地理信息系统研究新范式

doi:10.12082/dqxxkx.2023.220300

摘要/Abstract

摘要：

随着大数据时代的到来，地理信息系统（GIS）的时空范畴、信息内容和应用场景都得到了前所未有的扩展，地理信息系统需要由例外处理的被动适应方式，转变为内核支持的主动扩展方式，将地理信息系统扩展为新一代时空信息系统。本文在分析地理信息系统本质是以地图数据模型为核心的信息系统的基础上，从研究对象、基本原理和技术方法3个方面总结梳理了地理信息系统研究范式，并分析阐述了时空信息扩展对地理信息系统研究范式的新要求。其次，在分析全空间信息系统（PSIS）认知模型与多粒度时空对象数据模型的基础上，归纳出全空间信息系统基于时空实体的理论与技术路线，并总结其在多个领域的实践与应用。然后，系统分析了全空间信息系统对地理信息系统研究对象、基本原理和技术方法的具体扩展方式，提出全空间信息系统研究范式。最后，总结梳理了全空间信息系统研究范式的基本内容，并与地理信息系统研究范式进行了核心内容的分析对比，展望了地理信息系统研究范式进阶将带来的影响和变化。

关键词: 地理信息系统, 全空间信息系统, 研究范式, 时空信息, 时空实体, 时空对象, 数字世界

Abstract:

In the era of big data, the spatio-temporal category, information content, and application scenarios of Geographic Information Systems(GIS) have expanded unprecedentedly. GIS needs to transform from the passive adaptation mode of exception processing into an active kernel-supported mode, forming a new generation of spatio-temporal information system. Given that the essence of GIS is an information system with cartographic data model as the core, this paper summarizes the research paradigm of GIS from three aspects: research objects, basic principles, and technical methods, and analyzes the new requirements of spatio-temporal information expansion on the GIS research paradigm. Secondly, by analyzing the cognitive model of Pan-Spatial Information System (PSIS) and the multi-granularity spatio-temporal object data model, the theoretical and technical routes of the PSIS based on spatio-temporal entities are concluded, and its practice and application in many fields are summarized. Then, it systematically analyzes the specific extension mode of PSIS in GIS research object, basic principles, and technical methods, respectively, and proposes the PSIS research paradigm. Finally, this paper summarizes the basic content of the PSIS research paradigm, compares the core content with the GIS research paradigm, and looks forward to the impacts and changes that the advanced research paradigm of GIS would bring.

Key words: geographic information system, pan-spatial information system, research paradigm, spatio-temporal information, spatio-temporal entity, spatio-temporal object, digital world

华一新, 赵鑫科, 张江水. 地理信息系统研究新范式[J]. 地球信息科学学报, 2023, 25(1): 15-24.DOI:10.12082/dqxxkx.2023.220300

HUA Yixin, ZHAO Xinke, ZHANG Jiangshui. New Paradigm of Geographic Information Systems Research[J]. Journal of Geo-information Science, 2023, 25(1): 15-24.DOI:10.12082/dqxxkx.2023.220300

图/表 5

图1

表1

图2

图3

表2

参考文献 45

[1]	周成虎. 全空间地理信息系统展望[J]. 地理科学进展, 2015, 34(2):129-131. doi: 10.11820/dlkxjz.2015.02.001
	[Zhou C H. Prospects on pan-spatial information system[J]. Progress in Geography, 2015, 34(2):129-131. ] DOI:10.11820/dlkxjz.2015.02.001 doi: 10.11820/dlkxjz.2015.02.001
[2]	Li L N, Goodchild M F, Xu B. Spatial, temporal, and socioeconomic patterns in the use of Twitter and Flickr[J]. Cartography and Geographic Information Science, 2013, 40(2):61-77. DOI:10.1080/15230406.2013.777139 doi: 10.1080/15230406.2013.777139
[3]	Wang S W, Anselin L, Bhaduri B, et al. CyberGIS software: A synthetic review and integration roadmap[J]. International Journal of Geographical Information Science, 2013, 27(11):2122-2145. DOI:10.1080/13658816.2013.776049 doi: 10.1080/13658816.2013.776049
[4]	刘浩, 薛梅. 虚拟地理环境下的地理空间认知初步探索[J]. 遥感学报, 2021, 25(10):2027-2039.
	[Liu H, Xue M. Exploring the use of virtual geographic environments for geo-spatial cognition research[J]. National Remote Sensing Bulletin, 2021, 25(10):2027-2039. ] DOI:10.11834/jrs.20210460 doi: 10.11834/jrs.20210460
[5]	万刚, 武易天. 地图空间认知的数学基础[J]. 测绘学报, 2021, 50(6):726-738.
	[Wan G, Wu Y T. On the mathematical basis of map spatial cognition[J]. Acta Geodaetica et Cartographica Sinica, 2021, 50(6):726-738. ] DOI:10.11947/j.AGCS.2021.20210041 doi: 10.11947/j.AGCS.2021.20210041
[6]	Li W W, Batty M, Goodchild M F. Real-time GIS for smart cities[J]. International Journal of Geographical Information Science, 2020, 34(2):311-324. DOI:10.1080/13658816.2019.1673397 doi: 10.1080/13658816.2019.1673397
[7]	Usmani R S A, Hashem I A T, Pillai T R, et al. Geographic information system and big spatial data: A review and challenges[J]. International Journal of Enterprise Information Systems, 2020, 16(4):101-145. DOI:10.4018/IJEIS.2020100106 doi: 10.4018/IJEIS.2020100106
[8]	Elwood S, Goodchild M F, Sui D Z. Researching volunteered geographic information: Spatial data, geographic research, and new social practice[J]. Annals of the Association of American Geographers, 2012, 102(3):571-590. DOI:10.1080/00045608.2011.595657 doi: 10.1080/00045608.2011.595657
[9]	Senaratne H, Mobasheri A, Ali A L, et al. A review of volunteered geographic information quality assessment methods[J]. International Journal of Geographical Information Science, 2017, 31(1):139-167. DOI:10.1080/13658816.2016.1189556 doi: 10.1080/13658816.2016.1189556
[10]	陆锋, 张恒才. 大数据与广义GIS[J]. 武汉大学学报·信息科学版), 2014, 39(6):645-654.
	[Lu F, Zhang H C. Big data and generalized GIS[J]. Geomatics and Information Science of Wuhan University, 2014, 39(6):645-654. ] DOI:10.13203/j.whugis20140148 doi: 10.13203/j.whugis20140148
[11]	Kuhn T S. The Structure of Scientific Revolutions[M]. Chicago: University of Chicago Press, 1962.
[12]	华一新, 张毅, 成毅, 等. 地理信息系统原理[M].第二版. 北京: 科学出版社, 2019.
	[Hua Y X, Zhang Y, Cheng Y, et al. Geographic information system principles[M]. 2rd ed.ed. Beijing: Science Press, 2019. ]
[13]	吕慧玲, 李佩瑶, 汤圣君, 等. BIM模型到多细节层次GIS模型转换方法[J]. 地理信息世界, 2016, 23(4):64-70.
	[Lv H L, Li P Y, Tang S J, et al. Transformation method from BIM model to GIS model in different levels of details[J]. Geomatics World, 2016, 23(4):64-70. ] DOI:10.3969/j.issn.1672-1586.2016.04.012 doi: 10.3969/j.issn.1672-1586.2016.04.012
[14]	华一新. 全空间信息系统的核心问题和关键技术[J]. 测绘科学技术学报, 2016, 33(4):331-335.
	[Hua Y X. The core problems and key technologies of pan-spatial information system[J]. Journal of Geomatics Science and Technology, 2016, 33(4):331-335. ] DOI:10.3969/j.issn.1673-6338.2016.04.001 doi: 10.3969/j.issn.1673-6338.2016.04.001
[15]	江南, 方成, 陈敏颉. 全空间信息系统认知与表达初探[J]. 地球信息科学学报, 2017, 19(9):1150-1157. doi: 10.3724/SP.J.1047.2017.01150
	[Jiang N, Fang C, Chen M J. Initial exploration of pan-spatial cognition and representation[J]. Journal of Geo-information Science, 2017, 19(9):1150-1157. ] DOI:10.3724/SP.J.1047.2017.01150 doi: 10.3724/SP.J.1047.2017.01150
[16]	Goodchild M F. Geographic information systems and science: Today and tomorrow[J]. Annals of GIS, 2009, 15(1):3-9. DOI:10.1080/19475680903250715 doi: 10.1080/19475680903250715
[17]	华一新, 周成虎. 面向全空间信息系统的多粒度时空对象数据模型描述框架[J]. 地球信息科学学报, 2017, 19(9):1142-1149. doi: 10.3724/SP.J.1047.2017.01142
	[Hua Y X, Zhou C H. Description frame of data model of multi-granularity spatio-temporal object for pan-spatial information system[J]. Journal of Geo-information Science, 2017, 19(9):1142-1149. ] DOI:10.3724/SP.J.1047.2017.01142 doi: 10.3724/SP.J.1047.2017.01142
[18]	于天星, 李锐, 吴华意. 面向对象的地理实体时空位置多粒度表达.地球信息科学学报[J], 2017, 19(9):1208-1216.
	[Yu T X, Li R, Wu H Y. An object-oriented representation method for multi-granularity for spatio-temporal position of geographical entities[J]. Journal of Geo-information Science, 2017, 19(9):1208-1216. ] DOI:10.3724/SP.J.1047.2017.01208 doi: 10.3724/SP.J.1047.2017.01208
[19]	杨振凯, 张江水, 李翔, 等. 时空对象组成结构基本问题初探[J]. 测绘科学技术学报, 2021, 38(6): 639-645.
	[Yang Z K, Zhang J S, Li X, et al. The basic issues of composition structure of spatio-temporal objects[J]. Journal of Geomatics Science and Technology, 2021, 38(6):639-645. ] DOI:10.3969/j.issn.1673-6338.2021.06.014 doi: 10.3969/j.issn.1673-6338.2021.06.014
[20]	李锐, 石佳豪, 董广胜, 等. 多粒度时空对象组成结构表达研究[J]. 地球信息科学学报, 2021, 23(1):113-123. doi: 10.12082/dqxxkx.2021.200423
	[Li R, Shi J H, Dong G S, et al. Research on expression of multi-granularity spatio-temporal object composition structure[J]. Journal of Geo-information Science, 2021, 23(1):113-123. ] DOI:10.12082/dqxxkx.2021.200423 doi: 10.12082/dqxxkx.2021.200423
[21]	张政, 华一新, 张晓楠, 等. 多粒度时空对象关联关系基本问题初探[J]. 地球信息科学学报, 2017, 19(9):1158-1163. doi: 10.3724/SP.J.1047.2017.01158
	[Zhang Z, Hua Y X, Zhang X N, et al. The basic issues of associative relationship of spatial-temporal objects of multi-granularity[J]. Journal of Geo-information Science, 2017, 19(9):1158-1163. ] DOI:10.3724/SP.J.1047.2017.01158 doi: 10.3724/SP.J.1047.2017.01158
[22]	成波, 关雪峰, 向隆刚, 等. 一种面向时空对象及其关联关系动态变化表达的概念数据模型[J]. 地球信息科学学报, 2017, 19(11):1415-1421. doi: 10.3724/SP.J.1047.2017.01415
	[Cheng B, Guan X F, Xiang L G, et al. A conceptual data model for dynamic changes expression of spatio-temporal object and its association[J]. Journal of Geo-information Science, 2017, 19(11):1415-1421. ] DOI:10.3724/SP.J.1047.2017.01415 doi: 10.3724/SP.J.1047.2017.01415
[23]	曹一冰, 华一新, 郭邵萌. 多粒度时空对象行为特征的描述方法研究[J]. 地理信息世界, 2018, 25(2):23-29.
	[Cao Y B, Hua Y X, Guo S M. Study on the description of behavior characteristics of spatial-temporal objects of multi-granularity[J]. Geomatics World, 2018, 25(2):23-29. ] DOI:10.3969/j.issn.1672-1586.2018.02.005 doi: 10.3969/j.issn.1672-1586.2018.02.005
[24]	赵鑫科, 曹一冰, 杨飞, 等. 多粒度时空对象的行为控制与动态显示[J]. 地理信息世界, 2020, 27(3):107-113.
	[Zhao X K, Cao Y B, Yang F, et al. The behavior control and dynamic display of multi-granularity spatiotemporal objects[J]. Geomatics World, 2020, 27(3):107-113. ] DOI:10.3969/j.issn.1672-1586.2020.03.018 doi: 10.3969/j.issn.1672-1586.2020.03.018
[25]	刘朝辉, 李锐, 王璟琦. 顾及语义尺度的时空对象属性特征动态表达[J]. 地球信息科学学报, 2017, 19(9):1185-1194. doi: 10.3724/SP.J.1047.2017.01185
	[Liu Z H, Li R, Wang J Q. A dynamic representation method of considering semantic scales of attributes of spatio-temporal object[J]. Journal of Geo-information Science, 2017, 19(9):1185-1194. ] DOI:10.3724/SP.J.1047.2017.01185 doi: 10.3724/SP.J.1047.2017.01185
[26]	张江水, 华一新, 李翔. 多粒度时空对象建模的基本内容与方法[J]. 地理信息世界, 2018, 25(2):12-16.
	[Zhang J S, Hua Y X, Li X. The basic content and methods of multi-granularity spatio-temporal object modeling[J]. Geomatics World, 2018, 25(2):12-16. ] DOI:10.3969/j.issn.1672-1586.2018.02.003 doi: 10.3969/j.issn.1672-1586.2018.02.003
[27]	曹一冰, 张江水, 华一新, 等. 全空间时空对象可视化工具的设计与实现[J]. 测绘科学技术学报, 2021, 38(2):173-180.
	[Cao Y B, Zhang J S, Hua Y X, et al. Design and implementation of the visualization tool for spatio-temporal objects in pan-spatial information system[J]. Journal of Geomatics Science and Technology, 2021, 38(2):173-180. ] DOI:10.3969/j.issn.1673-6338.2021.02.011 doi: 10.3969/j.issn.1673-6338.2021.02.011
[28]	张毅, 华一新, 刘小春, 等. 面向全空间信息系统的传感设备实时数据管理架构[J]. 测绘科学技术学报, 2021, 38(3):301-308.
	[Zhang Y, Hua Y X, Liu X C, et al. A real-time data management architecture of sensing equipment for pan-spatial information system[J]. Journal of Geomatics Science and Technology, 2021, 38(3):301-308. ] DOI:10.3969/j.issn.1673-6338.2021.03.013 doi: 10.3969/j.issn.1673-6338.2021.03.013
[29]	杨飞, 华一新, 李响, 等. 多粒度时空对象行为驱动的传感设施接入方法[J]. 测绘科学技术学报, 2020, 37(5):537-544.
	[Yang F, Hua Y X, Li X, et al. Research on sensor facilities access method driven by multi-granularity spatio-temporal object behavior[J]. Journal of Geomatics Science and Technology, 2020, 37(5):537-544. ] DOI:10.3969/j.issn.1673-6338.2020.05.015 doi: 10.3969/j.issn.1673-6338.2020.05.015
[30]	訾璐, 张江水, 杨振凯, 等. 高精地图交通要素对象化建模方法[J]. 测绘科学技术学报, 2020, 37(6):636-642.
	[Zi L, Zhang J S, Yang Z K, et al. Object modeling method of traffic elements in high-precision map[J]. Journal of Geomatics Science and Technology, 2020, 37(6):636-642. ] DOI:10.3969/j.issn.1673-6338.2020.06.014 doi: 10.3969/j.issn.1673-6338.2020.06.014
[31]	刘慧, 崔虎平, 韦原原, 等. 基于时空对象的高铁网络建模方法[J]. 测绘科学技术学报, 2021, 38(1):104-110.
	[Liu H, Cui H P, Wei Y Y, et al. High-speed network modeling method based on spatio-temporal objects[J]. Journal of Geomatics Science and Technology, 2021, 38(1):104-110. ] DOI:10.3969/j.issn.1673-6338.2021.01.017 doi: 10.3969/j.issn.1673-6338.2021.01.017
[32]	张永树, 华一新, 张毅, 等. 人际关系网络对象化时空建模方法研究[J]. 测绘与空间地理信息, 2021, 44(6):41-45,53.
	[Zhang Y S, Hua Y X, Zhang Y, et al. Research on object-oriented spatio-temporal modeling of interpersonal relationship network[J]. Geomatics ＆ Spatial Information Technology, 2021, 44(6):41-45,53. ] DOI:10.3969/j.issn.1672-5867.2021.06.012 doi: 10.3969/j.issn.1672-5867.2021.06.012
[33]	陈敏颉, 江南, 陈达. 多粒度时空事件建模与可视化方法初探[J]. 地理信息世界, 2018, 25(2):30-35.
	[Chen M J, Jiang N, Chen D. Study on spatio-temporal events of multi-granularity modeling and visualization methods[J]. Geomatics World, 2018, 25(2):30-35. ] DOI:10.3969/j.issn.1672-1586.2018.02.006 doi: 10.3969/j.issn.1672-1586.2018.02.006
[34]	郭玥晗, 江南, 曹一冰, 等. 多粒度时空对象的校史信息可视化研究[J]. 测绘科学, 2021, 46(10):145-150.
	[Guo Y H, Jiang N, Cao Y B, et al. Research on the visualization of school history information based on multi-granularity spatio-temporal objects[J]. Science of Surveying and Mapping, 2021, 46(10):145-150. ] DOI:10.16251/j.cnki.1009-2307.2021.10.019 doi: 10.16251/j.cnki.1009-2307.2021.10.019
[35]	谢雨芮, 江南, 赵文双, 等. 基于多粒度时空对象的作战实体对象化建模研究[J]. 地球信息科学学报, 2021, 23(1):84-92. doi: 10.12082/dqxxkx.2021.200418
	[Xie Y R, Jiang N, Zhao W S, et al. Object modeling of combat entities based on multi-granularity spatio-temporal objects[J]. Journal of Geo-information Science, 2021, 23(1):84-92. ] DOI:10.12082/dqxxkx.2021.200418 doi: 10.12082/dqxxkx.2021.200418
[36]	张正方, 闫振军, 王增杰, 等. 基于Bayes网络的多粒度时空对象地理过程演化建模——以新安江模型为例[J]. 地球信息科学学报, 2021, 23(1):124-133. doi: 10.12082/dqxxkx.2021.200426
	[Zhang Z F, Yan Z J, Wang Z J, et al. Modeling of geographical process evolution of spatio-temporal objects of multi-granularity based on Bayesian network: A case study of the Xin'an Jiang model[J]. Journal of Geo-information Science, 2021, 23(1):124-133. ] DOI:10.12082/dqxxkx.2021.200426 doi: 10.12082/dqxxkx.2021.200426
[37]	Chen Y H, Jiang N, Cao Y B, et al. Visual method of analyzing COVID-19 case information using spatio-temporal objects with multi-granularity[J]. Journal of Geographical Sciences, 2021, 31(7):1059-1081. DOI:10.1007/s11442-021-1885-1 doi: 10.1007/s11442-021-1885-1
[38]	陈达, 苏亚龙, 崔虎平. 全空间信息系统中对象的时空内涵与特征[J]. 测绘与空间地理信息, 2019, 42(1):52-55.
	[Chne D, Su Y L, Cui H P. Temporal and spatial connotation and characteristics of entities in pan-spatial information system[J]. Geomatics & Spatial Information Technology, 2019, 42(1):52-55. ] DOI:10.3969/j.issn.1672-5867.2019.01.015 doi: 10.3969/j.issn.1672-5867.2019.01.015
[39]	陈祥葱, 张树清, 丁小辉, 等. 时空参考框架普适化表达[J]. 地球信息科学学报, 2017, 19(9):1201-1207. doi: 10.3724/SP.J.1047.2017.01201
	[Chen X C, Zhang S Q, Ding X H, et al. An exploratory study on ubiquitous representation of spatial-temporal reference framework[J]. Journal of Geo-information Science, 2017, 19(9):1201-1207. ] DOI:10.3724/SP.J.1047.2017.01201 doi: 10.3724/SP.J.1047.2017.01201
[40]	方裕, 周成虎, 景贵飞, 等. 第四代GIS软件研究[J]. 中国图象图形学报, 2001, 6(9):817-823.
	[Fang Y, Zhou C H, Jing G F, et al. Research of 4th generation GIS software[J]. Journal of Image and Graphics, 2001, 6(9):817-823. ] DOI:10.3969/j.issn.1006-8961.2001.09.001 doi: 10.3969/j.issn.1006-8961.2001.09.001
[41]	邬伦, 王晓明, 高勇, 等. 基于地理认知的GIS数据元模型研究[J]. 遥感学报, 2005, 9(5):583-588.
	[Wu L, Wang X M, Gao Y, et al. Research on GIS data meta-model based upon geographical cognition[J]. Journal of Remote Sensing, 2005, 9(5):583-588. ] DOI:10.11834/jrs.20050585 doi: 10.11834/jrs.20050585
[42]	李淑霞, 安敏, 李宏伟, 等. 常识空间认知研究与地名本体设计[J]. 测绘科学技术学报, 2011, 28(6):450-453.
	[Li S X, An M, Li H W, et al. Design of the ontology of place based on commonsense spatial cognition[J]. Journal of Geomatics Science and Technology, 2011, 28(6):450-453. ] DOI:10.3969/j.issn.1673-6338.2011.06.015 doi: 10.3969/j.issn.1673-6338.2011.06.015
[43]	曾梦熊, 华一新, 张江水, 等. 多粒度时空对象动态行为表达模型与方法研究[J]. 地球信息科学学报, 2021, 23(1):104-112. doi: 10.12082/dqxxkx.2021.200420
	[Zeng M X, Hua Y X, Zhang J S, et al. Research on dynamic behavior expression model and method of multi-granularity spatio-temporal objects[J]. Journal of Geo-information Science, 2021, 23(1):104-112. ] DOI:10.12082/dqxxkx.2021.200420 doi: 10.12082/dqxxkx.2021.200420
[44]	曾梦熊, 华一新, 张政, 等. 面向大规模空间Agent建模的分布式地理模拟框架[J]. 地球信息科学学报, 2022, 24(5):815-826. doi: 10.12082/dqxxkx.2022.220001
	[Zeng M X, Hua Y X, Zhang Z, et al. A distributed geospatial simulation framework for massive spatial agent-based modeling[J]. Journal of Geo-information Science, 2022, 24(5):815-826. ] DOI:10.12082/dqxxkx.2022.220001 doi: 10.12082/dqxxkx.2022.220001
[45]	华一新, 张江水, 曹一冰. 基于时空域的全空间数字世界时空对象组织与管理研究[J]. 地球信息科学学报, 2021, 23(1):76-83. doi: 10.12082/dqxxkx.2021.200417
	[Hua Y X, Zhang J S, Cao Y B. Research on organization and management of spatio-temporal objects in pan-spatial digital world based on spatio-temporal domain[J]. Journal of Geo-information Science, 2021, 23(1):76-83. ] DOI:10.12082/dqxxkx.2021.200417 doi: 10.12082/dqxxkx.2021.200417

	基本内容	内容描述	例外情况
研究对象	描述地理世界的数据	矢量、栅格数据为核心的地理空间数据	3D模型、点云、BIM等作为分离数据类型
基本原理	描述地理世界的原理	矢量、栅格数据模型	在数据结构上适当调整以适应新的应用需要
基本原理	认知地理世界的原理	基于矢量、栅格数据的分析和可视化	在数据结构上适当调整以适应新的应用需要
技术方法	地理空间数据技术	获取、处理、管理、分析、可视化	以矢量、栅格技术为核心，不断修补以兼容新数据类型

	基本内容	内容描述	范式进阶内容
研究对象	描述现实世界的数据	多粒度时空对象数据	①时空范畴扩展：由地理世界到现实世界 ②对象内涵扩展：GIS数据是多粒度时空对象的部分内容
基本原理	描述现实世界的原理	多粒度时空对象数据模型	①数据模型进阶：更全面、更动态、更关联、可演化地描述现实世界，多粒度时空对象数据模型包含GIS数据模型的信息内容 ②认知方式进阶：通过由多粒度时空对象组成的全空间数字世界认知现实世界
基本原理	认知现实世界的原理	全空间数字世界的交互、分析与可视化
技术方法	多粒度时空对象数据技术	获取、处理、管理、分析、可视化	新一代空间信息系统技术体系： ①面向时空对象的泛在时空数据获取与建模技术 ②时空实体数据整合与融合处理技术 ③面向时空对象的管理与共享技术 ④多粒度时空对象时空分析推演技术 ⑤时空场景可视化与交互技术
