基于伪纯像元的精度评价策略及其应用

doi:10.12082/dqxxkx.2022.220048

地球信息科学学报 ›› 2022, Vol. 24 ›› Issue (8): 1617-1630.doi: 10.12082/dqxxkx.2022.220048

基于伪纯像元的精度评价策略及其应用

徐肖¹^,²(), 李娅婷¹^,², 樊辉¹^,²^,^*()

1.云南大学国际河流与生态安全研究院,昆明 650091
2.云南省国际河流与跨境生态安全重点实验室,昆明 650091

收稿日期:2022-01-25 修回日期:2022-02-22 出版日期:2022-08-25 发布日期:2022-10-25
通讯作者: *樊辉（1972— ）,男,江西修水人,博士,研究员,主要从事地理大数据挖掘研究。E-mail: fanhui@ynu.edu.cn
作者简介:徐肖（1998— ）,女,四川南充人,硕士生,主要从事地理大数据挖掘研究。E-mail: xuxiao@mail.ynu.edu.cn
基金资助:
第二次青藏高原综合科学考察研究(2019QZKK0402);国家自然科学基金项目(41971239);国家自然科学基金项目(41461017);云南省教育厅科学研究基金项目(2022Y061)

Accuracy Assessment Strategy based on Pseudo-pure Pixels and its Application

XU Xiao¹^,²(), LI Yating¹^,², FAN Hui¹^,²^,^*()

1. Institute of International Rivers and Eco-Security, Yunnan University, Kunming, 650091, China
2. Yunnan Key Laboratory of International Rivers and Transboundary Eco-Security, Kunming 650091, China

Received:2022-01-25 Revised:2022-02-22 Online:2022-08-25 Published:2022-10-25
Contact: FAN Hui
Supported by:
The Second Tibetan Plateau Scientific Expedition and Research Program(2019QZKK0402);National Natural Science Foundation of China(41971239);National Natural Science Foundation of China(41461017);Scientific Research Foundation of Yunnan Provincial Education Department(2022Y061)

摘要/Abstract

摘要：

土地覆被是地球科学研究中的重要参量,评价土地覆被数据的制图精度是保障数据合理使用的前提。本文提出了一种基于伪纯像元的精度评价策略（伪纯像元策略）,即当低空间分辨率栅格窗口内对应的高空间分辨率数据中优势类别（面积最大的地类）的占比高于伪纯像元纯度阈值（代表像元纯度,取值范围：35%~100%,步长为5%）时,以此栅格窗口为基准生成土地覆被类型为优势类别的伪纯像元用于精度评价。以澜沧江-湄公河（澜湄）流域为试验区,选择GlobeLand30为参考数据,并基于混淆矩阵精度评价方法对比分析了伪纯像元策略与重采样法（最近邻法和众数法）在CCI-LC（300 m）和MCD12Q1（500 m） 2套全球土地覆被数据精度评价中的差异。结果表明：① 伪纯像元策略在35%~100%纯度阈值下对CCI-LC和MCD12Q1在澜湄流域评价的精度分别为72.76%~55.26%和71.44%~45.41%,比重采样法评价的单一精度（众数法：71.21%和70.54%、最近邻法：71.48和69.87%）能更好地反映像元纯度对土地覆被数据精度的影响;② CCI-LC的总体精度高于MCD12Q1,且2套数据的精度差随纯度阈值的增大而增加,CCI-LC和MCD12Q1在35%、100%纯度阈值下的精度差分别为1.32%和9.85%;③ 2套数据中耕地、有林地、草地和水体的分类精度均相对较高,而灌木林地（精度接近0）和裸地的分类精度均较低;④ 2套数据与GlobeLand30的空间不一致区域多出现在土地覆被类型高度异质化的混合像元区域,且随纯度阈值的增大,评价样本栅格更趋均质,混合像元对评价精度的影响也会递减。伪纯像元精度评价策略适用于跨空间分辨率土地覆被数据的精度对比,为评价全球土地覆被产品在区域尺度的适用性及适用范围提供了新的检验策略。

关键词: 伪纯像元, 重采样, 精度评价, 土地覆被, 澜湄流域, GlobeLand30, CCI-LC, MCD12Q1

Abstract:

Land cover is an important parameter in geoscience research, and the accuracy assessment of land cover products is a prerequisite to ensure reasonable application of land cover products. In this study, an accuracy assessment strategy based on pseudo-pure pixels (i.e., pseudo-pure pixel strategy) is proposed. That is, calculating the area of land cover types of the high-resolution pixels within a pixel window of coarse spatial resolution data and defining the land cover type with the largest area as the advantage type, and then generating pseudo-pure pixels of advantage type based on the pixel window when the area proportion of the advantage type is higher than a pseudo-pure pixel purity threshold (ranging from 35% to 100%, with a step length of 5%). We take the Lancang-Mekong (Lanmei) basin as the study area and select the GlobeLand30 as the reference data. The confusion matrix accuracy assessment method was used to compare the difference in the accuracy of two sets of global land cover data, i.e., CCI-LC (300 m) and MCD12Q1 (500 m), using different assessment methods, i.e., the pseudo-pure pixel strategy and the resampling method (Nearest and Majority). Our results show that: (1) The accuracy using the pseudo-pure pixel strategy for CCI-LC and MCD12Q1 in the Lanmei Basin under the purity thresholds of 35%~100% are 72.76%~55.26% and 71.44%~45.41%, respectively, and it can better reflect the influence of pixel purity on the accuracy of land cover data than the single accuracy obtained by resampling method (Nearest: 71.21% and 70.54%; Majority: 71.48 and 69.87%); (2) The overall accuracy of CCI-LC is higher than that of MCD12Q1. The accuracy difference of the two datasets increases with the increase of purity threshold, and it is 1.32% and 9.85% respectively for purity threshold of 35% and 100%, respectively; (3) In both datasets, the classification accuracy of cropland, forest, grassland, and water is relatively high, and the classification accuracy of shrub land and bare land is relatively low; (4) The spatial inconsistency between the two datasets and the GlobeLand30 mainly occur in mixed pixel regions with highly heterogeneous land cover types. And the assessment sample grids are purer with the increase of pseudo-pure pixel threshold, which reduces the effects of mixed pixels on accuracy assessment. The pseudo-pure pixel strategy has the potential to compare the mapping accuracy of land cover data with different spatial resolutions, and provides a promising validation method for determining the applicability and application scope of global land cover products at regional scales.

Key words: pseudo-pure pixel, resampling, accuracy assessment, land cover, Lancang-Mekong River Basin, GlobeLand30, CCI-LC, MCD12Q1

徐肖, 李娅婷, 樊辉. 基于伪纯像元的精度评价策略及其应用[J]. 地球信息科学学报, 2022, 24(8): 1617-1630.DOI:10.12082/dqxxkx.2022.220048

XU Xiao, LI Yating, FAN Hui. Accuracy Assessment Strategy based on Pseudo-pure Pixels and its Application[J]. Journal of Geo-information Science, 2022, 24(8): 1617-1630.DOI:10.12082/dqxxkx.2022.220048

图/表 11

图1

图2

表1

表2

不同土地覆被分类系统间的类别对应关系

编号	类别	GlobleLand30	CCI-LC	MCD12Q1
1	耕地	10用于种植农作物的土地,包括水田、灌溉旱地、大棚用地,以及果园茶园等灌木类经济作物种植地	10/11/12农田旱地/草本覆被的耕地/树或灌丛覆被的耕地 20灌溉旱地或洪泛耕地 30耕地(>50%)与树、灌、草等自然植被(<50%)的混交地	12农用地 14农用地与自然植被混合：40%~60%为天然乔木、灌木林地或草本植被
2	有林地	20树冠覆被度>30%的土地,包括落叶阔叶林、常绿阔叶林、落叶针叶林、常绿针叶林、混交林,以及树冠覆被度为10%~30%的疏林地	50常绿阔叶林(>15%) 60/61/62落叶阔叶林(>15%)/(>40%)/(15%~40%) 70/71/72常绿针叶林(>15%)/(>40%)/(15%~40%) 80/81/82落叶针叶林(>15%)/(>40%)/(15%~40%) 90针阔混交林 100乔木和灌木林地(>50%)与草本植物(<50%)的混交地	1常绿针叶林：冠幅>4 m²,覆被度>60% 2常绿阔叶林：冠幅>4 m²,覆被度>60% 3落叶针叶林：冠幅>4 m²,覆被度>60% 4落叶阔叶林：冠幅>4 m²,覆被度>60% 5针阔混交林：落叶常绿为主,冠幅>4 m²,覆被度>60% 8木本稀树草原：冠幅>4 m²,覆被度30%~60%
3	草地	30天然草本覆被度>10%的土地,包括草原、草甸、稀疏草原、荒漠草原、人工草地	110草本植被(>50%)与树(<50%)的混交地 130草地	10草地：以年生草本植物为主,高度<2 m
4	灌木林地	40灌木覆被度>30%的土地,包括山地灌丛、落叶和常绿灌丛,以及荒漠地区覆被度>10%的荒漠灌丛	120/121/122灌木林地/常绿灌木林地/落叶灌木林地 40树、灌、草等自然植被(>50%)与耕地(<50%)的混交地	6稠密灌丛：以木本多年生植物为主,高度1~2 m,覆被度>60% 7稀疏灌丛：以木本多年生植物为主,高度1~2 m,覆被度10%~60% 9稀树草原：树木覆被度10-30%,冠幅>4 m²
5	湿地	50有浅层积水或土壤过湿的土地,包括内陆沼泽、湖泊沼泽、河流洪泛湿地、森林/灌木湿地、泥炭沼泽、盐沼等	160被水淹没的有林地(淡水或咸水) 170被水淹没的有林地(海水) 180被水淹没的灌木林地和草本植物(淡水、海水或咸水)	11永久湿地：永久淹水面积30%~60%,植被覆被度>10%的土地
6	水体	60 陆地范围液态水覆被的区域	210水体	17水体：至少60%的区域被永久水体覆被
7	建设用地	80由人工建造活动形成的地表	190城镇地区	13城市和建筑区：至少30%的不透水表面,包括建筑材料、沥青道路
8	裸地	90植被覆被度<10%的自然覆被土地,包括荒漠、沙地、砾石地、裸岩、盐碱地等	200/201/202裸地/坚固的裸地/松散的裸地 150/152/153树、灌、草等稀疏植被(<15%)	16裸地：至少60%的区域是没有植被覆被的裸露地区(沙、岩石、土壤),植被覆被<10%
9	永久冰雪	100由永久积雪、冰川和冰盖覆被的土地	220 永久冰雪	15雪和冰：全年至少有60%的地区被冰雪覆被10个月

表2

图3

图4

图5

图6

图7

图8

图9

参考文献 45

[1]	Grekousis G, Mountrakis G, Kavouras M. An overview of 21 global and 43 regional land-cover mapping products[J]. International Journal of Remote Sensing, 2015, 36(21):5309-5335. DOI: 10.1080/01431161.2015.1093195 doi: 10.1080/01431161.2015.1093195
[2]	Singh D, McDermid S P, Cook B I, et al. Distinct influences of land cover and land management on seasonal climate[J]. Journal of Geophysical Research: Atmospheres, 2018, 123(21):12017-12039. DOI: 10.1029/2018JD028874 doi: 10.1029/2018JD028874
[3]	吴英迪, 蒙吉军. 中国自然资源生态服务重要性评价与空间格局分析[J]. 自然资源学报, 2022, 37(1):17-33.
	[ Wu Y D, Meng J J. Importance assessment and spatial pattern analysis of natural resources ecological services in China[J]. Journal of Natural Resources, 2022, 37(1):17-33. ] DOI: 10.31497/zrzyxb.20220102 doi: 10.31497/zrzyxb.20220102
[4]	Manakos I, Tomaszewska M, Gkinis I, et al. Comparison of global and continental land cover products for selected study areas in south central and eastern European region[J]. Remote Sensing, 2018, 10(12):1967-1988. DOI: 10.3390/rs10121967 doi: 10.3390/rs10121967
[5]	Zhao Y Y, Gong P, Yu L, et al. Towards a common validation sample set for global land-cover mapping[J]. International Journal of Remote Sensing, 2014, 35(13):4795-4814. DOI: 10.1080/01431161.2014.930202 doi: 10.1080/01431161.2014.930202
[6]	Bai Y, Feng M, Jiang H, et al. Assessing consistency of five global land cover data sets in China[J]. Remote Sensing, 2014, 6(9):8739-8759. DOI: 10.3390/rs6098739 doi: 10.3390/rs6098739
[7]	Yang Y K, Xiao P F, Feng X Z, et al. Accuracy assessment of seven global land cover datasets over China[J]. ISPRS Journal of Photogrammetry and Remote Sensing, 2017, 125(3):156-173. DOI: 10.1016/j.isprsjprs.2017.01.016 doi: 10.1016/j.isprsjprs.2017.01.016
[8]	刘琼欢, 张镱锂, 刘林山, 等. 七套土地覆被数据在羌塘高原的精度评价[J]. 地理研究, 2017, 36(11):2061-2074. doi: 10.11821/dlyj201711003
	[ Liu Q H, Zhang Y L, Liu L S, et al. Accuracy evaluation of the seven land cover datasets in the Qiangtang Plateau[J]. Geographical Research, 2017, 36(11):2061-2074. ] DOI: 10.11821/dlyj201711003 doi: 10.11821/dlyj201711003
[9]	Bai Y, Feng M, Jiang H, et al. Validation of land cover maps in China using a sampling-based labeling approach[J]. Remote Sensing, 2015, 7(8):10589-10606. DOI: 10.3390/rs70810589 doi: 10.3390/rs70810589
[10]	Stehman S V, Foody G M. Key issues in rigorous accuracy assessment of land cover products[J]. Remote Sensing of Environment, 2019, 231(9):111199. DOI: 10.1016/j.rse.2019.05.018 doi: 10.1016/j.rse.2019.05.018
[11]	Liang D, Zuo Y, Huang L S, et al. Evaluation of the consistency of MODIS land cover product (MCD12Q1) based on Chinese 30 m GlobeLand30 datasets: a case study in Anhui Province, China[J]. ISPRS International Journal of Geo-Information, 2015, 4(4): 2519-2541. DOI: 10.3390/ijgi4042519 doi: 10.3390/ijgi4042519
[12]	马京振, 孙群, 肖强, 等. 河南省GlobeLand30数据精度评价及对比分析[J]. 地球信息科学学报, 2016, 18(11):1563-1572. doi: 10.3724/SP.J.1047.2016.01563
	[ Ma J Z, Sun Q, Xiao Q, et al. Accuracy assessment and comparative analysis of GlobeLand30 dataset in Henan Province[J]. Journal of Geo-information Science, 2016, 18(11):1563-1572. ] DOI: 10.3724/SP.J.1047.2016.01563 doi: 10.3724/SP.J.1047.2016.01563
[13]	Schultz M, Tsendbazar N E, Herold M, et al. Utilizing the Global Land Cover 2000 reference dataset for a comparative accuracy assessment of 1 km global land cover maps[C]. ISPRS Archives, 2015, XL-7/W3:503-510. DOI: 10.5194/isprsarchives-XL-7-W3-503-2015 doi: 10.5194/isprsarchives-XL-7-W3-503-2015
[14]	Zhang X, Liu L Y, Chen X D, et al. GLC_FCS30: Global land-cover product with fine classification system at 30 m using time-series Landsat imagery[J]. Earth System Science Data, 2021, 13(6):2753-2776. DOI: 10.5194/essd-13-2753-2021 doi: 10.5194/essd-13-2753-2021
[15]	Chen J, Chen L J, Chen F, et al. Collaborative validation of GlobeLand30: Methodology and practices[J]. Geo-Spatial Information Science, 2021, 24(1):134-144. DOI: 10.1080/10095020.2021.1894906 doi: 10.1080/10095020.2021.1894906
[16]	陈逸聪, 邵华, 李杨. 多源土地覆被产品在长三角地区的一致性分析与精度评价[J]. 农业工程学报, 2021, 37(6):142-150.
	[ Chen Y C, Shao H, Li Y. Consistency analysis and accuracy assessment of multi-source land cover products in the Yangtze River Delta[J]. Transactions of the Chinese Society of Agricultural Engineering, 2021, 37(6):142-150. ] DOI: 10.11975/j.issn.1002-6819.2021.06.018 doi: 10.11975/j.issn.1002-6819.2021.06.018
[17]	Hu J W, Xia G S, Sun H. An SRTM-aided epipolar resampling method for multi-Source high-resolution satellite stereo observation[J]. Remote Sensing, 2019, 11(6):678-696. DOI: 10.3390/rs11060678 doi: 10.3390/rs11060678
[18]	张永梅, 滑瑞敏, 马健喆, 等. 基于深度学习与超分辨率重建的遥感高时空融合方法[J]. 计算机工程与科学, 2020, 42(9):1578-1586.
	[ Zhang Y M, Hua R M, Ma J J, et al. A high spatial temporal fusion method based on deep learning and super resolution reconstruction[J]. Computer Engineering & Science, 2020, 42(9):1578-1586. ] DOI: 10.3969/j.issn.1007-130X.2020.09.008 doi: 10.3969/j.issn.1007-130X.2020.09.008
[19]	张周威, 余涛, 孟庆岩, 等. 空间重采样方法对遥感影像信息影响研究[J]. 华中师范大学学报(自然科学版), 2013, 47(3):426-430.
	[ Zhang Z W, Yu T, Meng Q Y, et al. Influence of spatial resampling method on remote sensing image information[J]. Journal of Central China Normal University (Natural Sciences), 2013, 47(3):426-430. ] DOI: 10.19603/j.cnki.1000-1190.2013.03.028 doi: 10.19603/j.cnki.1000-1190.2013.03.028
[20]	赵英时. 遥感应用分析原理与方法[M]. 北京: 科学出版社, 2003:34-35.
	[ Zhao Y H. Principle and method of remote sensing application analysis[M]. Beijing: Science Press, 2003:34-35. ]
[21]	Liu C R, Frazier P, Kumar L. Comparative assessment of the measures of thematic classification accuracy[J]. Remote Sensing of Environment, 2007, 107(4):606-616. DOI: 10.1016/j.rse.2006.10.010 doi: 10.1016/j.rse.2006.10.010
[22]	MRC. Overview of the hydrology of the Mekong Basin[R]. Vientiane: Mekong River commission, 2005:73-75.
[23]	何大明. 澜沧江──湄公河水文特征分析[J]. 云南地理环境研究, 1995,(1):58-74.
	[ He D M. Hydrological characteristics of Lancang-Mekong River[J]. Yunnan Geographical Environment Research, 1995,(1):58-74. ]
[24]	陈丽晖, 曾尊固, 何大明. 国际河流流域开发中的利益冲突及其关系协调——以澜沧江-湄公河为例[J]. 世界地理研究, 2003, 12(1):71-78.
	[ Chen L H, Zeng Z G, He D M. Interest conflict and relationship coordination in international river basin development: A case study of Lancang-Mekong River[J]. World Regional Studies, 2003, 12(1):71-78. ]
[25]	Rundel P W. Chapter 7 Chapter 7 - Vegetation in the Mekong Basin[M]. The Mekong. San Diego; Academic Press. 2009:143-160. DOI: 10.1016/B978-0-12-374026-7.00007-3 doi: 10.1016/B978-0-12-374026-7.00007-3
[26]	ESA. Land Cover CCI: Product User Guide Version 2 (2017). Available online: https://www.esa-landcover-cci.org/?q=webfm_send/84.
[27]	Friedl M A, Sulla-Menashe D, Tan B, et al. MODIS Collection 5 global land cover: Algorithm refinements and characterization of new datasets[J]. Remote Sensing of Environment, 2010, 114(1):168-182. DOI: 10.1016/j.rse.2009.08.016 doi: 10.1016/j.rse.2009.08.016
[28]	Chen J, Chen J, Liao A P, et al. Global land cover mapping at 30 m resolution: A POK-based operational approach[J]. ISPRS Journal of Photogrammetry and Remote Sensing, 2015, 103(5):7-27. DOI: 10.1016/j.isprsjprs.2014.09.002 doi: 10.1016/j.isprsjprs.2014.09.002
[29]	陈军, 廖安平, 陈晋, 等. 全球30m地表覆盖遥感数据产品-Globe Land30[J]. 地理信息世界, 2017, 24(1):1-8.
	[ Chen J, Liao A P, Chen J, et al. 30 m Global land cover data product- GlobeLand30[J]. Geographic Information World, 2017, 24(1):1-8. ] DOI: 10.3969/j.issn.1672-1586.2017.01.002 doi: 10.3969/j.issn.1672-1586.2017.01.002
[30]	黄亚博, 廖顺宝. 首套全球30m分辨率土地覆被产品区域尺度精度评价——以河南省为例[J]. 地理研究, 2016, 35(8):1433-1446. doi: 10.11821/dlyj201608003
	[ Huang Y B, Liao S B. Regional accuracy assessments of the first global land cover dataset at 30-meter resolution: A case study of Henan province[J]. Geographical Research, 2016, 35(8):1433-1446. ] DOI: 10.11821/dlyj201608003 doi: 10.11821/dlyj201608003
[31]	Xu Y D, Yu L, Feng D L, et al. Comparisons of three recent moderate resolution African land cover datasets: CGLS-LC100, ESA-S2-LC20, and FROM-GLC-Africa30[J]. International Journal of Remote Sensing, 2019, 40(16):6185-6202. DOI: 10.1080/01431161.2019.1587207 doi: 10.1080/01431161.2019.1587207
[32]	姚远, 陈曦, 钱静. 定量遥感尺度转换方法研究进展[J]. 地理科学, 2019, 39(3):367-376. doi: 10.13249/j.cnki.sgs.2019.03.002
	[ Yao Y, Chen X, Qian J. A review on the methodology of scale issues in quantitative remote sensing[J]. Scientia Geographica Sinica, 2019, 39(3):367-376. ] DOI: 10.13249/j.cnki.sgs.2019.03.002 doi: 10.13249/j.cnki.sgs.2019.03.002
[33]	栾海军, 田庆久, 章欣欣, 等. 定量遥感地表参数尺度转换研究趋势探讨[J]. 地球科学进展, 2018, 33(5):483-492. doi: 10.11867/j.issn.1001-8166.2018.05.0483
	[ Nuan H J, Tian Q J, Zang X X, et al. Trends on scaling research for land surface parameters in quantitative remote sensing[J]. Advances in Earth Science, 2018, 33(5):483-492. ] DOI: 10.11867/j.issn.1001-8166.2018.05.0483 doi: 10.11867/j.issn.1001-8166.2018.05.0483
[34]	郝大磊, 肖青, 闻建光, 等. 定量遥感升尺度转换方法研究进展[J]. 遥感学报, 2018, 22(3):408-423.
	[ Hao D L, Xiao Q, Wen J G, et al. Advances in upscaling methods of quantitative remote sensing[J]. Journal of Remote Sensing, 2018, 22(3):408-423. ] DOI: 10.11834/jrs.20187070 doi: 10.11834/jrs.20187070
[35]	Li Y, Chen J, Rao Y H. A practical sampling method for assessing accuracy of detected land cover/land use change: Theoretical analysis and simulation experiments[J]. ISPRS Journal of Photogrammetry and Remote Sensing, 2018, 144(10):379-389. DOI: 10.1016/j.isprsjprs.2018.08.006 doi: 10.1016/j.isprsjprs.2018.08.006
[36]	周觅, 张杰林. 遥感影像尺度转换及最优尺度选择探讨[J]. 世界核地质科学, 2011, 28(2):94-98.
	[ Zhou M, Zhang J L. Scale transformation and optimal scale selection of remote sensing images[J]. World Nuclear Geoscience, 2011, 28(2):94-98. ] DOI: 10.3969/j.issn.1672-0636.2011.02.006 doi: 10.3969/j.issn.1672-0636.2011.02.006
[37]	郭紫甜, 王春梅, 刘欣, 等. 基于小流域抽样单元的中国FROM-GLC30数据精度评价[J]. 地球信息科学学报, 2021, 23(3):524-535. doi: 10.12082/dqxxkx.2021.200100
	[ Guo Z T, Wang C M, Liu X, et al. Accuracy evaluation of FROM-GLC30 data in China based on small watershed sampling unit[J]. Journal of Geo-information Science, 2021, 23(3):524-535. ] DOI: 10.12082/dqxxkx.2021.200100 doi: 10.12082/dqxxkx.2021.200100
[38]	廖顺宝, 葛乐玮, 王艳萍, 等. 利用地形参数提高土地覆被分类精度方法的改进[J]. 遥感信息, 2021, 36(3):10-16.
	[ Liao S B, Ge L W, Wang Y P, et al. An improved method to improve the accuracy of land cover classification using topographic parameters[J]. Remote Sensing Information, 2021, 36(3):10-16. ] DOI: 10.3969/j.issn.1000-3177.2021.03.002 doi: 10.3969/j.issn.1000-3177.2021.03.002
[39]	Reid W V, Chen D, Goldfarb L, et al. Earth system science for global sustainability: Grand challenges[J]. Science, 2010, 330(6006):916-917. DOI: 10.1126/science.1196263 doi: 10.1126/science.1196263 pmid: 21071651
[40]	Kuenzer C, Leinenkugel P, Vollmuth M, et al. Comparing global land-cover products - implications for geoscience applications: an investigation for the trans-boundary Mekong Basin[J]. International Journal of Remote Sensing, 2014, 35(8):2752-2779. DOI: 10.1080/01431161.2014.890305 doi: 10.1080/01431161.2014.890305
[41]	许光明, 杨雅萍, 杨飞, 等. 多分辨率遥感土地覆被数据质量综合评价——以湖南省桃源县为例[J]. 地球信息科学学报, 2016, 18(4):553-563. doi: 10.3724/SP.J.1047.2016.00553
	[ Xu G M, Yang Y P, Yang F, et al. Quality assessment of multi-resolution remote sensing land cover data: a case study in Taoyuan county of Hunan province[J]. Journal of Geo-information Science, 2016, 18(4):553-563. ] DOI: 10.3724/SP.J.1047.2016.00553 doi: 10.3724/SP.J.1047.2016.00553
[42]	Zhang M, Ma M G, De Maeyer P, et al. Uncertainties in classification system conversion and an analysis of inconsistencies in global land cover products[J]. ISPRS International Journal of Geo-Information, 2017, 6(4):112-129. DOI: 10.3390/ijgi6040112 doi: 10.3390/ijgi6040112
[43]	Hua T, Zhao W W, Liu Y X, et al. Spatial consistency assessments for global land-cover datasets: A comparison among GLC2000, CCI-LC, MCD12, GLOBCOVER and GLCNMO[J]. Remote Sensing, 2018, 10(11):1846-1864. DOI: 10.3390/rs10111846 doi: 10.3390/rs10111846
[44]	Latifovic R, Olthof I. Accuracy assessment using sub-pixel fractional error matrices of global land cover products derived from satellite data[J]. Remote Sensing of Environment, 2004, 90(2):153-165. DOI: 10.1016/j.rse.2003.11.016 doi: 10.1016/j.rse.2003.11.016
[45]	Wang L B, Bartlett P, Pouliot D, et al. Comparison and assessment of regional and global land cover datasets for use in CLASS over Canada[J]. Remote Sensing, 2019, 11(19):2286-2301. DOI: 10.3390/rs11192286 doi: 10.3390/rs11192286

数据集	GlobleLand30	CCI-LC	MCD12Q1
传感器	Landsat TM5/ETM+、HJ-1	ENVISAT MERIS、SPOT	Terra MODIS
分类方法	像元-对象-知识(POK方法)	非监督分类	监督分类/决策树/神经网络
分辨率/m	30	300	500
时相	2000年、2010年	1992—2020年	2001—2015年
分类体系	自分类体系 (10类)	LCCS (22类)	IGBP (17类)
总体精度/%	83.50	74.40	75.00
验证方法	交叉验证	样本验证	交叉验证
