南宁在建地铁沿线地表沉降监测

doi:10.12082/dqxxkx.2019.190151

地球信息科学学报 ›› 2019, Vol. 21 ›› Issue (9): 1467-1478.doi: 10.12082/dqxxkx.2019.190151

南宁在建地铁沿线地表沉降监测

覃纹³,黄秋燕^1,^2,³,庾露^3,^*(),胡宝清^1,²

^1. 南宁师范大学北部湾环境演变与资源利用重点实验室,南宁 530001
^2. 南宁师范大学广西地表过程与智能模拟重点实验,南宁 530001
^3. 南宁师范大学地理科学与规划学院,南宁 530001

收稿日期:2019-04-03 修回日期:2019-07-01 出版日期:2019-09-25 发布日期:2019-09-24
作者简介:覃纹（1996-）,女,广西钦州人,硕士生,主要从事合成孔径雷达干涉测量、资源环境遥感研究。E-mail: qinw0717@foxmail.com。
基金资助:
国家自然科学基金地区项目(41661090);国家自然科学基金地区项目(41661021);广西自然基金创新团队项目(2016JJF15001);南宁师范大学校级科研启动项目(0819-2017L05)

Surface Subsidence Monitoring during the Construction of Nanning Subways

QIN Wen³,HUANG Qiuyan^1,^2,³,YU Lu^3,^*(),HU Baoqing^1,²

^1. Key Laboratory of Environmental Change and Resource Utilization of Beibu Gulf, Nanning Normal University, Nanning 530001, China
^2. Key Laboratory of Surface Process and Intelligent Simulation, Nanning Normal University, Nanning 530001, China
^3. School of Geographical Science and Planning, Nanning Normal University, Nanning 530001, China

Received:2019-04-03 Revised:2019-07-01 Online:2019-09-25 Published:2019-09-24
Contact: YU Lu
Supported by:
National Natural Science Foundation of China(41661090);National Natural Science Foundation of China(41661021);Guangxi Natural Science Fund Innovation Team Project(2016JJF15001);Nanning Normal University School-level Scientific Research Launch Project(0819-2017L05)

摘要/Abstract

摘要：

南宁作为北部湾经济区的核心城市及中国-东盟博览会的永久举办地,正处于城市地铁修建及工程建设的高峰期。南宁位于复杂地质水文条件的南宁盆地中西部,地铁施工及运行有可能引发地表沉降等潜在风险,但关于南宁地铁修建区的沉降规律系统的认识仍十分有限。利用永久性散射体雷达干涉测量技术（Permanent Scatterers InSAR,PS-InSAR）处理54景Sentinel-1A影像,监测了2017年4月-2018年12月南宁市区地表沉降信息。结果表明,监测期内南宁地表形变速率为-23.8~9.0 mm/a,研究区大部分区域稳定,沉降点分布零星;4个重点沉降区位于蒲庙镇、九曲湾农场、江南地铁站及北湖-万秀村-虎丘一带;重点沉降区形变曲线总体上随时间变化呈现出不均匀下降;沉降成因可能与膨胀土膨胀特性、弃土滑坡、施工作业、列车流量过大及地下水位下降有关。5条地铁沉降值均属于安全范围。研究表明,南宁雨季降水丰富,地铁修建区表土以松散的第四系覆盖层为主,下伏基岩以工程力学性质存在一定不稳定性的第三系膨胀土为主,建议利用PS-InSAR技术对沉降重点区域及地铁沿线开展长期监测。

关键词: 地铁, Sentinel-1A, PS-InSAR, 地表沉降, 第三系膨胀土, 南宁

Abstract:

Nanning is the core city of the Beibu Gulf Economic Zone and the permanent venue of the China-ASEAN Expo, which is undergoing the construction peak of urban subways. Nanning is located in the central and western part of the Nanning Basin, where the geological and hydrological conditions are complicated. The construction and operation of subways may cause potential risks such as surface subsidence. However, it remains understudied regarding the surface subsidence along Nanning subways. In this paper, 54 Sentinel-1A images of Nanning city from April 2017 to December 2018 were processed by Permanent Scatterers Interferometric Synthetic Aperture Radar （PS-InSAR）, and then the surface subsidence information was extracted. Results showed that the surface deformation rate was -23.8~9.0 mm/a during the monitoring period, and most of the study area was stable, and the settlement point distribution was sporadic. There were four key subsidence areas , including Pumiao Town, Jiuquwan Farm, Jiangnan Subway Station, and Beihu- Wanxiu Village- Huqiu. The deformation curve of key settlement areas showed an uneven decline trend with time; the reason causing settlement may be attributed to the expansion characteristics of expansive soil, spoil landslide, construction operation, excessive train flow, and drop in the groundwater level. The sedimentation value of the five subways were all within the safe range. The rainy season precipitation of Nanning is rich, and the topsoil of the subway construction area is mainly composed of loose Quaternary overburden, where the underlying bedrock is mainly composed of Tertiary expansive soil with certain instability of engineering mechanics. Therefore, our findings suggest that the PS-InSAR technology should be used for long-term monitoring of key settlement areas and subways of Nanning for safe metro operation.

Key words: Subway, Sentinel-1A, PS-InSAR, surface subsidence, tertiary expansive soil, nanning

覃纹,黄秋燕,庾露,胡宝清. 南宁在建地铁沿线地表沉降监测[J]. 地球信息科学学报, 2019, 21(9): 1467-1478.DOI:10.12082/dqxxkx.2019.190151

QIN Wen,HUANG Qiuyan,YU Lu,HU Baoqing. Surface Subsidence Monitoring during the Construction of Nanning Subways[J]. Journal of Geo-information Science, 2019, 21(9): 1467-1478.DOI:10.12082/dqxxkx.2019.190151

图/表 10

图1

图2

Tab. 1

表2

图3

图4

图5

图6

图7

图8

参考文献 36

[1]	唐嘉, 刘国祥, 宋云帆 , 等. PALSAR和ASAR PSI显著地表沉降探测与分析[J]. 遥感学报, 2015,19(6):1019-1029.
	[ Tang J, Liu G X, Song Y F , et al. Detection and analysis of significant surface subsidence in PALSAR and ASAR PSI[J]. Journal of Remote Sensing, 2015,19(6):1019-1029. ]
[2]	李广宇, 张瑞, 刘国祥 , 等. Sentinel-1A TS-DInSAR京津冀地区沉降监测与分析[J]. 遥感学报, 2018,22(4):633-646.
	[ Li G Y, Zhang R, Liu G X , et al. Sentinel-1A TS-DInSAR settlement monitoring and analysis in beijing-tianjin-hebei region[J]. Journal of Remote Sensing, 2008,22(4):633-646. ]
[3]	董山, 张永红, 李明巨 , 等. 时序InSAR的连云港及盐城北部地表沉降研究[J]. 测绘科学, 2019,44(3):57-62.
	[ Dong S, Zhang Y H, Li M J , et al. Study on land subsidence in lianyungang and northern yancheng in time series InSAR[J]. Science of Surveying and Mapping, 2019,44(3):57-62. ]
[4]	张倍倍 . 合成孔径雷达干涉测量(InSAR)技术在地表沉降监测中的应用[J]. 西部资源, 2014(5):149-150.
	[ Zhang B B . Application of synthetic aperture radar interferometry (InSAR) technology in surface subsidence monitoring[J]. West Resources, 2014(5):149-150. ]
[5]	范秋雁 . 膨胀岩与工程[M]. 北京: 科学出版社, 2008.
	[ Fan Q Y. Expansive rock and engineering[M]. Beijing: Science Press, 2008. ]
[6]	李韵迪 . 南宁地铁3号线长岗路车站基坑变形特征研究[J]. 工程质量, 2018,36(4):68-73.
	[ Li Y D . Research on deformation characteristics of changgang road station foundation pit of nanning metro line 3[J]. Engineering Quality, 2018,36(4):68-73. ]
[7]	何高峰, 罗先启, 范训益 , 等. 南宁地铁2号线岩溶风险分析和处理原则[J]. 铁道标准设计, 2018,62(5):86-90.
	[ He G F, Luo X Q, Fan X Y , et al. Karst risk analysis and treatment principles for nanning metro line 2[J]. Railway Standard Design, 2018,62(5):86-90. ]
[8]	李金华, 宋涛, 朱海西 , 等. 南宁地铁2号线车站深基坑开挖变形规律研究[J]. 施工技术, 2017(19):37-40.
	[ Li J H, Song T, Zhu H X , et al. Study on deformation law of deep foundation pit excavation in station of nanning metro line 2[J]. Construction Technology, 2017(19):37-40. ]
[9]	陈新年, 郭颖, 贺小俪 , 等. 南宁软岩地层地铁车站深基坑变形规律分析[J]. 施工技术, 2014,40(1):96-99,108.
	[ Chen X B, Guo Y, He X L, , et al. Deformation law analysis of deep foundation pit of subway station in soft rock strata of nanning[J]. Construction Technology, 2014,40(1):96-99,108. ]
[10]	陈成全, 叶凤珍 . 南宁市修建地铁对南宁盆地松散岩类地下水的影响研究[J]. 工程建设与设计, 2017(14):30-31
	[ Chen C Q, Ye F Z . Study on the influence of subway construction in nanning on loose rock groundwater in nanning basin[J]. Engineering Construction and Design, 2017(14):30-31. ]
[11]	姜伏伟, 张发旺, 柳林 , 等. 南宁地铁施工降水诱发岩溶塌陷条件及安全防控措施[J]. 中国岩溶, 2018,37(3):415-420.
	[ Jiang F W, Zhang F W, Liu L , et al. Conditions of karst collapse induced by precipitation in nanning subway construction and safety prevention and control measures[J]. China Karst, 2018,37(3):415-420. ]
[12]	Ferretti A, Prati C, Rocca F . Nolinear subsidence rate estimation using permanent scatterers in differential SAR interferometry[J]. IEEE Transactions on Geosicence and Remote Sensing, 2000,38:2202-2212.
[13]	刘凯斯, 宫辉力, 陈蓓蓓 . 基于InSAR数据的北京地铁6号线地面沉降监测分析[J]. 地球信息科学学报, 2018,20(1):128-137.
	[ Liu K S, Gong H L, Chen B B . Monitoring and analysis of ground subsidence of beijing metro line 6 based on InSAR data[J]. Journal of Earth Information Science, 2018,20(1):128-137. ]
[14]	周玉营, 陈蜜, 宫辉力 , 等. 基于时序InSAR的京津高铁北京段地面沉降监测[J]. 地球信息科学学报, 2017,19(10):1393-1403.
	[ Zhou Y Y, Chen M, Gong H L , et al. Monitoring of ground subsidence in beijing section of beijing-tianjin high-speed railway based on time series InSAR[J]. Journal of Earth Information Science, 2017,19(10):1393-1403. ]
[15]	Yasser M, Freek V D M, Christoph H , et al. Using PS-InSAR to detect surface deformation in geothermal areas of west java in Indonesia[J]. International Journal of Applied Earth Observation and Geoinformation, 2018(64):386-396.
[16]	雷坤超, 贾三满, 陈蓓蓓 , 等. 基于PS-InSAR技术的廊坊市地面沉降监测研究[J]. 遥感技术与应用, 2013(28):1114-1119.
	[ Lei K C, Jia S M, Chen B B , et al. Research on land subsidence monitoring in langfang city based on PS-InSAR technology[J]. Remote Sensing Technology and Application, 2013(28):1114-1119. ]
[17]	郭山川, 侯湖平, 张绍良 , 等. 时序InSAR在城市地铁工程区形变监测中的应用[J]. 测绘通报, 2017(8):92-99.
	[ Guo S C, Hou H P, Zhang S L , et al. Application of time series InSAR in deformation monitoring of urban subway engineering area[J]. Bulletin of Surveying and Mapping, 2017(8):92-99. ]
[18]	罗得把 . 广西南宁盆地工程地质特征浅析[J]. 西部交通科技, 2006(5):72-74.
	[ Luo D Z . Analysis of engineering geological characteristics of nanning basin in guangxi[J]. Western Transportation Science & Technology, 2006(5):72-74. ]
[19]	周洪月, 汪云甲, 闫世勇 , 等. 沧州地区地面沉降现状Sentinel-1A/B时序InSAR监测与分析[J]. 测绘通报, 2017(7):89-93.
	[ Zhou H Y, Wang Y J, Yan S Y , et al. Status of land subsidence in cangzhou area, sentinel-1A /B time series InSAR monitoring and analysis[J]. Bulletin of Surveying and Mapping, 2017(7):89-93. ]
[20]	张艳梅, 王萍, 罗想 , 等. 利用Sentinel-1数据和SBAS-InSAR技术监测西安地表沉降[J]. 测绘通报, 2017(4):93-97.
	[ Zhang Y M, Wang P, Luo X , et al. Surface subsidence monitoring in xi 'an by sentinel-1 data and SBAS-InSAR[J]. Bulletin of Surveying and Mapping, 2017(4):93-97. ]
[21]	陈继伟, 曾琪明, 焦健 , 等. Sentinel-1A卫星TOPS模式数据的SBAS时序分析方法——以黄河三角洲地区为例[J]. 国土资源遥感, 2017,29(4):82-87.
	[ Chen J W, Zeng Q M, Jiao J , et al. SBAS time series analysis method for sentinel-1A satellite TOPS model data: A case study of the Yellow River delta region[J]. Remote Sensing of Land Resources, 2017,29(4):82-87. ]
[22]	Teije V D H, Martine M R, Nick C V D G , et al. Monitoring land subsidence in Yangon, Myanmar using Sentinel-1 persistent scatterer interferometry and assessment of driving mechanisms[J]. Remote Sensing of Environment, 2018,217:101-110.
[23]	邹财麟 . 山上倒垃圾上下瓦房塌后续:非法弃土埋隐患[N]. 南国早报, 2015-6-21(10).
	[ Zou C L . The collapse of the tiled house on the mountain after dumping garbage: illegal dumping and hidden danger[N]. South China Morning Post, 2015-6-21(10). ]
[24]	杨和平, 湛文涛, 肖杰 , 等. 南宁膨胀土作路堤填料的土性试验[J]. 中国公路学报, 2011,24(1):1-7.
	[ Yang H P, Zhan W T, Xiao J , et al. Soil test of expansive soil as embankment filler in nanning[J]. China Highway Journal, 2011,24(1):1-7. ]
[25]	肖杰, 杨和平, 李晗峰 , 等. 低应力条件下不同密度的南宁膨胀土抗剪强度试验[J]. 中国公路学报, 2013,26(6):15-37.
	[ Xiao J, Yang H P, Li H F , et al. Shear strength test of nanning expansive soil with different densities under low stress conditions[J]. China Highway Journal, 2013,26(6):15-37. ]
[26]	唐迎春, 黄钟晖, 张凯 , 等. 南宁第三系浅表层风化泥岩物理力学及膨胀特性指标分析[J]. 工程地质学报, 2014,22(1):144-151.
	[ Tang Y C, Huang Z G, Zhang K , et al. Analysis of physical mechanics and expansion characteristics of tertiary weathered mudstone in nanning[J]. Journal of Engineering Geology, 2014,22(1):144-151. ]
[27]	马少坤, 赵乃峰, 周东 , 等. 南宁膨胀土长期压缩特性研究[J]. 岩土力学, 2013,34(8):2280-2286.
	[ Ma S K, Zhao N F, Zhou D , et al. Study on long-term compression characteristics of expansive soil in nanning[J]. Rock and Soil Mechanics, 2013,34(8):2280-2286. ]
[28]	黎兆齐 . 南宁站南宁东站昨送客15.3万人次[N]. 南宁晚报, 2017-10-1(4).
	[ Li Z Q . Nanning east station saw off 153, 000 passengers yesterday[N]. Nanning Evening News, 2017-10-1(4). ]
[29]	赵鹏, 雷斌 . 轨道交通工程建设风险管理的研究[J]. 地下空间与工程学报, 2012,8(S2):1818-1823.
	[ Zhao P, Lei B . Research on risk management of rail transit engineering construction[J]. Chinese Journal of Underground Space and Engineering, 2012,8(S2):818-1823. ]
[30]	刘琦, 岳国森, 丁孝兵 , 等. 佛山地铁沿线时序InSAR形变时空特征分析[J]. 武汉大学学报(信息科学版), 2019,44(7):1099-1106.
	[ Liu Q, Yue G S, Ding X B , et al. Temporal and spatial characteristics analysis of deformation along foshan subway using time series InSAR[J]. Journal of Wuhan University (Information Science Edition), 2019,44(7):1099-1106. ]
[31]	朱茂, 沈体雁, 黄松 , 等. InSAR技术地铁沿线建筑物形变监测[J]. 国土资源遥感, 2019,31(2):196-203.
	[ Zhu M, Shen T Y, Huang S , et al. Deformation monitoring of buildings along the InSAR technology metro[J]. Remote Sensing of Land and Resources, 2019,31(2):196-203. ]
[32]	Daniele P, Zhi Y W, Hui L . Shanghai subway tunnels and highways monitoring through Cosmo-SkyMed Persistent Scatterers[J]. ISPRS Journal of Photogrammetry and Remote Sensing, 2012,73:58-67.
[33]	葛大庆, 张玲, 王艳 , 等. 上海地铁10号线建设与运营过程中地面沉降效应的高分辨率InSAR监测及分析[J]. 上海国土资源, 2014,35(4):62-67.
	[ Ge D Q, Zhang L, Wang Y , et al. High-resolution InSAR monitoring and analysis of land subsidence effects during construction and operation of shanghai metro line 10[J]. Shanghai Land Resources, 2014,35(4):62-67. ]
[34]	秦晓琼, 杨梦诗, 王寒梅 , 等. 高分辨率PS-InSAR在轨道交通形变特征探测中的应用[J]. 测绘学报, 2016,45(6):713-721.
	[ Qin X Q, Yang M S, Wang H M , et al. Application of high resolution PS-InSAR in the detection of deformation characteristics of rail transit[J]. Journal of Surveying and Mapping, 2016,45(6):713-721. ]
[35]	李金华, 宋涛, 朱海西 , 等. 南宁地铁2号线车站深基坑开挖变形规律研究[J]. 施工技术, 2017,46(19):32-35.
	[ Li J H, Song T, Zhu H X , et al. Study on deformation law of deep foundation pit excavation of nanning metro line 2 station[J]. Construction Technology, 2017,46(19):32-35. ]
[36]	李韵迪 . 南宁地铁3号线长堽路车站基坑变形特征研究[J]. 工程质量, 2018,36(4):68-73.
	[ Li Y D . Research on deformation characteristics of foundation pit of changgang road station of nanning subway line 3[J]. Engineering Quality, 2018,36(4):68-73. ]

时间		空间基线/m	时间	时间基线/d	空间基线/m	时间	时间基线/d	空间基线/m
2017-04-03	0	-35.0929	2017-11-05	216	45.2097	2018-06-09	432	-24.6097
2017-04-15	12	-74.4984	2017-11-17	228	41.5198	2018-06-21	444	-1.7339
2017-04-27	24	70.6223	2017-11-29	240	15.9682	2018-07-03	456	73.8204
2017-05-09	36	-75.0670	2017-12-11	252	33.7829	2018-07-15	468	35.5915
2017-05-21	48	-43.8730	2017-12-23	264	82.5005	2018-07-27	480	47.1928
2017-06-02	60	-30.8616	2018-01-04	276	82.5183	2018-08-08	492	20.8403
2017-06-14	72	10.9047	2018-01-16	288	46.8289	2018-08-20	504	-36.5445
2017-06-26	84	20.1468	2018-01-28	300	50.1835	2018-09-01	516	-73.3495
2017-07-08	96	67.6315	2018-02-09	312	-20.2486	2018-09-13	528	29.7106
2017-07-20	108	36.1572	2018-02-21	324	-5.6931	2018-09-25	540	62.7836
2017-08-01	120	-50.6033	2018-03-05	336	0	2018-10-07	552	52.9528
2017-08-13	132	-61.7094	2018-03-17	348	28.3550	2018-10-19	564	-55.9534
2017-08-25	144	13.5000	2018-03-29	360	30.5529	2018-10-31	576	-64.3076
2017-09-06	156	70.6805	2018-04-10	372	8.8881	2018-11-12	588	-17.6692
2017-09-18	168	-20.5977	2018-04-22	384	9.5435	2018-11-24	600	68.2421
2017-09-30	180	-65.7919	2018-05-04	396	37.1262	2018-12-06	612	-4.2850
2017-10-12	192	-82.5454	2018-05-16	408	12.2794	2018-12-18	624	84.5637
2017-10-24	204	-49.4931	2018-05-28	420	-6.0092	2018-12-30	636	-27.8057
