深圳湾和岘港湾30年土地利用变化研究

doi:10.3724/SP.J.1047.2016.01276

摘要/Abstract

摘要：

本文以南海周边的岘港湾和深圳湾为研究对象,选取了1987年和2015年的遥感影像,基于土地利用转移矩阵、土地利用动态度模型和土地利用程度模型,对2个海湾近30年来的土地利用变化情况进行了对比研究,对所属海岸带的绿地、围填海及城市扩张等变化程度进行了整体分析,透过海湾不同的土地利用特征探究其发展情况。研究结果表明：（1）深圳湾原本的耕地全部被开发为城镇用地,约51%的养殖用地转变为城镇用地,而岘港湾约有86%耕地转化为城镇用地,养殖用地面积则增加了1.43 km²;（2）深圳湾填海造陆面积达32 km²,岘港湾填海造陆面积约5 km²,远小于深圳湾的造陆强度;（3）岘港湾城镇土地增加速度略高于深圳湾,其2015年土地利用综合指数为283.28,而深圳湾在1987年就达到274.12,且2015年该值高达320.52,岘港湾的土地利用综合指数远低于同期深圳湾的水平,岘港湾的土地利用呈现出明显的工业化中期的土地利用特征,而深圳湾则已进入工业化后期;（4）岘港湾裸地面积增加了3.5倍,而深圳湾没有增加,深圳湾的红树林面积增加了2.1倍,而岘港湾的红树林在1987年前已消失,深圳湾的开发方式更注重对自然土地类型及功能性绿地的保护。

关键词: 南海, 海湾, 土地利用变化, 遥感, 区域对比

Abstract:

Bays that are similar in their geographical conditions may experience different land use changes due to the distinct levels of development. In this paper, Shenzhen Bay in China and Danang Bay in Vietnam were chosen as the study regions. Based on the land use data in 1987 and 2015, which is interpreted from Landsat image, a dynamic degree model and a comprehensive index was used to extract the information of land exploration and utilization in Shenzhen Bay and Danang Bay. Finally, the level of economic development was estimated by analyzing the land use changes. The whole research includes four parts that are explained as follows. (1) From 1987 to 2015, all of the arable land and 51% of the aquaculture land was turned into the urban land in Shenzhen Bay region. However, in Danang Bay region, 86% of the arable land was changed into the urban land and the aquaculture land had increased with an annual rate of 0.55 square kilometers, which is opposite to Shenzhen Bay. (2) The land area transformed from water in Shenzhen Bay is 32 square kilometer, being much greater than Danang Bay, which is 5 square kilometers, explaining that the scale of sea reclamation in Shenzhen Bay is far more severe than Danang Bay. (3) The dynamic degree of urban land in Danang Bay is higher than Shenzhen Bay. Meanwhile, the land utilization comprehensive index model claims that the land utilization degree in Shenzhen Bay is much higher, which reveals that the level of development in Shenzhen Bay is obviously higher than Danang Bay. Analysis on all land use changes shows that Danang Bay is in the middle of industrialization, while Shenzhen Bay is in the late industrialization. (4) The area of bare land had increased by 3.5 times in Danang Bay, while there was no increase in Shenzhen Bay. Furthermore, the area of mangroves had increased by 2.1 times in Shenzhen Bay. All of these conclusions indicate that more attention should be paid to the growth of natural functional vegetation and the protection of ecological environment in Shenzhen Bay than in Danang Bay.

Key words: South China Sea, bay, land use change, remote sensing, regional comparison

冯雪, 苏奋振, 王武霞, 丁智. 深圳湾和岘港湾30年土地利用变化研究[J]. 地球信息科学学报, 2016, 18(9): 1276-1286.DOI:10.3724/SP.J.1047.2016.01276

FENG Xue,SU Fenzhen,WANG Wuxia,DING Zhi. Study on Land Use Changes of Shenzhen Bay and Danang Bay for 30 Years[J]. Journal of Geo-information Science, 2016, 18(9): 1276-1286.DOI:10.3724/SP.J.1047.2016.01276

图/表 12

图1

表1

表2

图2

表3

表4

图3

表5

岘港湾1987-2015年土地利用状况

土地类型	1987年该类面积/ $k m 2$	1987年该类占陆域比例/（%）	2015年该类面积/ $k m 2$	2015年该类占陆域比例/（%）	减少地占1987年同类面积比例/（%）	增加地占2015年同类面积比例/（%）
草地	23.28	11.04	10.95	5.09	59.34	10.10
城镇用地	26.21	12.43	87.30	40.53	0.00	68.38
耕地	40.10	19.02	5.65	2.62	85.92	0.00
林地	110.66	52.48	107.80	50.05	2.58	0.00
裸地	0.47	0.22	1.68	0.78	0.00	71.84
沙地	10.14	4.81	0.56	0.26	95.20	6.97
养殖用地	0.00	0.00	1.43	0.66	0.00	100.00

表5

表6

图4

图5

表7

参考文献 27

[1]	徐国良,黄贤金,李丽,等. 1991-2011年南海周边国家及地区经济重心及经济发展重心演变分析[J].资源科学,2014(4):682-690.
	[ Xu G L, Huang X J, Li L, et al.Evolvement analysis of the economic gravity center and economic development gravity center in the regions of South China Sea during 1991-2011[J]. Resources Science, 2014,4:682-690. ]
[2]	骆东奇,姜文,周心琴,等.重庆市土地利用与经济发展耦合关系分析[J].资源调查与评价,2007,24(4):67-71. doi: 10.3969/j.issn.1009-4210.2007.04.014
	[ Luo D Q, Jiang W, Zhou X Q.A study of relationship between economic developmentand land use change in Chongqing City[J]. Scientific and Technological Management of Land and Resources, 2007,24(4):67-71. ] doi: 10.3969/j.issn.1009-4210.2007.04.014
[3]	孙颖. 区域土地资源配置与社会经济发展[J].地域研究与开发,2004,23(6):93-97. doi: 10.3969/j.issn.1003-2363.2004.06.022
	[ Sun Y.Regional land resources equipment and society economy development[J]. Areal Research and Development, 2004,23(6):93-97. ] doi: 10.3969/j.issn.1003-2363.2004.06.022
[4]	王业侨. 海南省经济社会发展与土地利用相关分析[J].地域研究与开发,2006,25(3):81-84,124. doi: 10.3969/j.issn.1003-2363.2006.03.019
	[ Wang Y Q.Analysis of the relationship between social economic development and land use in Hainan Province[J]. Areal Research and Development, 2006,25(3):81-84,124. ] doi: 10.3969/j.issn.1003-2363.2006.03.019
[5]	Abino A C, Kim S Y, Mi N J.Assessing land use and land cover of the Marikina sub-watershed, Philippines[J]. Forest Science & Technology, 2015,11(2):1-11. doi: 10.1080/21580103.2014.957353
[6]	Song G, Fu C L, Yong E.Landscape pattern change in Yueqing Bay wetland based on RS and GIS[J]. Journal of Northeast Forestry University, 2010,38(12):80-83. doi: 10.1017/S0004972710001772
[7]	Satyanarayana B, Mohamad K A, Idris I F, et al.Assessment of mangrove vegetation based on remote sensing and ground-truth measurements at Tumpat, Kelantan Delta, east coast of Peninsular Malaysia[J]. International Journal of Remote Sensing, 2011,32(6):1635-1650. doi: 10.1080/01431160903586781
[8]	Lam-Dao N, Pham-Bach V, Nguyen-Thanh M, et al.Change detection of land use and riverbank in Mekong Delta, Vietnam using time series remotely sensed data[J]. Journal of Resources and Ecology, 2011,2(4):370-374. doi: 10.3969/j.issn.1674-764x.2011.04.011
[9]	童绍玉,蔡运龙,李双成.云南省楚雄市与双柏县土地利用变化对比研究[J].地理研究,2006,25(3):397-405,563.
	[ Tong S Y, Cai Y L, Li S C.The comparative analysis of land use change between Chuxiong and Shuangbai in Yunnan Province[J]. Geographical Research, 2006,25(3):397-405,563. ]
[10]	刘永超,李加林,袁麒翔.人类活动对港湾岸线及景观变迁影响的比较——以中国象山港与美国坦帕湾为例[A].浙江省地理学会、宁波大学.2015年浙江省地理学会学术年会会议论文摘要集[C].浙江省地理学会、宁波大学,2015:1
	. [ Liu Y C, Li J L, Yuan Q X.Comparison of effect of human activity on the bay shoreline and landscape changes: in case of China Xiangshan and Tampa Bay[A]. In: Proceedings of the 2015 Zhejiang Geographical Society Annual Conference[C]. The Geographical Society of Zhejiang Province, Ningbo University,2015. ]
[11]	于杰,陈国宝,黄梓荣,等.近10年间广东省3个典型海湾海岸线变迁的遥感分析[J].海洋湖沼通报,2014(3):91-96.
	[ Yu J, Chen G B, Huang Z R, et al.Changes in the coastline of three typical bays in Guangdong during recent 10 years revealed by satellite image[J]. Transactions of Oceanology and Limnology, 2014,3:91-96. ]
[12]	黎氏红草. 越南岘港市旅游业发展现状及对策研究[D].南宁:广西大学,2011.
	[ Li S H C. On the strategy and status about Danang's tourism in Vietnam[D].Nanning: Guangxi University, 2011. ]
[13]	广西社会科学院副研究员杨然.岘港:广西进入中南半岛的重要门户[N].广西日报,2007-11-22006.
	[ Yang R. Danang: the important gateway of Guangxi into Indochina[N]. Nanning: Guangxi Daily, 2007-11-22006. ]
[14]	刘杏玲,赵焕庭,郑德延,等.深圳湾的演变与开发利用[J].热带海洋,1988(1):48-56.
	[ Liu X L, Zhao H T, Zheng D Y, et al.The evolution and development-utilization of Shenzhen Bay[J]. Journal of Tropical Oceanography, 1988,1:48-56. ]
[15]	黄惠莲. 岘港[J].东南亚研究资料,1985(1):100.
	[ Huang H L.Danang[J]. Southeast Asian Studies, 1985,1:100. ]
[16]	悠之.越南港口[N].广西日报,2007-03-05006.
	[ You Z. Vietnam bay[N]. Guangxi Daily, 2007-03-05006. ]
[17]	栾维新,崔红艳.基于GIS的辽河三角洲潜在海平面上升淹没损失评估[J].地理研究,2004,23(6):805-814,880.
	[ Luan W X, Cui H Y.Submerged loss assessment of potential sea-level rise of Liao River Delta Region based on GIS[J]. Geographical Research, 2004,23(6):805-814,880. ]
[18]	刘勇. 基于海湾系统概念及其分类的遥感应用[D].山东科技大学,2009.
	[ Liu Y.Remote sensing application based on bay system concept and classification[D]. Qingdao: Shandong University of Science and Technology, 2009. ]
[19]	苏奋振,等.海岸带遥感评估[M].北京:科学出版社,2015.
	[ Su F Zet al. Coastal remote sensing assessment[M]. Beijing: Science Press, 2015. ]
[20]	刘纪远,布和敖斯尔.中国土地利用变化现代过程时空特征的研究——基于卫星遥感数据[J].第四纪研究,2000,20(3): 229-239.
	[ Liu J Y, Buheaosier. Study on spatial-temporal feature of modern land-use change in China: Using remote sensing techniques[J]. Quaternary Sciences, 2000,20(3):229-239. ]
[21]	樊玉山,刘纪远.西藏自治区土地利用[M].北京:科学出版社,1992.
	[ Fan Y S, Liu J Y.Land use of Tibet autonomous region[M]. Beijing: Science Press, 1992. ]
[22]	宋艳暾,余世孝,李楠,等.快速城市化过程与景观格局研究——以深圳经济特区为例[J].中山大学学报(自然科学版),2006,45(6):87-92. doi: 10.3321/j.issn:0529-6579.2006.06.020
	[ Song Y T, Yu S X, Li N, et al.Relationship between processes of rapid urbanization and landscape temporal and spatial patterns - a case study in Shenzhen SEZ[J]. Acta Scientiarum Naturalium Universitatis Sunyatseni, 2006,45(6):87-92. ] doi: 10.3321/j.issn:0529-6579.2006.06.020
[23]	山东省人民政府.越南岘港市[J].山东政报,2006(8):48.
	[ Danang in Vietnam[J]. Gazette of the People's Government of Shandong Province, 2006,8:48. ]
[24]	常青,李双成,王仰麟,等.基于稳定映射分析的深圳绿色景观时空演化及启示[J].地理学报,2012,67(12):1611-1622.
	[ Chang Q, Li S C, Wang Y L, et al.Green landscape evolution and its diving factors in Shenzhen[J]. Acta Geographica Sinica, 2012,67(12):1611-1622. ]
[25]	张文忠,王传胜,吕昕,等.珠江三角洲土地利用变化与工业化和城市化的耦合关系[J].地理学报,2003,53(5):677-685. doi: 10.3321/j.issn:0375-5444.2003.05.005
	[ Zhang W Z, Wang C S, Lv X, et al.Coupling relationship between land use change and industrialization & urbanization in the Zhujiang River Delta[J]. Acta Geographica Sinica, 2003,58(5):677-685. ] doi: 10.3321/j.issn:0375-5444.2003.05.005
[26]	赵翠薇,濮励杰,孟爱云,等.基于经济发展阶段理论的土地利用变化研究——以广西江州区为例[J].自然资源学报,2006,21(2):172-179. doi: 10.11849/zrzyxb.2006.02.002
	[ Zhao C W, Pu L J, Meng A Y, et al.A study on land use changes based on theory of economic development phases - a case study of Jiangzhou county in Guangxi[J]. Journal of Natural Resources, 2006,21(2):172-179. ] doi: 10.11849/zrzyxb.2006.02.002
[27]	夏向阳,张红辉.后工业化时代沿海副省级城市经济发展及其驱动力研究——基于深圳、厦门、青岛、宁波4市的实证研究[J].科技进步与对策,2011(18):21-25. doi: 10.3969/j.issn.1001-7348.2011.18.005
	[ Xia X Y, Zhang H H.Coastal sub-provincial city economic development and driving force in the post-industrial era: based on the empirical research in Shenzhen, Xiamen, Qingdao and Ningbo[J]. Science & Technology Progress and Policy, 2011,18:21-25. ] doi: 10.3969/j.issn.1001-7348.2011.18.005

	深圳湾	岘港湾
位置	22o24′18″~22o32′12″N 113o53′06~11o02′30″E	16°4'19"~16°11'58"N 108°7'22"~108°14'35"E
水域面积/km²	90	130
年均温度/℃	22.4	25.9
年降水量/mm	1933	2505
形态	狭长型半封闭	宽长型半开敞
平均潮差/m	0.38	0.7
近湾城市	经济特区深圳	直辖市岘港
河流作用	缓慢淤积	无明显淤积

	土地利用类型	分级指数
未利用土地级	裸地、沙地	1
土地自然再生利用级	林地、草地、水体	2
土地人为再生利用级	耕地、养殖用地	3
土地非再生利用级	城镇用地	4

土地类型	1987年该类面积/km²	1987年该类占陆域比例/（%）	2015年该类面积/km²	2015年该类占陆域比例/（%）	减少地占1987年同类面积比例/（%）	增加地占2015年同类面积比例/（%）
草地	12.79	5.13	22.87	7.97	43.81	68.50
城镇用地	62.57	25.12	167.83	58.48	0.00	62.72
耕地	14.65	5.88	0.00	0.00	100.00	0.00
红树林	2.68	1.08	5.73	2.00	18.47	64.94
林地	107.36	43.11	76.15	26.54	36.30	10.20
裸地	2.09	0.84	2.09	0.73	0.00	0.00
养殖用地	46.91	18.84	12.30	4.29	74.91	4.30
