乌江上游地区森林生态系统水源涵养功能评估及其空间差异探究

doi:10.3724/SP.J.1047.2016.00987

摘要/Abstract

摘要：

乌江流域是西南地区重要经济中心的生态和安全屏障,其上游地区长年面临水土流失和土地石漠化等问题,严重影响到当地和长江沿岸人民的生产生活。本文基于贵州省毕节地区2010年森林二类调查小班数据,运用综合能力蓄水法对乌江上游地区森林生态系统水源涵养量进行估算,分析了水源涵养能力的空间分异特征,并使用线性回归和相关分析法对森林水源涵养能力与林地海拔、坡度和土地退化类型之间的关系进行了深入探讨。结果表明：（1）2010年,研究区森林生态系统的水源涵养总量为563.05 $×$ 10⁶ m³,单位面积水源涵养量达774.73 t/hm²,水源涵养能力分布表现为东部地区自东北向西南逐渐减弱、西部地区强弱相间的碎片化分布特征;（2）随着林地海拔的升高,森林单位面积水源涵养量表现出显著的下降趋势 $(P < 0.01)$ ,海拔平均每上升1000 m,单位水源涵养量相应减少90.56 t/hm²左右;（3）森林水源涵养能力与坡度呈显著的负相关 $(P < 0.01)$ ,坡度平均每增加1°,单位水源涵养量相应减少2.44 t/hm²;（4）土地退化对森林水源涵养功能的影响较大,退化土地的森林水源涵养能力较非退化土地平均下降23.50%。正确认识森林生态系统的水源涵养功能及其空间差异,对了解当地森林生态系统现状,以及制订实施更有针对性、更高效的水资源可持续利用和生态环境恢复及建设等相关政策具有重要意义。

关键词: 水源涵养, 乌江上游, 森林生态系统, 立地条件, 土地退化, 综合蓄水能力法

Abstract:

As the longest tributary on the right bank of upper Yangtze River, while also occupying the largest basin area in Guizhou Province, Wujiang River is of great importance to the economic and ecological environment in Yangtze Basin and Southwest China. However, the upper reaches of Wujiang River are suffering from long-term soil erosion and land degradation, which has threatened the local safety and development. This paper, based on the forest resource inventory data of Bijie prefecture in Guizhou Province in 2010, aims to estimate the water conservation of forest ecosystem in the upper reaches of Wujiang River and to analyze its spatial variation. The relationship between the unit water conversation of forest ecosystem, which is regarded as the Forest Water Conservation Capacity (FWCC) in this paper, and elevation, slope and land degradation types was deeply explored. The integrated storage capacity method and the linear regression was employed. The results show that: (1) In 2010, the water conservation of forest ecosystem in the study area was 563.05 million cubic meters in total, yielding a water conservation of 774.73 t/hm² per unit area. FWCC presented a pattern of gradually decreasing from northeast to southwest in the east region, and an uneven pattern in the west region. (2) A significant $(P < 0.01)$ negative correlation was found between FWCC and elevation, that FWCC decreased by 90.56 t/hm² with every 1 km increase in elevation. (3) FWCC significantly $(P < 0.01)$ decreased by 2.44 t/hm² with every 1 degree increase in slope. (4) Land degradation showed a strong negative effect to FWCC, and the FWCC of degraded land dropped by 23.50% on average compared with the non-degraded land. A better understanding of the water conservation function and its spatial variation of forest ecosystem would be helpful to learn the status of local forest ecosystem, and to formulate and implement the sustainable utilization of water resources, as well as the restoration and construction of ecological environment, under the guidance of more targeted and efficient policies.

Key words: water conservation, Wujiang River basin, forest ecosystem, site condition, land degradation, integrated storage capacity method

唐玉芝, 邵全琴. 乌江上游地区森林生态系统水源涵养功能评估及其空间差异探究[J]. 地球信息科学学报, 2016, 18(7): 987-999.DOI:10.3724/SP.J.1047.2016.00987

TANG Yuzhi,SHAO Quanqin. Water Conservation Capacity of Forest Ecosystem and Its Spatial Variation in the Upper Reaches of Wujiang River[J]. Journal of Geo-information Science, 2016, 18(7): 987-999.DOI:10.3724/SP.J.1047.2016.00987

图/表 11

图1

表1

表2

图2

图3

表3

图4

图5

表4

图6

图7

参考文献 52

[1]	陈东立,余新晓,廖邦洪.中国森林生态系统水源涵养功能分析[J].世界林业研究,2005,18(1):49-54. doi: 10.3969/j.issn.1001-4241.2005.01.010
	[ Chen D ., Yu X ., Liao B H.Analysis on the function of conservation water of the Chinese forest ecosystem[J]. World Forestry Research, 2005,18(1):49-54. ] doi: 10.3969/j.issn.1001-4241.2005.01.010
[2]	鲁绍伟,毛富玲,靳芳,等.中国森林生态系统水源涵养功能[J].水土保持研究,2005,12(4):223-226.
	[ Lu S ., Mao F ., Jin ., et al.The water resource conservation of forest ecosystem in China[J]. Research of Soil and Water Conservation, 2005,12(4):223-226. ]
[3]	邓坤枚,石培礼,谢高地.长江上游森林生态系统水源涵养量与价值的研究[J].资源科学,2002,24(6):68-73. doi: 10.3321/j.issn:1007-7588.2002.06.012
	[ Deng K ., Shi P ., Xie G D.Water conservation of forest ecosystem in the upper reaches of Yangtze River and its benefits[J]. Resources Science, 2002,24(6):68-73. ] doi: 10.3321/j.issn:1007-7588.2002.06.012
[4]	石培礼,吴波,程根伟,等.长江上游地区主要森林植被类型蓄水能力的初步研究[J].自然资源学报,2004,19(3):351-360. doi: 10.3321/j.issn:1000-3037.2004.03.012
	[ Shi P ., Wu ., Cheng G ., et al.Water retention capacity evaluation of main forest vegetation types in the upper Yangtze basin[J]. Journal of Natural Resources, 2004,19(3):351-360. ] doi: 10.3321/j.issn:1000-3037.2004.03.012
[5]	温远光,刘世荣.我国主要森林生态系统类型降水截留规律的数量分析[J].林业科学,1995,31(4):289-298.
	[ Wen Y ., Liu S R.Quantitative analysis of the characteristics of rainfall interception of main forest ecosystems in China[J]. Scientia Silvae Sinicae, 1995,31(4):289-298. ]
[6]	Wilcox B ., Thurow T L.Emerging issues in rangeland ecohydrology: vegetation change and the water cycle[J]. Rangeland Ecology & Management, 2006,59(2):220-224. doi: 10.2111/05-090R1.1
[7]	Guo ., Xiao ., Gan ., et al.Ecosystem functions, services and their values-a case study in Xingshan county of China[J]. Ecological Economics, 2001,38(1):141-154. doi: 10.1016/S0921-8009(01)00154-9
[8]	张彪,李文华,谢高地,等.北京市森林生态系统的水源涵养功能[J].生态学报,2008,28(11):5619-5624. doi: 10.3321/j.issn:1000-0933.2008.11.046
	[ Zhang ., Li W ., Xie G ., et al.Characteristics of water conservation of forest ecosystem in Beijing[J]. Acta Ecologica Sinica, 2008,28(11):5619-5624. ] doi: 10.3321/j.issn:1000-0933.2008.11.046
[9]	蔡体久. 基于RS和GIS的林型结构与森林涵养水源关系的研究[J].水土保持学报,2001,15(4):16-19. doi: 10.3321/j.issn:1009-2242.2001.04.005
	[ Cai T J.Relationship between forest types and water conservation function of forest based on RS and GIS[J]. Journal of Soil and Water Conservation, 2001,15(4):16-19. ] doi: 10.3321/j.issn:1009-2242.2001.04.005
[10]	聂忆黄. 基于地表能量平衡与SCS模型的祁连山水源涵养能力研究[J].地学前缘,2010,17(3):269-275.
	[ Nie Y H.A study of the water conservation of Qilian Mountains based on surface energy balance and SCS model[J]. Earth Science Frontiers, 2010,17(3):269-275. ]
[11]	王晓学,李叙勇,莫菲,等.基于元胞自动机的森林水源涵养量模型新方法——概念与理论框架[J].生态学报,2010,30(20):5491-5500.
	[ Wang X ., Li X ., Mo ., et al.Exploration of a new modeling method for forest water conservation based on cellular automata: concept and theoretical framework[J]. Acta Ecologica Sinica, 2010,30(20):5491-5500. ]
[12]	张堡宸,胡建荣,李新军,等.基于遥感数据的森林水源涵养估测研究[J].中国农学通报,2014,30(1):98-102.
	[ Zhang B ., Hu J ., Li X ., et al.Estimation and research of forest water conservation based on remote sensing[J]. Chinese Agricultural Science Bulletin, 2014,30(1):98-102. ]
[13]	余新晓,周彬,吕锡芝,等.基于InVEST模型的北京山区森林水源涵养功能评估[J].林业科学,2012,48(10):1-5. doi: 10.11707/j.1001-7488.20121001
	[ Yu X ., Zhou ., Lu X ., et al.Evaluation of water conservation function in mountain forest areas of Beijing based on InVEST model[J]. Scientia Silvae Sinicae, 2012,48(10):1-5. ] doi: 10.11707/j.1001-7488.20121001
[14]	Calder I R.Dependence of rainfall interception on drop size: development of the two-layer stochastic model[J]. Journal of Hydrology, 1996,185(1):363-378. doi: 10.1016/0022-1694(95)02998-2
[15]	Fujieda ., Kudoh T, de Cicco V, et al. Hydrological processes at two subtropical forest catchments: the Serra do Mar, São Paulo, Brazil[J]. Journal of Hydrology, 1997,196(1):26-46.
[16]	Johnson R C.The interception, throughfall and stemflow in a forest Highland Scotland and the comparison with other upland forests in the U.K[J]. Journal of Hydrology, 1990,118(1):281-287.
[17]	Onda ., Yukawa N.The influence of understories and litter layer on the infiltration of forested hillslopes[C]. Proceedings of the International Symposium of Forest Hydrology, 1994:107-114.
[18]	Andréassian V.Waters and forests: from historical controversy to scientific debate[J]. Journal of Hydrology, 2004,291(1):1-27. doi: 10.1016/j.jhydrol.2003.12.015
[19]	Sandström K.Can forests provide water: widespread myth or scientific reality?[J]. Ambio, 1998,27(2):132-138.
[20]	Vertessy R ., Zhang ., Dawes W R.Plantations, river flows and river salinity[J]. Australian Forestry, 2003,66(1):55-61. doi: 10.1080/00049158.2003.10674890
[21]	Bonell ., Purandara B ., Venkatesh ., et al.The impact of forest use and reforestation on soil hydraulic conductivity in the Western Ghats of India: Implications for surface and sub-surface hydrology[J]. Journal of Hydrology, 2010,391(1):47-62.
[22]	Jobbagy E ., Jackson R B.Groundwater use and salinization with grassland afforestation[J]. Global Change Biology, 2004,10(8):1299-1312. doi: 10.1111/j.1365-2486.2004.00806.x
[23]	Nosetto M ., Jobbagy E ., Paruelo J M.Land-use change and water losses: the case of grassland afforestation across a soil textural gradient in central Argentina[J]. Global Change Biology, 2005,11(7):1101-1117. doi: 10.1111/j.1365-2486.2005.00975.x
[24]	Sahin ., Hall M J.The effects of afforestation and deforestation on water yields[J]. Journal of Hydrology, 1996,178(1):293-309. doi: 10.1016/0022-1694(95)02825-0
[25]	Brauman K ., Freyberg D ., Daily G C.Forest structure influences on rainfall partitioning and cloud interception: a comparison of native forest sites in Kona, Hawai'i[J]. Agricultural and Forest Meteorology, 2010,150(2):265-275. doi: 10.1016/j.agrformet.2009.11.011
[26]	Cornish P ., Vertessy R A.Forest age-induced changes in evapotranspiration and water yield in a eucalypt forest[J]. Journal of Hydrology, 2001,242(1):43-63. doi: 10.1016/S0022-1694(00)00384-X
[27]	禄文斌. 毕节地区的水土流失及其防治对策[J].中国水土保持,1992,128(11):8-11.
	[ Lu W B.Soil loss in Bijie prefecture and its countermeasures of prevention and control[J]. Soil and Water Conservation in China, 1992,128(11):8-11. ]
[28]	李昊,蔡运龙,陈睿山,等.基于植被遥感的西南喀斯特退耕还林工程效果评价——以贵州省毕节地区为例[J].生态学报,2011,31(12):3255-3264.
	[ Li ., Cai Y ., Chen R ., et al.Effect assessment of the project of grain for green in the karst region in Southwestern China: a case study of Bijie Prefecture[J]. Acta Ecologica Sinica, 2011,31(12):3255-3264. ]
[29]	刘璐璐,邵全琴,刘纪远,等.琼江河流域森林生态系统水源涵养能力估算[J].生态环境学报,2013,22(3):451-457.
	[ Liu L ., Shao Q ., Liu J ., et al.Estimation of forest water conservation capacity in Qiongjiang River watershed[J]. Ecology and Environmental Sciences, 2013,22(3):451-457. ]
[30]	孙清琳,李延森,郭继凯,等.云和县森林生态系统水源涵养功能评估[J].北京大学学报(自然科学版),2015,51(5): 888-896.
	[ Sun Q ., Li Y ., Guo J ., et al.Assessment of water conservation function of forest ecosystem in Yunhe County, Zhejiang Province[J]. Acta Scientiarum Naturalium Universitatis Pekinensis, 2015,51(5):888-896. ]
[31]	吴丹,邵全琴,刘纪远.江西泰和县森林生态系统水源涵养功能评估[J].地理科学进展,2012,31(3):330-336. doi: 10.11820/dlkxjz.2012.03.008
	[ Wu ., Shao Q ., Liu J Y.Assessment of water conservation function of forest ecosystem in Taihe County, Jiangxi Province[J]. Progress in Geography, 2012,31(3):330-336. ] doi: 10.11820/dlkxjz.2012.03.008
[32]	苏帆. 重庆四面山森林涵养水源功能价值评价及管理研究[D].北京:北京林业大学,2010.
	[ Su F.Evaluation and management on forest water conservation in Simian Mountains, Chongqing, China[D]. Beijing: Beijing Forestry University, 2010. ]
[33]	戴晓勇,裴家模,罗魏,等.不同森林类型枯落物持水特性研究[J].贵州林业科技,2008,36(4):32-34.
	[ Dai X ., Pei J ., Luo ., et al.Study on litter water-holding characteristics of different forest vegetation types[J]. Guizhou Forestry Science and Technology, 2008,36(4):32-34. ]
[34]	李默然,丁贵杰,鲍斌,等.贵州黔东南地区不同森林类型涵养水源功能研究[J].广东农业科学,2013(10):162-165.
	[ Li M ., Ding G ., Bao ., et al.Study on water-holding function of main forest types in southeast of Guizhou Province[J]. Guangdong Agricultural Sciences, 2013,10:162-165. ]
[35]	张晓珊,巫启新,刘延惠.贵州省长防林体系生态经济效益计量与评价[J].贵州林业科技,2001,29(4):36-40.
	[ Zhang X ., Wu Q ., Liu Y H.Measurement and evaluation of the ecological and economic benefits of Yangtze River Shelter Forest in Guizhou Province[J]. Guizhou Forestry Science and Technology, 2001,29(4):36-40. ]
[36]	秦嘉励. 岷江上游不同土地利用方式下土壤生态系统服务价值评估研究[D].成都:四川农业大学,2009.
	[ Qin J L.Valuing the soil ecosystem services of the different land-use types in the upper reaches of the Minjiang River[D]. Chengdu: Sichuan Agricultural University, 2009. ]
[37]	秦嘉励,杨万勤,张健.岷江上游典型生态系统水源涵养量及价值评估[J].应用与环境生物学报,2009,15(4):453-458. doi: 10.3724/SP.J.1145.2009.00453
	[ Qin J ., Yang W ., Zhang J.Assessment of ecosystem water conservation value in the upper Minjiang River, Sichuan, China[J]. Chinese Journal of Applied Environmental Biology, 2009,15(4):453-458. ] doi: 10.3724/SP.J.1145.2009.00453
[38]	张彪,李文华,谢高地,等.森林生态系统的水源涵养功能及其计量方法[J].生态学杂志,2009,28(3):529-534.
	[ Zhang ., Li W ., Xie G ., et al.Water conservation function and its measurement methods of forest ecosystem[J]. Chinese Journal of Ecology, 2009,28(3):529-534. ]
[39]	张立恭. 岷江上游水源涵养林涵水能力综合评价[J].四川林勘设计,1997(4):27-31.
	[ Zhang L G.A comprehensive evaluation of water-storage ability of water conservation forest in the upper reaches of Minjiang River[J]. Sichuan Forestry Exploration And Design, 1997,4:27-31. ]
[40]	Qian S.Environmental and ecological statistics with R[M]. Boca Raton, FL: CRC Press, 2010.
[41]	王秀春,黄秋昊,蔡运龙.贵州省乌江流域植被覆盖动态变化分析[J].水土保持研究,2008,15(5):15-17.
	[ Wang X ., Huang Q ., Cai Y L.Assessment of vegetative land cover change using AVHRR/NDVI and SPOT/NDVI data in Wujiang River basin, Southwest China[J]. Research of Soil and Water Conservation, 2008,15(5):15-17. ]
[42]	姚文艺,汤立群.水力侵蚀产沙过程及模拟[M].郑州:黄河水利出版社,2001.
	[ Yao W ., Tang L Q.Process and simulation of hydraulic erosion and sediment yield[M]. Zhengzhou: The Yellow River Water Conservancy Press, 2001. ]
[43]	陈法扬. 不同坡度对土壤冲刷量影响试验[J].中国水土保持,1985(2):26-31.
	[ Chen F Y.Test of effect of different slope on soil erosion[J]. Soil and Water Conservation in China, 1985,2:26-31. ]
[44]	刘志,江忠善.降雨因素和坡度对片蚀影响的研究[J].水土保持通报,1994,14(6):19-22.
	[ Liu ., Jiang Z S.Study on the influence of rainfall factors and slope on the sheet erosion[J]. Bulletin of Soil and Water Conservation, 1994,14(6):19-22. ]
[45]	王秀英,曹文洪,陈东.土壤侵蚀与地表坡度关系研究[J].泥沙研究,1998(2):36-41.
	[ Wang X ., Cao W ., Chen D.Study on relationship between soil erosion and land slope[J]. Journal of Sediment Research, 1998,2:36-41. ]
[46]	蔡运龙,蒙吉军.退化土地的生态重建:社会工程途径[J].地理科学,1999,19(3):198-204.
	[ Cai Y ., Meng J J.Ecological reconstruction of degraded land: a social approach[J]. Scientia Geographica Sinica, 1999,19(3):198-204. ]
[47]	周应书,何兴辉,谢永贵,等.毕节喀斯特山地植被恢复立地类型划分[J].林业科学,2008,44(12):123-128. doi: 10.11707/j.1001-7488.20081222
	[ Zhou Y ., He X ., Xie Y ., et al.Type classification for vegetation restoration of Karst Mountains in Bijie[J]. Scientia Silvae Sinicae, 2008,44(12):123-128. ] doi: 10.11707/j.1001-7488.20081222
[48]	伍光和,蔡运龙.综合自然地理学[M].北京:高等教育出版社,2004.
	[ Wu G ., Cai Y L.Integrated physical geography[M]. Beijing: Higher Education Press, 2004. ]
[49]	Vitousek P ., Mooney H ., Lubchenco ., et al.Human domination of Earth's ecosystems[J]. Science, 1997,277(5325):494-499.
[50]	Crawford R M .. Eco-hydrology: plants and water in terrestrial and aquatic environments.[J]. Journal of Ecology, 2000,88(6):1095-1096. doi: 10.1046/j.1365-2745.2000.05262.x
[51]	刘世荣. 中国森林生态系统水文生态功能规律[M].北京:中国林业出版社,1996.
	[ Liu S R.Ecohydrological functions of forest ecosystems in China[M]. Beijing:China Forestry Publishing House, 1996. ]
[52]	罗明,龙花楼.土地退化研究综述[J].生态环境,2005,14(2):287-293.
	[ Luo ., Long H L.Progress in the research on land degradation[J]. Ecology and Environment, 2005,14(2):287-293. ]

森林类型	海拔范围/m	平均郁闭度	平均胸径/cm	活立木蓄积量/（m³/hm²）	平均土层厚度/cm	主要优势树种
温性针叶林	786~2854	0.394	8.239	15.890	42.36	华山松、柳杉
暖性针叶林	714~2566	0.475	12.003	36.826	39.09	马尾松、云南松、杉木
暖性针阔混交林	782~2450	0.419	10.302	24.944	42.00	针阔混交林
落叶阔叶林	705~2472	0.399	9.443	19.197	42.27	桦类、椴类、杨树
常绿落叶阔叶混交林	722~2677	0.532	9.097	20.827	36.67	栎类
常绿阔叶林	777~2618	0.523	9.301	25.185	38.04	樟类、楠类
暖性竹林	804~2074	0.703	4.368	0.003	52.92	毛竹、杂竹
经济林	738~2442	0.311	3.597	2.838	44.44	梨桃类、核桃、板栗
灌丛	708~2886	0.489	0.003	0.004	31.70	杂灌、茶叶、火棘

森林类型	林冠层截留率/（%）	枯落物层单位最大持水量/（t/hm²）	土壤层非毛管孔隙度/（%）	文献来源
温性针叶林	28.73	25.67	10.16	[32]、[33]、[4]
暖性针叶林	28.50	37.69	8.91	[32]、[34]、[4]
暖性针阔混交林	24.33	34.08	12.13	[34]、[33]、[34]
落叶阔叶林	20.19	32.46	9.15	[34]、[33]、[34]
常绿落叶阔叶混交林	22.57	32.66	15.32	[32]、[33]、[4]
常绿阔叶林	18.14	18.62	10.31	[34]、[34]、[34]
暖性竹林	18.83	20.69	11.77	[32]、[33]、[4]
经济林	29.32	23.8	8.65	[35]、[31]、[36]
灌丛	24.56	15.97	9.80	[35]、[33]、[37]

代码	森林类型	林地面积/（10³hm²）	林冠截留量/（10⁶m³）	枯落物层持水量/（10⁶m³）	土壤蓄水量/（10⁶m³）	水源涵养总量/（10⁶m³）	单位面积水源涵养量/（t/hm²）
Ⅰ	温性针叶林	135.086	56.702	3.468	58.334	118.503	877.245
Ⅱ	暖性针叶林	125.837	52.397	4.743	44.942	102.081	811.216
Ⅲ	暖性针阔混交林	9.427	3.351	0.321	4.754	8.426	893.807
Ⅳ	落叶阔叶林	67.856	20.016	2.203	26.279	48.497	714.705
Ⅴ	常绿落叶阔叶混交林	64.007	21.106	2.090	37.225	60.421	943.975
Ⅵ	常绿阔叶林	4.173	1.106	0.078	1.700	2.883	690.942
Ⅶ	暖性竹林	0.202	0.056	0.004	0.129	0.189	934.861
Ⅷ	经济林	3.103	1.329	0.074	1.172	2.575	829.922
Ⅸ	灌丛	317.078	113.775	5.064	100.635	219.473	692.174

代码	森林类型	回归方程	相关系数R²	P
Ⅰ	温性针叶林	y = -2.5116x + 938.62	0.765	*
Ⅱ	暖性针叶林	y = -0.8702x + 831.01	0.378
Ⅲ	暖性针阔混交林	y = -3.8570x +1002.48	0.583
Ⅳ	落叶阔叶林	y = -2.6220x + 787.02	0.803	*
Ⅴ	常绿落叶阔叶混交林	y = -0.8110x + 948.23	0.106
Ⅵ	常绿阔叶林	y = -1.2000x + 727.78	0.348
Ⅶ	暖性竹林	y = -7.1497x + 991.73	0.744	*
Ⅷ	经济林	y = -4.8133x + 998.49	0.582
Ⅸ	灌丛	y = -0.5153x + 687.96	0.136
	研究区整体	y = -2.4350x + 828.09	0.910	**
