黄土高原生态退耕的时空分异特征

doi:10.3724/SP.J.1047.2017.00355

摘要/Abstract

摘要：

生态退耕是调整陆地生态系统结构与功能以应对土地利用过度干扰的重要途径之一,因此科学掌握退耕格局与耕地格局演变对黄土高原生态环境治理与生态修复具有深远意义。本文以位于黄土高原的延安市为典型区,从生态退耕的整体特征、地形因素及区域差异等角度,探究生态退耕以来其耕地变化及退耕状况的空间分异特征。结果表明：生态退耕致使延安市耕地面积由2000年的11 752.80 km²减少为2013年的9149.93 km²,退耕面积为2756.85 km²,退耕指数为22.15%,且退耕耕地主要转化为林地、草地,占退耕面积的95.29%;耕地与退耕面积主要分布于6~15°、15~25°坡度及第II级（925~1115 m）、第III级（1115~1275 m）,且2005-2013年的生态退耕速率均高于2000-2005年的生态退耕速率;县域退耕面积及退耕程度均呈现由北向南依次递减的分异特征,而退耕重心与耕地重心均在延安市几何中心以北的安塞县与宝塔区边界,且生态退耕的重心由东北向西南方向迁移,耕地重心则由北向南迁移。本文通过对延安市生态退耕的时空分异特征分析可为黄土高原更加科学合理地推进生态保育与生态文明建设提供参考。

关键词: 生态退耕, 时空分异, 黄土高原, 延安市

Abstract:

Ecological restoration is an important way to adjust the structure and function of ecosystem in order to cope with the excessive interference of land use. Scientific mastery of restoration pattern and farmland pattern evolution has a profound significance on the management of regional ecological environment and the conservation of vegetation in Loess Plateau. This study, taking Yan'an City in Loess Plateau as a typical area, explores the spatial differentiation characteristics of farmland variation and restoration status from the overall characteristics of ecological restoration, topographic factors and regional differences since ecological restoration. The results show that the arable land of Yan'an City decreased from 11752.80 km² to 9149.93km² due to the ecology restoration during 2000-2013. The returned farmland is 2756.85 km², and the returned farmland index is 22.15%. The cultivated land was mostly converted to forest and grassland accounting for 95.29% of the total amount. Farmland and the returned farmland area was mainly distributed in slope (6~25°) and the altitude level of II（925~1115 m）, III（1115~1275 m）, IV（1275~1442 m）, which accounted for more than 70% of the area. The degree of farmland returning increased gradually with the increase of slope, with the land reclamation rate decreased gradually with the increase of slope and elevation. The highest degree of ecological restoration is the altitude level of IV, and the least is altitude level of III. The ecological restoration rate of 2005-2013 was higher than that of 2000-2005. The area and extent of restoration in county decreased from north to south. The center of farmland returning and cultivated land is located in the boundary of Ansai county and Baota District which are in the north of Yan’an City. The center of ecological restoration was changing from northeast to southwest while the center of cultivated land was changing from north to south. This study may provide more scientific and reasonable reference for ecological conservation and construction of ecological civilization in Loess Plateau by the analysis of spatial-temporal differentiation characteristics of ecological restoration in Yan'an city.

Key words: ecological restoration, spatial-temporal differentiation, the Loess Plateau, Yan'an city

杜国明, 孙晓兵, 刘彦随, 郑惠玉, 马榕徽. 黄土高原生态退耕的时空分异特征[J]. 地球信息科学学报, 2017, 19(3): 355-364.DOI:10.3724/SP.J.1047.2017.00355

DU Guoming,SUN Xiaobing,LIU Yansui,ZHENG Huiyu,MA Ronghui. Temporal and Spatial-Differentiation Characteristics of Ecological Restoration in Loess Plateau[J]. Journal of Geo-information Science, 2017, 19(3): 355-364.DOI:10.3724/SP.J.1047.2017.00355

图/表 8

图1

表1

图2

图3

图4

图5

图6

图7

参考文献 30

[1]	张甜,彭建,刘焱序,等.基于植被动态的黄土高原生态地理分区[J].地理研究,2015,34(9):1643-1661. doi: 10.11821/dlyj201509004
	[Zhang T, Peng J, Liu Y X, et al.Eco-geographical regionalization in Loess Plateau based on the dynamic consistency of vegetation[J]. Geographical Research, 2015,34(9):1643-1661. ] doi: 10.11821/dlyj201509004
[2]	王秀红,申建秀.中国生态退耕重要阶段耕地面积时空变化分析[J].中国农学通报,2013,29(29):133-137. doi: 10.11924/j.issn.1000-6850.2012-3966
	[Wang X H, Shen J X.Spatio-temporal changes in cropland area during important period of the grain-for-green policy in China[J]. Chinese Journal of Applied Ecology, 2013,29(29):133-137. ] doi: 10.11924/j.issn.1000-6850.2012-3966
[3]	谷长磊,刘琳,邱扬,等.黄土丘陵区生态退耕对草本层植物多样性的影响[J].水土保持研究,2013,20(5):99-103.
	[Gu C L, Liu L, Qiu Y, et al.Effects of ecological restoration on species diversity of herb layer in the hilly-gullied area of Loess Plateau[J]. Research of Soil and Water Conservation, 2013,20(5):99-103. ]
[4]	刘艳华,徐勇,刘毅.近20年来黄土高原地区的经济增长时空分异特征[J].地球信息科学学报,2012,14(1):22-31. doi: 10.3724/SP.J.1047.2012.00022
	[Liu Y H, Xu Y, Liu Y.Spatio-temporal difference of economic growth in the Loess Plateau Region over the past 20 years[J]. Journal of Geo-information Science, 2012,14(1):22-31. ] doi: 10.3724/SP.J.1047.2012.00022
[5]	刘宇,傅伯杰.黄土高原植被覆盖度变化的地形分异及土地利用/覆被变化的影响[J].干旱区地理,2013,36(6):1097-1102.
	[Liu Y, Fu B J.Topographical variation of vegetation cover evolution and the impact of land use/cover change in the Loess Plateau[J]. Arid Land Geography, 2013,36(6):1097-1102. ]
[6]	田剑,汤国安,周毅,等.黄土高原沟谷密度空间分异特征研究[J].地理科学,2013,33(6):622-628.
	[Tian J, Tan G A, Zhou Y, et al.Spatial variation of gully density in the Loess Plateau[J]. Scinece Geographica Sinica, 2013,33(6):622-628. ]
[7]	朱会义,吕昌河.近30年延安市耕地变化的政策背景及其作用机理[J].地理研究,2010,29(8):1510-1518.
	[Zhu H Y, Lv C H.Farmland change in Yan'an: The impact and acting mechanism of policies[J]. Geog Raphical Research,2010,29(8):1510-1518. ]
[8]	欧阳玲,王宗明,贾明明,等.基于遥感的吉林省中西部耕地数量和质量空间格局变化分析[J].农业工程学报,2016,32(13):234-242.
	[Ouyang L, Wang Z M, Jia M M, et al.Spatial pattern on quantity and quality of culatived land in mid-west Jilin province based on remote sensing[J]. Transactions of Chinses Society of Agricultural Engineering, 2016,32(13):234-242. ]
[9]	张文杰,程维明,李宝林,等.黄土高原丘陵沟壑区切沟侵蚀与地形关系分析——以纸坊沟流域为例[J].地球信息科学学报,2014,16(1):87-94. doi: 10.3724/SP.J.1047.2014.00087
	[Zhang W J, Cheng W M, Li B L, et al.The relationship between gully erosion and geomorphological factors in the hill and ravine region of the Loess Plateau[J]. Journal of Geo-information Science, 2014,16(1):87-94. ] doi: 10.3724/SP.J.1047.2014.00087
[10]	赵安周,刘宪锋,朱秀秀,等.2000-2014黄土高原植被覆盖时空变化特征及其归因[J].中国环境科学,2016,36(5):1568-1578.
	[Zhao A Z, Liu X F, Zhu X X, et al.Spatiotemporal analyses and associated driving forces of vegetation coverage change in the Loess Plateau[J]. China Environmental Science, 2016,36(5):1568-1578. ]
[11]	穆少杰,李建龙,陈奕兆,等.2001-2010年内蒙古植被覆盖度时空变化特征[J].地理学报,2012,67(9):1255-1268.
	[Mu S J, Li J L, Chen Y Z, et al.Spatial differences of variations of vegetation coverage in Inner Mongolia during 2001-2010[J]. Acta Geographica Sinica, 2012,67(9):1255-1268. ]
[12]	王超,甄霖,杜秉贞,等.黄土高原典型区退耕还林还草工程实施效果实证分析[J].中国生态农业学报,2014,22(7):850-858.
	[Wang C, Zhen L, Du B Z, et al.Assessment of the impact of grain for green project on farmer's livelihood in the Loess Plateau[J]. Chinese Journal of Eco-Agriculture, 2014,22(7):850-858. ]
[13]	汪芳甜,安萍莉,蔡璐佳,等.基于RS与GIS的内蒙古武川县退耕还林生态成效监测[J].农业工程学报,2015,31(11):269-277.
	[Wang F T, An P L, Cai L J, et al.Monitoring effects of ecosystem restructuring project for returning grain plots to forestry in Wuchuan county of Inner Mongolia based on RS and GIS[J]. Transactions of the CSAE,2015,31(11):269-277. ]
[14]	张宝庆,吴普特,赵西宁.近30a黄土高原植被覆盖时空演变监测与分析[J].农业工程学报,2011,27(4):287-293.
	[Zhang B Q, Wu P T, Zhao X N.Detecting and analysis of spatial and temporal variation of vegetation cover in the Loess Plateau during 1982-2009[J]. Transactions of the CSAE, 2011,27(4):287-293. ]
[15]	Dong J W, Liu J Y, Shi W J.China's sloping land conversion program at the beginning of 21st century and its habitat suitability in typical region of Loess Plateau[J]. Journal of Resources and Ecology, 2010,1(1):36-44. doi: 10.3969/j.issn.1674-764x.2010.01.005
[16]	李郎平,鹿化煜.黄土高原25万年以来粉尘堆积与侵蚀的定量估算[J].地理学报,2010,65(1):37-52.
	[Li L P, Lu H Y.A preliminarily quantitative estimation of the sedimentation and erosion rates of loess deposits in Chinese Loess Plateau over the past 250ka[J]. Acta Geographica Sinica, 2010,65(1): 37-52. ]
[17]	魏新民. 隋唐以前黄土高原生态资源环境变迁研究[J].干旱区资源与环境,2010,24(3):109-115.
	[Wei X M.Influence of human activity on Loess Plateau before Sui and Tang Dynasty[J]. Journal of Arid Land Resources and Environment, 2010,24(3):109-115. ]
[18]	田义超,李晶,任志远.近300年来黄土高原耕地变化及时空格局分析[J].干旱区资源与环境,2012,26(2):94-101.
	[Tian Y C, Li J, Ren Z Y.The crop land change and spatial pattern in Loess Plateau over past 300 years[J]. Journal of Arid Land Resources and Environment, 2012,26(2):94-101. ]
[19]	曹雪,金晓斌,王金朔,等.近300年中国耕地数据集重建与耕地变化分析[J].地理学报,2014,69(7):896-906. doi: 10.11821/dlxb201407002
	[Cao X, Jin X B, Wang J S, et al.Reconstruction and change analysis of cropland data of China in recent 300 years[J]. Acta Geographica Sinica, 2014,69(7):896-906. ] doi: 10.11821/dlxb201407002
[20]	Fu B J, Meng Q H, Qiu Y, et al.Effects of land use on soil erosion and nitrogen loss in the hilly area of the Loess Plateau, China[J]. Land Degradation & Development, 2004,15(1):87-96. doi: 10.1002/ldr.572
[21]	周书贵,邵全琴,曹巍.近20年黄土高原土地利用/覆被变化特征分析[J].地球信息科学学报,2016,18(2):190-199. doi: 10.3724/SP.J.1047.2016.00190
	[Zhou S G, Shao Q Q, Cao W.Characteristics of land use and land cover change in the Loess Plateau over the past 20 years[J]. Journal of Geo-information Science, 2016,18(2):190-199. ] doi: 10.3724/SP.J.1047.2016.00190
[22]	孙东琪,张京祥,朱传耿,等.中国生态环境质量变化态势及其空间分异分析[J].地理学报,2012,67(12):1599-1610. doi: 10.11821/xb201212002
	[Sun D Q, Zhang J X, Zhu C G, et al.An assessment of China's ecological environment quality change and its spatial variation[J]. Acta Geographica Sinica, 2012,67(12):1599-1610. ] doi: 10.11821/xb201212002
[23]	李粉玲,常庆瑞,申健,等.黄土高原沟壑区生态环境状况遥感动态监测——以陕西省富县为例[J].应用生态学报,2015,26(12):3811-3817.
	[Li F L, Chang Q R, Shen J, et al.Dynamic monitoring of ecological environment in loess hilly and gully region of Loess Plateau based on remote sensing: A case study on Fuxian County in Shaanxi Province, Northwest China[J]. Chinese Journal of Applied Ecology, 2015,26(12):3811-3817. ]
[24]	孙文义,邵全琴,刘纪远.黄土高原不同生态系统水土保持服务功能评价[J].自然资源学报,2014,29(3):365-376. doi: 10.11849/zrzyxb.2014.03.001
	[Sun W Y, Shao Q Q, Liu J Y.Assessment of soil conservation function of the ecosystem services on the Loess Plateau[J]. Journal of Natural Resources, 2014,29(3):365-376.] doi: 10.11849/zrzyxb.2014.03.001
[25]	李慧,周维博,庄妍,等.延安市农业水土资源匹配及承载力[J].农业工程学报,2016.32(5):156-162.
	[Li H, Zhou W B, Zhuang Y, et al.Agricultural water and soil resources matching patterns and carrying capacity in Yan'an City[J]. Transactions of the CSAE, 2016,32(5):156-162. ]
[26]	杜国明,孙晓兵,刘彦随.延安市退耕对生态的影响及其人文驱动因素分析[J].水土保持研究,2016,23(3):233-239.
	[Du G M, Sun X B, Liu Y S.Analysis of ecological restoration on ecosystem service and its human driving factors in Yan'an city[J]. Research of Soil and Water Conservation, 2016,23(3):233-239. ]
[27]	韩会然,杨成凤,宋金平.北京市土地利用变化特征及驱动机制[J].经济地理,2015,35(5):148-154. doi: 10.15957/j.cnki.jjdl.2015.05.022
	[Han H R, Yang C F, Song J P.The spatial-Temporal characteristic of land use changein Beijing and its driving mechanism[J].Economic Geography, 2015,35(5):148-154. ] doi: 10.15957/j.cnki.jjdl.2015.05.022
[28]	杨俊,王占岐,谢方俊,等.湖北省土地整治项目投资的时空分异及地域分区研究[J].中国土地科学,2015,29(2):74-81. doi: 10.13708/j.cnki.cn11-2640.2015.02.010
	[Yang J, Wang Z Q, Xie F J, et al.Spatio-temporal differentiation and zone division of land consolidation investment: A case study of Hubei Province[J]. China Land Science, 2015,29(2):74-81. ] doi: 10.13708/j.cnki.cn11-2640.2015.02.010
[29]	刘黎明,林培.黄土高原持续土地利用研究[J].资源科学,1998,20(1):54-61.
	[Liu L M, Lin P.Research on sustainable land use system in the Loess Plateau region[J]. Resources Science, 1998,20(1):54-61. ]
[30]	朱会利,杨改河,韩磊.延安市退耕过程植被覆盖度变化及其影响因子分析[J].农业机械学报,2015,46(8):272-280. doi: 10.6041/j.issn.1000-1298.2015.08.038
	[Zhu H L, Yang G H, Han L.Analysis of fractional vegetation coverage changes and Its influencefactors during farmland returned to forest period in Yan'an City[J].Transactions of The Chinese Society of Agricultural machinery, 2015,46(8):272-280. ] doi: 10.6041/j.issn.1000-1298.2015.08.038

地形要素	分级标准	级别	面积/km²	比例/%
高程/m	362~925	I	2581.96	7.00
	925~1115	II	8003.76	21.69
	1115~1275	III	9845.04	26.68
	1275~1442	IV	9564.36	25.92
	1442~1795	V	6907.07	18.72
坡度/°	≤2	1	1272.43	3.45
	2~6	2	4184.40	11.34
	6~15	3	14 443.46	39.14
	15~25	4	13 046.39	35.35
	>25	5	3955.50	10.72
