地理数据空间本体构建及其在数据检索中的应用

doi:10.3724/SP.J.1047.2016.00443

地球信息科学学报 ›› 2016, Vol. 18 ›› Issue (4): 443-452.doi: 10.3724/SP.J.1047.2016.00443

地理数据空间本体构建及其在数据检索中的应用

王东旭^1,²(), 诸云强^1,^3,*^*(), 潘鹏¹, 罗侃^1,², 侯志伟^1,²

1. 中国科学院地理科学与资源研究所资源与环境信息系统国家重点实验室,北京 100101
2. 中国科学院大学,北京 100049
3. 江苏省地理信息资源开发与利用协同创新中心,南京 210023

收稿日期:2015-05-22 修回日期:2015-09-10 出版日期:2016-04-20 发布日期:2016-04-19
作者简介:
作者简介:王东旭(1990-),男,湖北仙桃人,硕士生,研究方向为地学数据共享和地理信息技术与应用。E-mail: wang_dongxu23@163.com
基金资助:
国家自然科学基金项目“基于元数据语义的地理空间数据关联方法研究”(41371381);科技基础性工作专项重点项目“科技基础性工作数据资料集成与规范化整编”(2013FY110900);国家科技基础条件平台——地球系统科学数据共享平台(2005DKA32300)

Construction of Geodata Spatial Ontology and Its Application in Data Retrieval

WANG Dongxu^1,²(), ZHU Yunqiang^1,^3,^*(), PAN Peng¹, LUO Kan^1,², HOU Zhiwei^1,²

1. State Key Laboratory of Resources and Environmental Information System, Institute of Geographic Sciences and Natural Resources Research,CAS, Beijing 100101, China
2. University of Chinese Academy of Sciences, Beijing 100049, China
3. Jiangsu Center for Collaborative Innovation in Geographical Information Resource Development and Application Nanjing 210023, China

Received:2015-05-22 Revised:2015-09-10 Online:2016-04-20 Published:2016-04-19
Contact: ZHU Yunqiang

摘要/Abstract

摘要：

随着新地理信息时代的来临,地理数据已经呈现出爆炸式增长的趋势。如何在海量的地理数据中准确、及时地找到人们所需要的数据,并把相关联的数据智能地推荐给用户,成为亟待解决的一大难题。针对传统以关键词、主题词等字符串匹配为核心的数据发现方法存在的查不全、查不准的问题,本文通过对地理空间中的概念、属性、关系、规则,以及相应实例的详细表达,初步提出了地理空间本体构建框架,并在此基础上构建了较为完整的地理数据空间本体,以实现地理数据的智能关联,最后在地球系统科学数据共享平台中进行应用实践。结果表明,引入地理数据空间本体后,检索的结果在数据的查全和查准方面显著提高,而且还能智能推荐相关联的数据信息。本文构建的地理数据空间本体对于大数据时代背景下地理数据的精确发现和共享有重要意义。

关键词: 地理数据, 空间本体, 数据检索, 数据共享

Abstract:

Geodata has been increasing at a tremendous speed in what we call the new era of Geographic Information. It is a challenge to accurately find the needed data in a real-time fashion amongst the massive spatial data and to recommend the associated required data intelligently to users. In light of the problem that the data retrieval by traditional searching methods based on keywords and topic words cannot satisfy the real needs emerged in the geoscience research, this study built a Geodata Spatial-Ontology Model through a detailed expression of the concepts, characteristics, relationship and instances of spatial data. In addition, this article presents the qualitative and quantitative spatial relationship, which plays an inestimable role in describing the inner connection between spatial objects. Then a Geodata Spatial-Ontology is built according to the Geodata Spatial-Ontology Model, and most of the concepts, instances and the relationship between them are elaborated. At the end of this paper, an application has been developed to parse the ontology and extract the semantic information using Apache Jena, which is a free and open source Java framework designed to build the Semantic Web and linked data applications. By associating the Geodata Spatial-Ontology with the Data Sharing Infrastructure of Earth System Science, the experiment in this research proves that the proposed ontology shows a significant improvement in data discovery. The Geodata Spatial Ontology constructed in this paper will have an important significance to the accurate data discovery and data sharing in the era of big data.

Key words: geodata, spatial ontology, data retrieval, data sharing

王东旭, 诸云强, 潘鹏, 罗侃, 侯志伟. 地理数据空间本体构建及其在数据检索中的应用[J]. 地球信息科学学报, 2016, 18(4): 443-452.DOI:10.3724/SP.J.1047.2016.00443

WANG Dongxu,ZHU Yunqiang,PAN Peng,LUO Kan,HOU Zhiwei. Construction of Geodata Spatial Ontology and Its Application in Data Retrieval[J]. Journal of Geo-information Science, 2016, 18(4): 443-452.DOI:10.3724/SP.J.1047.2016.00443

图/表 8

图1

图2

图3

图4

图5

图6

图7

表1

参考文献 29

[1]	李军,周成虎.地学数据特征分析[J].地理科学,1999,19(2):158-162. doi: 10.3969/j.issn.1000-0690.1999.02.013
	[ Li J,Zhou C H.Analysis on the characteristics of geospatial data[J]. Scientia Geographica Sinica,1999,19(2):158-162. ] doi: 10.3969/j.issn.1000-0690.1999.02.013
[2]	宋佳,王卷乐,诸云强,等.基于地理空间本体的语义检索相关度研究[J].计算机工程与应用,2011(5):114-117. doi: 10.3778/j.issn.1002-8331.2011.05.035
	[ Song J, Wang J L, Zhu Y Q, et al.Research on relevancy for semantic retrieval based on geographic spatio-ontology[J]. Computer Engineering and Application, 2011,5:114-117. ] doi: 10.3778/j.issn.1002-8331.2011.05.035
[3]	Gruber T R.Toward principles for the design of ontologies used for knowledge sharing[J]. International Journal of Human and Computer Studies, 1995,43(5):907-928. doi: 10.1006/ijhc.1995.1081
[4]	闵敏,谭传凤,蒋玲,等.地理时空本体研究进展[J].华中师范大学学报(自然科学版),2006,40(1):132-137. doi: 10.3321/j.issn:1000-1190.2006.01.034
	[ Min M, Tan C F, Jiang L, et al.Research progress in geographical spatio-temporal ontologies[J]. Journal of Central China Normal University( Nat. Sci. ), 2006,40(1):132-137. ] doi: 10.3321/j.issn:1000-1190.2006.01.034
[5]	邓世鸿,唐世渭,张铭,等.Ontology 研究综述[J].北京大学学报(自然科学版),2002,38(5):730-738.
	[ Deng S H, Tang S W, Zhang M, et al.Overview of ontology[J]. Journal of Peking University (natural science edition) ,2002,38(5):730-738. ]
[6]	Gruber T R.A translation approach to portable ontology specifications[J]. Knowledge Acquisition,1993,5:199-220. doi: 10.1006/knac.1993.1008
[7]	Maedche A, Staab S.Ontology learning for the semantic web[J]. IEEE Intelligent Systems & Their Applications,2001,16(2):72-79. doi: 10.1109/5254.920602
[8]	Eilbeck K, Lewis S E, Mungall C J, et al.The sequence ontology: a tool for the unification of genome annotations[J]. Genome Biology, 2005,6(5):1465-1497. doi: 10.1186/gb-2005-6-5-r44 pmid: 1175956
[9]	Arpinar B, Sheth A, Ramakrishman C.Geospatial ontology development and semantic analytics[J]. Transactions in GIS,2006,10(4):551-575. doi: 10.1016/j.neulet.2005.04.024
[10]	景东升. 基于本体的地理空间信息语义表达和服务研究[D].北京:中国科学院遥感应用研究所,2005.
	[ Jing D S.A research on geo-spatial information semantic expression and service based on ontology[J]. Beijing: Institute of Remote Sensing Applications, Chinese Academy of Sciences, 2005. ]
[11]	宋佳,诸云强,王卷乐,等.基于GML的时空地理本体模型构建及应用研究[J].地球信息科学学报,2009,11(4):442-451. doi: 10.3969/j.issn.1560-8999.2009.04.006
	[ Song J, Zhu Y Q, Wang J L.A Study on the model of Spatio-temporal Geo-ontology based on GML[J]. Journal of Geo-information Science, 2009,11(4):442-451. ] doi: 10.3969/j.issn.1560-8999.2009.04.006
[12]	Vandecasteele A, Napoli A.Spatial ontologies for detecting abnormal maritime behavior[J]. Oceans,2012,5(1):1-7.
[13]	马胜男,孙翊,郭明明.SWEET本体研究述评[J].标准科学,2010(9):38-43. doi: 10.3969/j.issn.1674-5698.2010.09.009
	[ Ma S N, Sun Y, Guo M M.Review of sweet ontology[J]. Standard Science, 2010,9:38-43. ] doi: 10.3969/j.issn.1674-5698.2010.09.009
[14]	曹泽文,李立人,邓苏.战场空间本体构建方法研究[J].火力与指挥控制,2008,33(6):22-25. doi: 10.3969/j.issn.1002-0640.2008.06.006
	[ Cao Z W, Li L R, Deng S.Research on battle-space ontologies construction method[J]. Fire and Command Cntrol, 2008,33(6):22-25. ] doi: 10.3969/j.issn.1002-0640.2008.06.006
[15]	杜萍. 基于本体的中国行政区划地名识别与抽取研究[D].兰州:兰州大学,2011.
	[ Du P.Study on the ontology-based extraction of the names of chinese administrative division[D]. Lanzhou: Lanzhou University, 2011. ]
[16]	李淑霞. 地名本体及其在地理空间数据组织中的应用研究[D].郑州:解放军信息工程大学,2009.
	[ Li S X.Research on ontology of place and its applications in geospatial data organization[D]. Zhengzhou: The PLA Information Engineering University, 2009. ]
[17]	Pais J, Pinto-Ferreira C.Search strategies for reasoning about spatial ontologies[C]. Tools with Artificial Intelligence, Proceedings Tenth IEEE International Conference,1998:418-422.
[18]	潘燕群,刘小生.地理本体中空间关系的表达和推理研究[D].南昌:江西理工大学,2008.
	[ Pan Y Q, Liu X S.Research on the representation and reasoning of spatial relations in geographical ontology[D]. Nanchang: Institutes of Technology of Jiangxi, 2008. ]
[19]	黄卿贤,胡谷雨,王立峰.本体的概念、建模与应用[J].解放军理工大学学报(自然科学版),2005,6(2):123-126. doi: 10.3969/j.issn.1009-3443.2005.02.005
	[ Huang Q X, Hu G Y, Wang L F.Concept, modeling and application of ontology[J]. Journal of PLA University of Science and Technology (NATURAL SCIENCE EDITION), 2005,6(2):123-126. ] doi: 10.3969/j.issn.1009-3443.2005.02.005
[20]	Perez A G, Benjamins V R.Overview of knowledge sharing and reuse components: Ontologies and problem-solving methods[R]. Workshop on ontologies and problem-solving methods: lessons learned and future trends (IJCAI99) , deAgosto, Estocolmo, 1999.
[21]	黄茂军. 地理本体的形式化表达机制及其在地图服务中的应用研究[D].武汉:武汉大学,2005.
	[ Huang M J.Study on formal representation of geographic ontolpgy and its application in map services[D]. Wuhan: Wuhan University, 2005. ]
[22]	易茹兰. 基于地理本体的地理信息予以表达与查询方法研究[D].长沙:中南大学,2009.
	[ Yi R L.Research on methods of semantic representation and query of geographic information via geo-ontology[D]. Changsha: Central South University, 2009. ]
[23]	贾黎莉. Ontology构建中概念间关系的研究[D].北京:中国农业科学院,2007.
	[ Jia L L.The study of concept-to-concept relations in ontology construction[D]. Beijing:Chinese Academy of Agricultural Sciences Master Dissertation, 2007. ]
[24]	杜世宏,秦其明,王桥.空间关系及其应用[J].地学前缘,2006,13(3):69-80. doi: 10.3321/j.issn:1005-2321.2006.03.010
	[ Du S H, Qin Q M, Wang J.The spatial relations in GIS and their applications[J]. Earth Science Frontiers, 2006,13(3):69-80. ] doi: 10.3321/j.issn:1005-2321.2006.03.010
[25]	郭庆胜,郑春燕.锥形空间方向关系模型的改进[J].武汉大学学报(信息科学版),2007,32(1):81-84. doi: 10.3321/j.issn:1671-8860.2007.01.021
	[ Guo Q S, Zheng C Y.Improvement of cone-Shaped spatial direction-relation model[J]. Geomatics and Information Science of Wuhan University, 2007,32(1):81-84. ] doi: 10.3321/j.issn:1671-8860.2007.01.021
[26]	王中辉,闫浩文.一种改进的锥形方向关系模型[J].武汉大学学报(信息科学版),2014,39(2):186-190. doi: 10.13203/j.whugis20120688
	[ Wang Z H, Yan H W.An improved cone-based model for decribling spatial direction relations[J]. Geomatics and Information Science of Wuhan University, 2014,39(2):186-190. ] doi: 10.13203/j.whugis20120688
[27]	曹菡,陈军.方向关系与距离关系的定性描述与推理[J].西安石油学院学报(自然科学版),2001,16(1):68-72. doi: 10.3969/j.issn.1673-064X.2001.01.017
	[ Cao H, Chen J.Qualitative description and reasoning of spatial distance and direction[J]. Journal of Xi’an Petroleum Institute (Natural Science Edition), 2001,16(1):68-72. ] doi: 10.3969/j.issn.1673-064X.2001.01.017
[28]	Liu Y, Wang X, JinX, et al. Oninternalcardinal directionrelations[A]. In: Spatial Information Theory: Cognitive and Computational Foundations[M]. Proceedings of COSIT'05, 2005:283-299.
[29]	郭杨,等.地理科学叙词表[M].北京:科学出版社,1995.
	[ Guo Y, et al.Geography science thesaurus[M]. Beijing: Science Press, 1995. ]

序号	检索词汇	数据库中相关数据	关键词检索					地理空间数据本体检索
序号	检索词汇	数据库中相关数据	检索结果总数		检索结果相关数	查全率/（%）	查准率/（%）	检索结果总数	检索结果相关数	查全率/(%)	查准率/(%)
1	华北地区	7	5	2	28.6	40.0		9	7	100	77.8
2	华东地区	21	4	1	4.7	25.0		29	21	100	72.4
3	黄河流域	18	17	8	44.4	47.1		23	18	100	78.3
4	一级流域	48	38	29	60.4	76.3		71	48	100	67.6
5	太湖	18	13	10	55.6	76.9		26	18	100	69.2
6	东北平原	12	11	6	50.0	54.5		19	12	100	63.2
7	青藏高原	35	37	22	62.9	59.5		42	35	100	83.3
8	南海	33	18	13	39.4	72.2		48	33	100	68.8
