环长株潭城市群湿地生态安全研究

doi:10.3724/SP.J.1047.2016.01217

摘要/Abstract

摘要：

本文选取环长株潭城市群为研究区域,以Landsat TM影像解译后的土地利用数据、MODIS影像计算的植被指数,以及人口、经济和气候数据等为数据源,基于“压力-状态-响应”框架模型构建湿地生态安全评价指标体系对该区域2000-2010年湿地生态安全进行综合评价。结果表明：（1）环长株潭城市群2000、2005、2010年湿地生态安全指数均值分别为0.7268、0.7151和0.7196,湿地生态安全状态“良好”,生态安全等级程度为“较安全”。（2）环长株潭城市群区域差异性明显,一级湿地生态安全区主要分布在洞庭湖周边,二级湿地生态安全区沿主要河流分布,三级湿地生态安全区主要分布在2个或3个城市之间的交界区域。（3)研究期间环长株潭城市群湿地面积变化明显,该区域湿地总面积逐年减少;森林沼泽、草本沼泽、湖泊、河流、水田的斑块分维数均呈增加趋势;水库/坑塘、河流破碎度指数明显高于其他景观类型,湿地生态系统服务价值总体减少。在此基础上,从土地利用变化与转型、湿地景观结构与功能、自然因素等方面对影响该区域湿地生态安全的主要驱动因子进行了分析。结果表明,人类社会经济活动直接作用于湿地生态环境,通过改变区域景观和土地利用结构使湿地面积发生变化,直接影响湿地生态安全。气温、降水等气候因素通过改变水热状况和植被覆盖,间接影响湿地生态安全。针对该区域湿地生态安全存在的问题,建议在发展过程中正确处理好经济与生态环境之间的关系,尽可能减少人类活动对湿地生态环境的干扰。

关键词: 湿地, 生态安全, 环长株潭城市群, PSR模型

Abstract:

This paper takes Chang-Zhu-Tan Urban Agglomeration as study area. Based on the vegetation index and land use data interpreted from Landsat TM images and combined with the population, economic and climate data, a framework model was established. The results show that: (1) the mean values of wetland ecological security index in 2000, 2005 and 2010 for Chang-Zhu-Tan Urban Agglomeration were 0.7268, 0.7151 and 0.7196, respectively. The status of regional wetland ecological security was good, and the ecological security degree was relatively safe. In the recent decade, the overall performance of the regional ecological security index had decreased, and the decrease of the corresponding area was 21577 km², which accounted for 22.28% of the total land area; (2) in this study area, there is obvious difference of regional ecological security, that the first-class wetland ecological safety area mainly distributed in the surrounding regions of Dongting Lake, the second-class ecological safety region distributed along the major rivers, the third-class ecological safety area mainly distributed in the border area of two or three cities, and the fourth-class wetland ecological safety area mainly distributed in Yueyang city, Xiangtan city, Changsha city and Hengyang city. (3) During the study period, the area of wetland in Chang-Zhu-Tan Urban Agglomeration has changed obviously, that the total area of wetland has decreased year after year. The fractal dimension of forest swamp, herbaceous swamp, lake, river and paddy field showed an increasing trend. The fragmentation index of ponds/rivers was significantly higher than that of other types of landscape, and the value of wetland ecosystem services was decreasing in general. Finally, the main factors affecting the ecological security of wetland were analyzed from the aspects of land use change and transition, and wetland landscape structure and function.

Key words: wetland, ecological security, Chang-Zhu-Tan urban agglomeration, pressure- state-response model

廖柳文, 秦建新. 环长株潭城市群湿地生态安全研究[J]. 地球信息科学学报, 2016, 18(9): 1217-1226.DOI:10.3724/SP.J.1047.2016.01217

LIAO Liuwen,QIN Jianxin. Ecological Security of Wetland in Chang-Zhu-Tan Urban Agglomeration[J]. Journal of Geo-information Science, 2016, 18(9): 1217-1226.DOI:10.3724/SP.J.1047.2016.01217

图/表 8

表1

表2

表3

图1

图2

表4

表5

表6

参考文献 31

[1]	刘艳艳,吴大放,王朝晖.湿地生态安全评价研究进展[J].地理与地理信息科学,2011,27(1):69-75.
	[ Liu Y Y, Wu D F, Wang Z H.Research review on ecological security assessment of wetland[J]. Geography and Geo-Information Science, 2011,27(1):69-75. ]
[2]	Ehrenfeld J G.Evaluating wetlands within an urban context[J]. Ecological Engineering, 2000,15(3-4):253-265. doi: 10.1023/A:1009543920370
[3]	朱卫红,苗承玉,郑小军,等.基于3S技术的图们江流域湿地生态安全评价与预警研究[J].生态学报,2014,34(6):1379-1390. doi: 10.5846/stxb201211241666
	[ Zhu W H, Miao C Y, Zheng X J, et al.Study on ecological safety evaluation and warming of wetlands in Tumen River watershed based on 3S technology[J]. Acta Ecologica Sinica, 2014,34(6):1379-1390. ] doi: 10.5846/stxb201211241666
[4]	朱卫红,郭艳丽,孙鹏,等.图们江下游湿地生态系统健康评价[J].生态学报,2012,32(21):6609-6618. doi: 10.5846/stxb201109191373
	[ Zhu W H, Guo Y L, Sun P, et al.Wetland ecosystem health assessment of the Tumen River downstream[J]. Acta Ecologica Sinica, 2012,32(21):6609-6618. ] doi: 10.5846/stxb201109191373
[5]	恭映壁,李春华,胡曰利. 50年来长沙市湿地时空变化及空间自相关分析[J].中国农学通报,2012,28(14):269-274. doi: 10.3969/j.issn.1000-6850.2012.14.053
	[ Gong Y B, Li C H, Hu Y L.Spatial-temporal changes and spatial autocorrelation analysis of wetland in Changsha city in recent 50 years[J]. Chinese Agricultural Science Bulletin, 2012,28(14):269-274. ] doi: 10.3969/j.issn.1000-6850.2012.14.053
[6]	Holland C C, Honea J E, Gwin S E, et al.Wetland degradation and loss in the rapidly urbanizing area of Portland, Oregon[J]. Wetland, 1995,15(4):336-345.
[7]	Bates B, Kundzewicz Z W, Wu S, et al.Climate change and water technical paper of the intergovernmental panel on climate change[M]. Geneva, IPCC, 2008.
[8]	Dimitriou E, Zacharias I.Climatic and anthropogenic impacts on the hydroecological regime of a large freshwater body[J]. Geophysical Research Abstracts, 2005,7:822-826.
[9]	王文杰,张哲,王维,等.流域生态健康评价框架及其评价方法体系研究(一)——框架和指标体系[J].环境工程技术学报,2012,2(4):271-277. doi: 10.3969/j.issn.1674-991X.2012.04.042
	[ Wang W J, Zhang Z, Wang W, et al.Framework and method system of watershed ecosystem health assessment (I): framework and indicator system[J]. Journal of Environmental Engineering Technology, 2012,2(4):271-277. ] doi: 10.3969/j.issn.1674-991X.2012.04.042
[10]	龙花楼,刘永强,李婷婷,等.生态用地分类初步研究[J].生态环境学报,2015,24(1):1-7. doi: 10.16258/j.cnki.1674-5906.2015.01.001
	[ Long H L, Liu Y Q, LI T T, et al.A primary study on ecological land use classification[J]. Ecology and Environmental Sciences, 2015,24(1):1-7. ] doi: 10.16258/j.cnki.1674-5906.2015.01.001
[11]	苗李莉,蒋卫国,侯鹏.基于遥感和GIS的城市湿地资源综合分析——以北京市为例[J].西安建筑科技大学学报(自然科学版),2013,45(1):130-135. doi: 10.3969/j.issn.1006-7930.2013.01.021
	[ Miao L L, Jiang W G, Hou P.Comprehensive analysis of urban wetland resources based on remote sensing and GIS—a case study of Beijing City[J]. Journal of Xi’an University of Architecture & Technology (Natural Science Edition), 2013,45(1):130-135. ] doi: 10.3969/j.issn.1006-7930.2013.01.021
[12]	李静,王秀珍,黄敬峰. 1978-2010年杭州城市湿地动态变化定量研究[J].科技通报,2013,29(3):201-207. doi: 10.3969/j.issn.1001-7119.2013.03.043
	[ Li J, Wang X Z, Huang J F.Quantitative study on dynamic change of Hangzhou urban wetland during 1978-2010[J]. Bulletin of Science and Technology, 2013,29(3):201-207. ] doi: 10.3969/j.issn.1001-7119.2013.03.043
[13]	郝敬锋,刘红玉,胡和兵,等.城市化背景下区域湿地生态安全多尺度综合评价[J].南京师大学报(自然科学版),2011,34(1):119-124. doi: 10.3969/j.issn.1001-4616.2011.01.024
	[ Hao J F, Liu H Y, Hu H B, et al.Assessment of urban wetland ecological security at differing scales[J]. Journal of Nanjing Normal University (Natural Science Edition), 2011,34(1):119-124. ] doi: 10.3969/j.issn.1001-4616.2011.01.024
[14]	王荣军,谢余初,张影,等.基于PSR模型的旱区城市湿地生态安全评估[J].生态科学,2015,34(3):133-138.
	[ Wang R J, Xie Y C, Zhang Y, et al.Ecological security evaluation of urban wetland in arid China based on PSR model[J]. Ecological Science, 2015,34(3):133-138. ]
[15]	江东,杨小唤,王乃斌,等.基于RS、GIS的人口空间分布研究[J].地球科学进展,2002,17(5):734-738.
	[ Jiang D, Yang X H, Wang N B, et al.Study on spatial distribution of population based on remote sensing and GIS[J]. Advance in Earth Sciences, 2002,17(5):734-738. ]
[16]	刘红辉,江东,杨小唤,等.基于遥感的全国GDP 1km格网的空间化表达[J].地球信息科学,2005,7(2):120-123. doi: 10.3969/j.issn.1560-8999.2005.02.025
	[ Liu H H, Jiang D, Yang X H, et al.Spatialization approach to 1km grid GDP supported by remote sensing[J]. Geo-information Science, 2005,7(2):120-123. ] doi: 10.3969/j.issn.1560-8999.2005.02.025
[17]	孟猛,倪健,张治国.地理生态学的干燥度指数及其应用评述[J].植物生态学报,2004,28(6):853-861.
	[ Meng M, Ni J, Zhang Z G.Aridity index and its applications in geo-ecological study[J]. Acta Phytoecologica Sinica, 2004,28(6):853-861. ]
[18]	Costanza R, D'Arge R, Groot R D, et al. The value of the world's ecosystem services and natural capital[J]. Nature, 1997,387(15):253-260.
[19]	Groot R D, Brander L, Ploeg S V D, et al. Global estimates of the value of ecosystems and their services in monetary units[J]. Ecosystem Services, 2012,1(1):50-61. doi: 10.1016/j.ecoser.2012.07.005
[20]	高吉喜. 可持续发展理论探索——生态承载力的理论、方法与应用[M].北京:中国环境科学出版社,2001.
	[ Gao J X.Exploration on the theory of sustainable development—theoretical method and application of ecological carrying capacity[M]. Beijing: China Environmental Science Press, 2001. ]
[21]	杜培军,陈宇,谭琨.湿地景观格局与生态安全遥感监测分析——以江苏滨海湿地为例[J].国土资源遥感,2014,26(1):158-166. [ Du P J, Chen Y, Tan K. Monitoring and analyzing wetland landscape pattern change and ecological security using remote sensing images: a case study of Jiangsu coastal wetland[J]. Remote Sensing for Land and Resources, 2014,26(1):158-166. ] doi: 10.6046/gtzyyg.2014.01.27
[22]	葛京凤,梁彦庆,冯忠江,等.山区生态安全评价、预警与调控研究—以河北山区为例[M].北京:科学出版社,2011.
	[Ge J F, Liang Y Q, Feng Z J, et al.Research on ecological security assessment alarming and controls in mountains—a case of Hebei mountain area[M]. Beijing: Science Press, 2011. ]
[23]	龙花楼,李秀彬.区域土地利用转型分析:以长江沿线样带为例[J].自然资源学报,2002,17(2): 144-149. doi: 10.11849/zrzyxb.2002.02.003
	[ Long H L, Li X B.Analysis on regional land use transition: a case study in transect of the Yangtze River[J]. Journal of Natural Resources, 2002,17(2):144-149. ] doi: 10.11849/zrzyxb.2002.02.003
[24]	孟伟庆,李洪远,郝翠,等.近30年天津滨海新区湿地景观格局遥感监测分析[J].地球信息科学学报,2010,12(3):436-443.
	[ Meng W Q, Li H Y, Hao C, et al.Changes in wetland landscape pattern and its driving forces of Binhai new area of Tianjin city in the past three decades[J]. Journal of Geo-information Science, 2010,12(3):436-443. ]
[25]	陈云浩,蒋卫国,赵文吉,等.基于多源信息的北京城市湿地价值评价与功能分区[M].北京:科学出版社,2012.
	[ Chen Y H, Jiang W G, Zhao W J, et al.Value assessment and functional partition of Beijing urban wetland based on the multi-source information[M]. Beijing: Science Press, 2012. ]
[26]	董李勤,章光新.全球气候变化对湿地生态水文的影响研究综述[J].水科学进展,2011,22(3):429-436.
	[ Dong L Q, Zhang G X.Review of the impacts of climate change on wetland ecohydrology[J]. Advance in Water Science, 2011,22(3):429-436. ]
[27]	宋长春. 湿地生态系统对气候变化的响应[J].湿地科学,2003,1(2):122-127.
	[ Song C C.Influence of global climate change on wetlands[J]. Wetland Science, 2003,1(2):122-127. ]
[28]	Huxman T E, Smith M D, Fay P A, et al.Convergence across biomes to a common rain-use efficiency[J]. Nature, 2004,429(6992):651-654.
[29]	Knapp A K, Smith M D.Variation among biomes in temporal dynamics of aboveground primary production[J]. Science, 2001,291(5503):481-484.
[30]	Jiang W G, Wang W J, Cheng Y H, et al.Quantifying driving forces of urban wetlands change in Beijing City[J]. Journal of Geographical Sciences, 2012,22(2):301-314. doi: 10.1007/s11442-012-0928-z
[31]	苗李莉,蒋卫国,万圆,等.基于加权Voronoi图的北京市湿地功能分区研究[J].地球信息科学学报,2013,15(4):554-559. doi: 10.3724/SP.J.1047.2013.00554
	[ Miao L L, Jiang W G, Wan Y, et al.Beijing urban wetland function zoning based on the weighted voronoi diagram[J]. Journal of Geo-information Science, 2013,15(4):554-559. ] doi: 10.3724/SP.J.1047.2013.00554

目标层A	准则层B	要素层C	指标层D
湿地生态安全综合评价	压力 B₁	人口经济状况 C₁（0.5）	人口密度 D₁₁ (0.0801)
	（0.2402）		国内生产总值 D₁₂ (0.04)
		气候状况 C₂（0.5）	年平均气温 D₂₁（0.048）
			年平均降水 D₂₂（0.048）
			干燥度 D₂₃（0.024）
	状态 B₂	植被状况 C₃（0.3333）	植被净初级生产力 D₃₁ (0.035)
	（0.2098）		归一化植被指数 D₃₂（0.035）
		景观结构 C₄（0.6667）	破碎化指数 D₄₁（0.0278）
			分维数 D₄₂（0.0234）
			景观优势度指数 D₄₃（0.0556）
			斑块数量 D₄₄（0.0331）
	响应 B₃	面积变化 C₅（0.5）	某类湿地斑块面积占湿地斑块总面积比重 D₅₁（0.0917）
	（0.5499）		湿地面积 D₅₂ (0.1833)
		湿地生态系统功能 C₆（0.5）	生态弹性度 D₆₁（0.1375）
			生态系统服务功能 D₆₂（0.1375）

	供水	文化	娱乐	水分调控	食物供应	污染物净化	气候调节	生物多样性
沼泽	630.80	146.16	40.75	2.49	3.90	137.70	36.60	87.60
湖泊/河流	175.71	-	19.09	451.94	3.40	55.20	36.60	-
农田	-	-	-	-	4.48	-	-	-

等级	综合指数范围	生态安全状态	生态安全度
一级	[0.1,0.5)	差	危险
二级	[0.5,0.6)	较差	较危险
三级	[0.6,0.7)	一般	预警
四级	[0.7,0.8)	良好	较安全
五级	[0.8,1.0]	好	安全

年份	森林沼泽	灌丛沼泽	草本沼泽	湖泊	水库/坑塘	河流	水田	湿地总面积
2000	435.45	0.68	1693.83	1716.83	843.62	1425.82	20 562.42	26 678.66
2005	429.81	0.93	1688.63	1719.18	913.74	1422.58	20 273.52	26 448.39
2010	438.64	0.71	1697.60	1730.08	783.91	1456.94	20 213.97	26 321.85

2000年土地利用类型			2010年土地利用类型						总计(2010年）	减少
2000年土地利用类型	森林沼泽	灌丛沼泽	草本沼泽			湖泊	水库/坑塘	河流	水田	非湿地区
森林沼泽	435.25	0.00	0.03	0.00	0.00	0.00	0.01	0.17	435.45	0.20
灌丛沼泽	0.00	0.68	0.00	0.00	0.00	0.00	0.00	0.00	0.68	0.00
草本沼泽	0.00	0.00	1690.18	0.13	0.00	0.31	0.91	2.30	1693.83	3.65
湖泊	0.34	0.00	0.00	1707.76	0.02	0.13	0.66	7.92	1716.83	9.07
水库/坑塘	0.80	0.00	2.09	2.93	764.14	3.09	19.25	51.32	843.62	79.47
河流	0.25	0.00	0.37	0.00	0.24	1423.50	0.43	1.03	1425.82	2.32
水田	1.33	0.03	2.38	10.52	14.18	25.99	20 092.41	415.58	20 562.42	470.02
非湿地区	0.67	0.00	2.55	8.74	5.32	3.93	100.30	70 104.08	70 225.38	121.50
总计(2000年）增加	438.64 3.39	0.71 0.03	1697.60 7.42	1730.08 22.32	783.91 19.77	1456.94 33.44	20 213.97 121.56	70 582.19 478.41
