基于供需匹配的养老服务设施规划布局研究

doi:10.12082/dqxxkx.2022.210699

摘要/Abstract

摘要：

人口老龄化是当前社会关注的重点问题之一,养老设施配置得合理与否对城市品质提升和社会公平地实现至关重要。当前对养老设施的研究已不在少数,但多从养老机构或社区养老设施的单一视角进行分析,评价内容集中于设施数量和空间分布的合理性,导致研究结果有所局限。因此,本文基于2018年武汉市社区级老年常住人口数据、2020年武汉市养老设施数据和道路交通等多源大数据,首先将社区养老设施纳入城市养老服务体系,并从养老设施和养老服务两大角度综合评价设施的供需匹配关系,结果表明： ① 区域层面,武汉市养老设施供需均呈现出中心城区集聚,外围分散的“核心-边缘”特征,但仍然存在数量等级体系不合理以及区域配置水平差距大等问题;② 社区层面,运用两步移动搜索法,发现武汉市养老设施供需匹配度：都市发展区>中心城区>外围城区;③ 养老服务上,武汉市医疗保健类和精神慰藉类服务供需匹配关系较差,且设施普遍缺少专业化的服务供给,高品质多样化的养老需求较难得到满足。针对武汉市养老设施和养老服务的供需匹配问题,本文从体系构建、空间布局以及实施管理方面提出了优化建议,同时运用最小设施点数模型将建议落实至空间层面,以期为类似地区养老设施规划提供有效参考。

关键词: 养老设施, 养老服务, 供需匹配, 两步移动搜索法, 最小设施点数模型, 养老设施服务体系, 空间布局, 武汉市

Abstract:

Population aging is one of the key issues concerned by the current society. Whether the allocation of elderly care facilities is reasonable or not is very important for the improvement of urban quality and the realization of social equity. At present, there are quite a few studies on elderly care facilities, but they mostly conduct analyses from a single perspective of elderly care institutions or community elderly care facilities, and the evaluation content is also limited to the rationality of the number and spatial distribution of facilities, resulting in one-sided research results. This paper utilizes multiple data sources including the data of community-level elderly permanent residents in Wuhan in 2018, the data of elderly care facilities in Wuhan in 2020, road traffic, and other big data. We first integrates community elderly care facilities into the urban elderly care service system, and then comprehensively evaluates the relationship between supply and demand of facilities from the perspectives of elderly care facilities and elderly care services. The results show that: (1) At the regional level, the elderly care facilities in Wuhan show the characteristics of "core edge" of agglomeration in the central urban area and dispersion in the periphery. There are still some problems in the supply level, such as unreasonable quantity hierarchy and large gap in regional allocation level; (2) At the community level, using the two-step mobile search method, this paper finds the matching degree of supply and demand of elderly care facilities in Wuhan: Urban Development Area > Central Urban Area > far urban area; (3) In terms of elderly care services, the supply-demand relationship between medical care and spiritual comfort services in Wuhan is poor, and the facilities generally lack professional service supply, so it is difficult to meet the high-quality and diversified elderly care needs. In view of the existing problems of the matching degree between the supply and demand of old-age facilities and the elderly population, this paper puts forward optimization suggestions from the aspects of system construction, spatial layout, and implementation management, and uses the minimum facility point model to implement the suggestions to the spatial level in order to provide effective reference for the planning of elderly care facilities in similar areas.

Key words: elderly care facilities, pension services, supply and demand matching, two step moving search method, minimum facility point model, elderly care facilities service system, spatial layout, Wuhan

彭建东, 邢露, 杨红. 基于供需匹配的养老服务设施规划布局研究[J]. 地球信息科学学报, 2022, 24(7): 1349-1362.DOI:10.12082/dqxxkx.2022.210699

PENG Jiandong, XING Lu, YANG Hong. Research on Planning and Layout of Elderly Care Service Facilities based on Supply-Demand Matching[J]. Journal of Geo-information Science, 2022, 24(7): 1349-1362.DOI:10.12082/dqxxkx.2022.210699

图/表 17

图1

表1

表2

图2

图3

图4

图5

图6

表3

图7

图8

表4

表5

表6

图9

表7

图10

参考文献 36

[1]	中华人民共和国中央人民政府. 第七次全国人口普查主要数据情况[EB/OL]. http://www.gov.cn/xinwen/2021-05/11/content_5605760.
	[ The Central People's Government of the People's Republic of China. Main data of the Seventh National Census[EB/OL]. http://www.gov.cn/xinwen/2021-05/11/content_5605760. ]
[2]	孙碧竹. 我国社会养老服务体系发展研究[D]. 长春: 吉林大学, 2019.
	[ Sun B Z. A study of the development of social service system for elderly in China[D]. Changchun: Jilin University, 2019. ]
[3]	胡刚钰, 黄建中, 牛强. 老龄化背景下社区服务设施相关研究综述与启示[J]. 城市发展研究, 2016, 23(2):78-83.
	[ Hu G Y, Huang J Z, Niu Q. Review and revelation of the community service facilities research under the background of aging[J]. Urban Development Studies, 2016, 23(2):78-83. ]DOI: 10.3969/j.issn.1006-3862.2016.02.012 doi: 10.3969/j.issn.1006-3862.2016.02.012
[4]	程杨, 戴特奇, 陶卓霖, 等. 基于公平最大化目标的2020年北京市养老设施布局优化[J]. 地理科学进展, 2015, 34(12):1609-1616. doi: 10.18306/dlkxjz.2015.12.009
	[ Cheng Y, Dai T Q, Tao Z L, et al. Spatial optimization of residential care facility locations in 2020 in Beijing: Maximum equity in accessibility[J]. Urban Development Studies, 2015, 34(12):1609-1616. ]DOI: 10.18306/dlkxjz.2015.12.009 doi: 10.18306/dlkxjz.2015.12.009
[5]	Greenberg J N, Ginn A. A multivariate analysis of the predictors of long-term care placement[J]. Home Health Care Services Quarterly, 1979, 1(1):75-99. DOI: 10.1300/J027v01n01_04 doi: 10.1300/J027v01n01_04 pmid: 10309056
[6]	Kraus A S, Spasoff R A, Beattie E J, et al. Elderly applicants to long-term care institutions. L their characteristics, health problems and state of mind[J]. Journal of the American Geriatrics Society, 1976, 24(3):117-125. DOI: 10.1111/j.1532-5415.1976.tb04282.x doi: 10.1111/j.1532-5415.1976.tb04282.x pmid: 814154
[7]	Jennifer M, Kinney. Home Care and Caregiving[M]. San Diego: Academic Press, 1998.
[8]	Morgan L A, Kunkel S. Aging: the social context[M]. Thousand Oaks, Calif: Pine Forge Press, 1998
[9]	胡舒云, 陆玉麒, 胡国建, 等. 基于多源大数据的深圳市医疗设施可达性与公平性测算[J]. 经济地理, 2021, 41(11):87-96.
	[ Lu Y Q, Hu G J, et al. Measuring accessibility and equity of medical resources in Shenzhen based on multi-source big data[J]. Economic Geography, 2021, 41(11):87-96. ] DOI: 10.15957/j.cnki.jjdl.2021.11.010 doi: 10.15957/j.cnki.jjdl.2021.11.010
[10]	魏冶, 修春亮, 高瑞, 等. 基于高斯两步移动搜索法的沈阳市绿地可达性评价[J]. 地理科学进展, 2014, 33(4):479-487. doi: 10.11820/dlkxjz.2014.04.005
	[ Xiu C L, Gao R, et al. Evaluation of green space accessibility of Shenyang using Gaussian based 2-step floating catchment area method[J]. Progress in Geography, 2014, 33(4):479-487. ] DOI: 10.11820/dlkxjz.2014.04.005 doi: 10.11820/dlkxjz.2014.04.005
[11]	易铮, 冯沥娇, 董芊里, 等. 基于可达性分析的公园绿地布局优化——以许昌市建成区为例[J]. 现代城市研究, 2020, 35(11):53-60.
	[ Yi Z, Feng L J, Dong Q L, et al. Research on accessibility analysis and layout optimization of park green space based on ArcGIS technology: A case study of Xuchang[J]. Modern Urban Research, 2020, 35(11): 53-60.] DOI: 10.3969/j.issn.1009-6000.2020.11.008 doi: 10.3969/j.issn.1009-6000.2020.11.008
[12]	许昕, 赵媛. 南京市养老服务设施空间分布格局及可达性评价——基于时间成本的两步移动搜索法[J]. 现代城市研究, 2017, 32(2):1-11.
	[ Xu X, Zhao Y. Spatial distribution pattern and accessibility assessment of pension service facilities in Nanjing: Two-step floating catchment area method based on time cost[J]. Modern Urban Research, 2017, 32(2):1-11. ] DOI: 10.3969/j.issn.1009-6000.2017.02.001 doi: 10.3969/j.issn.1009-6000.2017.02.001
[13]	傅俐, 王勇, 曾彪, 等. 基于改进两步移动搜索法的北碚区医疗设施空间可达性分析[J]. 地球信息科学学报, 2019, 21(10):1565-1575. doi: 10.12082/dqxxkx.2019.190188
	[ Fu L, Wang Y, Zeng B, et al. Spatial accessibility of medical facilities in Beibei District based on modified two-step floating catchment area method[J]. Journal of Geo-Information Science, 2019, 21(10):1565-1575. ]
[14]	杨慧, 杨乃, 孔凡敏, 等. 基于改进型两步移动搜索法的县域义务教育资源空间可达性评价——以湖北省监利县为例[J]. 复旦学报(自然科学版), 2021, 60(5):618-625.
	[ Yang H, Yang N, Kong F M, et al. Spatial accessibilities evaluation of compulsory education at County level based on improved two-step floating catchment area method—Taking Jianli County of Hubei Province as an example[J]. Journal of Fudan University (Natural Science), 2021, 60(5):618-625. ]DOI: 10.15943/j.cnki.fdxb-jns.2021.05.005 doi: 10.15943/j.cnki.fdxb-jns.2021.05.005
[15]	Radke J, Mu L. Spatial decompositions, modeling and mapping service regions to predict access to social programs[J]. Geographic Information Sciences, 2000, 6(2):105-112. DOI: 10.1080/10824000009480538 doi: 10.1080/10824000009480538
[16]	王琼. 城市社区居家养老服务需求及其影响因素——基于全国性的城市老年人口调查数据[J]. 人口研究, 2016, 40(1):98-112.
	[ Wang Q. Demands and determinants of community home-based care services for urban elderly: Based on the 2010 national elderly survey in China[J]. Population Research, 2016, 40(1):98-112. ]
[17]	易文飞, 俞永增, 张艺伟, 等. 基于p-中位模型的区域综合能源系统能源站优化规划[J]. 电力系统自动化, 2019, 43(4):107-112.
	[ Yi W F, Yu Y Z, Zhang Y W, et al. P-Median model based optimal planning of energy station for regional integrated energy systems[J]. Automation of Electric Power Systems, 2019, 43(4):107-112. ] DOI: 10.7500/AEPS20180228002 doi: 10.7500/AEPS20180228002
[18]	陈志芬, 李俊伟, 卢方欣, 等. 城市消防站选址布局优化及对雄安新区的启示[J]. 中国安全生产科学技术, 2018, 14(9):12-17.
	[ Chen Z F, Li J W, Lu F X, et al. Optimizing location of fire stations and it's enlightenments for Xiongan New Area[J]. Journal of Safety Science and Technology, 2018, 14(9):12-17. ] DOI: 10.11731/j.issn.1673-193x.2018.09.002 doi: 10.11731/j.issn.1673-193x.2018.09.002
[19]	詹庆明, 杨爽. 村镇应急公共设施选址布局优化研究[J]. 地球信息科学学报, 2019, 21(5):641-653. doi: 10.12082/dqxxkx.2019.180487
	[ Zhan Q M, Yang S. Optimization of emergency facilities layout in villages[J]. Journal of Geo-information Science, 2019, 21(5):641-653. ] DOI: 10.12082/dqxxkx.2019.180487 doi: 10.12082/dqxxkx.2019.180487
[20]	陶卓霖, 程杨, 戴特奇, 等. 公共服务设施布局优化模型研究进展与展望[J]. 城市规划, 2019, 43(8):60-68,88.
	[ Tao Z L, Cheng Y, Dai T Q, et al. Research progress and prospect of public service facilities layout optimization models[J]. City Planning Review, 2019, 43(8):60-68,88. ] DOI: 10.11819/cpr20190809a doi: 10.11819/cpr20190809a
[21]	张喆. 基于连续需求的区域最大覆盖设施选址问题的研究[D]. 北京: 北京交通大学, 2019.
	[ Zhang Z. Research on regional maximal covering facility location problem based on continuous demand[D]. Beijing: Beijing Jiaotong University, 2019. ]
[22]	彭永明, 王铮. 农村中小学选址的空间运筹[J]. 地理学报, 2013, 68(10):1411-1417. doi: 10.11821/dlxb201310010
	[ Peng Y M, Wang Z. Space operation of rural primary and secondary school location[J]. Acta Geographica Sinica, 2013, 68(10):1411-1417. ] DOI: 10.11821/dlxb201310010 doi: 10.11821/dlxb201310010
[23]	武汉市规划研究院. 武汉市城市总体规划(2017-2035年)[EB/OL]. https:\\www.jjw.com\news\2428.html.
	[ Wuhan Planning Research Institute. Wuhan urban master plan (2017-2035)[EB/OL]. https:\\www.jjw.com\news\2428.html. ]
[24]	武汉市统计局. 武汉统计年鉴[M]. 武汉: 中国统计出版社, 2020.
	[ Wuhan Bureau of Statistics. Wuhan Statistical Yearbook[M]. Wuhan: China Statistics Press, 2020. ]
[25]	武汉市人民政府. 市人民政府关于提升养老服务供给水平加快养老服务业的实施意见[EB/OL]. http://www.wuhan.gov.cn/zwgk/xxgk/zfwj/gfxwj/202003/t20200316_973322.shtml.
	[ Wuhan Municipal People's Government. Opinions of the Municipal People's Government on improving the supply level of elderly care services and accelerating the implementation of elderly care service industry[EB/OL]. http://www.wuhan.gov.cn/zwgk/xxgk/zfwj/gfxwj/202003/t20200316_973322.shtml. ]
[26]	中华人民共和国住房和城乡建设部. 养老服务设施建筑设计规范[S]. 2013.
	[ Ministry of Housing and Urban Rural Development of the People's Republic of China. Code for architectural design of elderly care service facilities[S]. 2013. ]
[27]	武汉市人民政府. 市人民政府关于印发武汉市推进“互联网+居家养老”新模式实施方案的通知[EB/OL]. http://www.wuhan.gov.cn/zwgk/xxgk/zfwj/wjql/202003/t20200316_973356.shtml.
	[ Wuhan Municipal People's Government. Notice of the Municipal People's Government on Issuing the implementation plan of Wuhan's new mode of promoting Internet plus home care[EB/OL]. http://www.wuhan.gov.cn/zwgk/xxgk/zfwj/wjql/202003/t20200316_973356.shtml. ]
[28]	武汉市民政局. 2020年中心城区实现半径1公里内提供社区居家养老服务老人在家中即可享受专业照料[EB/OL]. http://mzj.wuhan.gov.cn/mzdt_912/mtxw_915/201801/t20180119_162574.shtml.
	[ Wuhan Civil Affairs Bureau. In 2020, the central urban area will provide community home-based elderly care services within a radius of 1 km, and the elderly can enjoy professional care at home[EB/OL] http://mzj.wuhan.gov.cn/mzdt_912/mtxw_915/201801/t20180119_162574.shtml. ]
[29]	王法辉, 戴特奇. 公共资源公平配置的规划方法与实践[J]. 城市与区域规划研究, 2020(2):28-40.
	[ Wang F H, Dai T Q. Spatial optimization and planning practice towards equal access of public services[J]. Journal of Urban Regional Planning, 2020(2):28-40. ]
[30]	李小云. 面向原居安老的城市老年友好社区规划策略研究[D]. 广州: 华南理工大学, 2012.
	[ Li X Y. Research on planning strategy of city aging friendly community based on aging in place[D]. Guangzhou: South China University of Technology, 2012. ]
[31]	黄建中, 吴萌. 特大城市老年人出行特征及相关因素分析——以上海市中心城为例[J]. 城市规划学刊, 2015(2):93-101.
	[ Huang J Z, Wu M. An investigation and analysis of travel characteristics and related factors of the elderly population in megacities: The case of the central area in Shanghai[J]. Urban Planning Forum, 2015(2):93-101. ] DOI: 10.16361/j.upf.201502012 doi: 10.16361/j.upf.201502012
[32]	冯建喜, 杨振山. 南京市城市老年人出行行为的影响因素[J]. 地理科学进展, 2015, 34(12):1598-1608. doi: 10.18306/dlkxjz.2015.12.008
	[ Feng J X, Yang Z S. Factors influencing travel behavior of urban elderly people in Nanjing[J]. Progress in Geography, 2015, 34(12):1598-1608. ] DOI: 10.18306/dlkxjz.2015.12.008 doi: 10.18306/dlkxjz.2015.12.008
[33]	王天鑫. 基于医养结合的我国养老服务供求研究[D]. 长春: 东北师范大学, 2018.
	[ Wang T X. The study of the elderly services supply and demand in China upon the perspective of medical and pension combined[D]. Changchun: Northeast Normal University, 2018. ]
[34]	中华人民共和国住房和城乡建设部. 住房城乡建设部关于发布国家标准《城市居住区规划设计标准》的公告[EB/OL]. https:\\www.mohurd.gov.cn\gongkai\fdzdgknr\tzgg\201811\20181130_238590.html.
	[ Ministry of Housing and Urban-Rural Development of the People's Republic of China. Announcement of the Ministry of housing and urban rural development on Issuing the national standard planning and design standards for urban residential areas[EB/OL]. https:\\www.mohurd.gov.cn\gongkai\fdzdgknr\tzgg\201811\20181130_238590.html. ]
[35]	徐艺文. 城市社区公共服务设施区位研究[D]. 徐州: 中国矿业大学, 2020.
	[ Xu Y W. Research on location of public service facilities in urban communities[D]. Xuzhou: China University of Mining and Technology, 2020. ]
[36]	戴特奇, 廖聪, 胡科, 等. 公平导向的学校分配空间优化——以北京石景山区为例[J]. 地理学报, 2017, 72(8):1476-1485. doi: 10.11821/dlxb201708011
	[ Dai T Q, Liao C, Hu K, et al. Secondary school allocation optimization towards equal access: A case study on Shijingshan District, Beijing[J]. Acta Geographica Sinica, 2017, 72(8):1476-1485. ] DOI: 10.11821/dlxb201708011 doi: 10.11821/dlxb201708011

名称	数据类型	数据来源	年份	数据预处理
武汉市老年人口数据	社区级矢量人口数据	武汉市土地利用和城市空间规划研究中心	2018	整理、添加
武汉市养老设施空间数据	POI数据	百度地图API接口	2020	清洗、重分类、坐标配准
武汉市养老设施属性数据	JSON数据	武汉市民政局官方网站、养老信息网、春座养老网	2020	清洗、整理
交通路网数据	矢量数据	百度地图数据	2020	以百度地图数据为基础进行矢量化处理

规模	老年养护院/床	养老院/床	老年日间照料中心/人
小型	≤100	≤150	≤40
中型	101~250	151~300	40~100
大型	>250	>300	—

	较高	一般	较低
阈值	0.324~1.468	0.052~0.324	0.000~0.051
数量/个	22	811	2985
占比/%	0.58	21.24	78.18

服务功能		设施服务类型供给情况
		大型			中型			小型
		内容	配置情况		内容	配置情况		内容	配置情况
日常基本的养老服务	生活照顾	饮食起居/清洁卫生/生活护理等	高		饮食起居/清洁卫生/生活护理等	高		日托/全托/助餐/上门照料等	较高
高品质多样化的养老服务	医疗保健	保健康复/健康管理等	较高		保健康复/健康管理等	一般		健身/康复训练等	较低
	精神文化	文体娱乐/学习教育等	较高	文体娱乐/学习教育等		较高	学习教育/休闲娱乐等		一般
	心理慰藉	心理咨询/心理支持/临终关怀等	较低	心理咨询/心理支持/临终关怀等		较低	心理咨询		低

等级	属性	服务对象	服务功能
小型养老设施	社区级养老设施	居住在附近、自理能力较强的老年人	休闲娱乐、餐桌服务和上门服务等基础性功能为主
中型养老设施	街道级养老设施	具有一定自理能力的老年人	医疗保健、康养娱乐等功能为主
大型养老设施	区域级养老设施	自理能力较差或需要提供长期照料的老年人	长期护理、医疗保健等功能为主
