1758. ] DOI: 10.13249/j.cnki.sgs.2018.11.002 doi: 10.13249/j.cnki.sgs.2018.11.002
[24]	金凤君, 王成金. 轴-辐侍服理念下的中国航空网络模式构筑[J]. 地理研究, 2005, 24(5):774-784.
	[ Jin F J, Wang C J. Hub-and-Spoke System and China Aviation Network Organization[J]. Geographical Research, 2005, 24(5):774-784. ] DOI: 10.3321/j.issn:1000-0585.2005.05.015 doi: 10.3321/j.issn:1000-0585.2005.05.015
[25]	王法辉, 金凤君, 曾光. 中国航空客运网络的空间演化模式研究[J]. 地理科学, 2003, 23(5):519-525.
	[ Wang F H, Jin F J, Zeng G. Geographic patterns of air passenger transport in China[J]. Scientia Geographica Sinica, 2003, 23(5):519-525. ] DOI: 10.13249/j.cnki.sgs.2003.05.002 doi: 10.13249/j.cnki.sgs.2003.05.002
[26]	Cook G N, Goodwin J. Airline networks: A comparison of hub- and-spoke and point-to-point systems[J]. Journal of Aviation /Aerospace Education & Research, 2008, 17(2):52-54. DOI: 10.15394/jaaer.2008.1443 doi: 10.15394/jaaer.2008.1443
[27]	唐雅茹. 日本成田机场快线对市郊快线建设的启示[J]. 城市轨道交通研究, 2009, 12(7):5-8.
	[ Tang Y R. Inspiration of NARITA EXPRESS for suburb rapid line construction[J]. Urban Mass Transit, 2009, 12(7):5-8. ] DOI: 10.16037/j.1007-869x.2009.07.020 doi: 10.16037/j.1007-869x.2009.07.020
[28]	王倩, 翟文鹏. 珠三角机场群航班时刻优化研究[J]. 河南科技大学学报(自然科学版), 2018,39(1):29-34, 40,6.
	[ Wang Q, Zhai W P. Research on flight schedule optimization of the Pearl River Delta Multi-airport[J]. Journal of Henan University of Science and Technology(Natural Science), 2018,39(1):29-34, 40,6. ] DOI: 10.15926/j.cnki.issn1672-6871.2018.01.006 doi: 10.15926/j.cnki.issn1672-6871.2018.01.006
[29]	朱诺. 北京首都机场国际航空运输市场监测分析[J]. 空运商务, 2020(1):32-37.
	[ Zhu N. Beijing Capital Airport International Air Transport Market Monitoring Analysis. Air Transport & Business, 2020(1):32-37. ] DOI: 10.3969/j.issn.1671-3095.2020.01.023 doi: 10.3969/j.issn.1671-3095.2020.01.023
[30]	北京市规划和自然资源委员会. 北京城市总体规划(2016-2035)[EB/OL]. 2018-01.
	[ Beijing Municipal Commission of Planning and Natural Resources. Master Planning of Beijing (2016-2035)[EB/OL]. 2018-01. ]http://ghzrzyw.beijing.gov.cn/zhengwuxinxi/zxzt/bjcsztgh20162035/202001/t20200102_1554613.html
[31]	张文尝, 等. 城市交通与城市发展[M]. 北京: 商务印书馆, 2010.
	[ Zhang W C, et al. Urban Transportation and Urban Development[M]. Beijing: The Commercial Press, 2010. ]
[32]	潘竟虎, 从忆波. 中国民用机场可达性与服务范围测度[J]. 经济地理, 2015, 35(2):46-53.
	[ Pan J H, Cong Y B. Measurement to accessibility and service coverage of civil airports in China[J]. Economic Geography, 2015, 35(2):46-53. ] DOI: 10.15957/j.cnki.jjdl.2015.02.007 doi: 10.15957/j.cnki.jjdl.2015.02.007
[33]	曹小曙, 廖望. 全球多机场区域空间格局与类型划分[J]. 地理科学进展, 2018, 37(11):1473-1484. doi: 10.18306/dlkxjz.2018.11.004
	[ Cao X S, Liao W. Spatial pattern and classification of the worldwide multi-airport regions[J]. Progress in Geography, 2018, 37(11):1473-1484. ] DOI: 10.18306/dlkxjz.2018.11.004 doi: 10.18306/dlkxjz.2018.11.004
[34]	Dresner M, Lin J S C, Windle R. The impact of low-costcarriers on airport and route competition[J]. Journal of Transport Economics and Policy, 1996, 30(3):309-328. DOI: 10.4324/9781315091617-18 doi: 10.4324/9781315091617-18
[35]	Lieshout R, Malighetti P, Redondi R, et al. The competitive landscape of air transport in Europe[J]. Journal of Transport Geography, 2016, 50:68-82. DOI: 10.1016/j.jtrangeo.2015.06.001 doi: 10.1016/j.jtrangeo.2015.06.001
[36]	Sun X, Wandelt S, Hansen M, et al. Multiple airport regions based on inter- airport temporal distances[J]. Transportation Research Part E: Logistics & Transportation Review, 2017, 101:84-98. DOI: 10.1016/j.tre.2017.03.002 doi: 10.1016/j.tre.2017.03.002
[37]	陈杰, 李昂, 符峥, 等. 公交模式对公共服务设施可达性的影响[J]. 地球信息科学学报, 2019, 21(7):983-993. doi: 10.12082/dqxxkx.2019.180328
	[ Chen J, Li A, Fu Z, et al. Accessibility of public service facilities as influenced by public transport modes[J]. Journal of Geo-information Science, 2019, 21(7):983-993. ] DOI: 10.12082/dqxxkx.2019.18032 doi: 10.12082/dqxxkx.2019.18032

数据类型	数据来源	数据年份
路网数据	OpenStreetMap（OSM）空间数据集(https://www.openstreetmap.org/)	2020
实时出行数据	高德地图API路径规划平台（ https://lbs.amap.com/api/webservice/guide/api/direction）	2020
点位坐标	高德地图API地理编码平台（ https://lbs.amap.com/api/webservice/guide/api/georegeo）	2020
人口密度数据	WorldPop数据集(https://www.worldpop.org/)	2020

起点	终点	车程时间/h		时间差/min	起点	终点	车程时间/h		时间差/min
起点	终点	拥堵时段	非拥堵时段	时间差/min	起点	终点	拥堵时段	非拥堵时段	时间差/min
北京西站	首都机场	1.28	0.97	18.48	北京西站	大兴机场	0.91	0.86	2.73
黄村站		1.58	1.37	12.7	黄村站		0.58	0.53	2.92
北京东站		0.78	0.57	12.53	北京东站		0.96	0.91	3.28
北京站		0.85	0.67	10.58	北京站		1.10	1.08	1.17
北京南站		1.12	0.95	9.68	北京南站		0.82	0.78	2.43
北京北站		0.84	0.70	8.08	北京北站		1.10	1.09	0.88
大兴机场		1.37	1.29	4.88	首都机场		1.37	1.29	4.88
清河站		0.71	0.63	4.77	清河站		1.27	1.18	5.05
通州西站		0.78	0.70	4.38	通州西站		1.08	1.06	1.23
北京朝阳站		0.51	0.44	4.20	北京朝阳站		1.14	1.07	4.50
昌平北站		0.97	0.91	3.20	昌平北站		2.03	1.79	14.30
顺义西站		0.50	0.45	3.00	顺义西站		1.60	1.58	0.88
均值				8.04	均值				3.69

起点	终点	时间/h	起点	终点	时间/h
大兴机场	首都机场	2.21	首都机场	大兴机场	2.21
北京朝阳站		1.19	北京朝阳站		2.20
北京东站		1.22	北京东站		2.76
北京站		0.90	北京站		1.44
北京北站		1.06	北京北站		2.59
顺义西站		1.52	顺义西站		2.63
清河站		1.27	清河站		2.82
通州西站		1.30	通州西站		2.06
北京南站		1.10	北京南站		2.53
北京西站		1.17	北京西站		2.42
昌平北站		1.29	昌平北站		2.33
黄村站		1.65	黄村站		2.02
