顾及土地利用动态变化的滑坡易发性评估方法

doi:10.12082/dqxxkx.2023.220567

Abstract

Abstract:

The causes of landslide disasters are complex, and landslide susceptibility assessment is of great significance for disaster warning, prevention, and control management. In the previous mapping studies on landslide susceptibility assessment, land use change factor was not considered. This paper proposed a combination of factors for landslide susceptibility assessment by considering land use dynamic change factor. The landslide frequency ratio was used to quantitatively measure the correlation between land use change and landslide development. And Logistic Regression (LR) model was used to compare the prediction ability of the model before and after the introduction of land use change factor. We constructed three machine learning models: Decision Tree (DT), Gradient Boosting Decision Tree (GBDT), and Random Forest (RF). We used AUC and other indicators to compare model performance. Finally, we took Sanming City of Fujian Province as the study area and the whole Fujian Province as the verification area to conduct the landslide susceptibility assessment research. The results show that there is a strong correlation between land use change factor and landslide development. The inclusion of land use change factor improves model prediction accuracy, which indicates that it is necessary to introduce dynamic factor in the assessment of landslide susceptibility. The verification results show that RF model has higher prediction accuracy than DT and GBDT. The high landslide prone areas are mainly distributed in the west and central of Sanming City, where the land use change degree is high, and the impact of human activities is great. The low landslide prone areas basically locate in the high-altitude areas with little influence of human activities. This study provides a new research perspective for landslide susceptibility assessment and helps to explore the impact of human activities on disaster formation.

Key words: landslide, susceptibility, land use change, ensemble learning, decision tree, gradient boosting decision tree, random forest, Sanming

LIN Xuanxin, XIAO Guirong, ZHOU Houbo. Landslide Susceptibility Assessment Method Considering Land Use Dynamic Change[J].Journal of Geo-information Science, 2023, 25(5): 953-966.DOI:10.12082/dqxxkx.2023.220567

Figures/Tables 16

Fig. 1

Fig. 2

Tab. 1

Fig. 3

Tab. 2

Tab. 3

Fig. 4

Tab. 4

Tab. 5

Tab. 6

Tab. 7

Fig. 5

Fig. 6

Tab. 8

Tab. 9

Tab. 10

References 45

[1]	杨城, 林广发, 张明锋, 等. 基于DEM的福建省土质滑坡敏感性评价[J]. 地球信息科学学报, 2016, 18(12):1624-1633. doi: 10.3724/SP.J.1047.2016.01624
	[ Yang C, Lin G F, Zhang M F, et al. Soil landslide susceptibility assessment based on DEM[J]. Journal of Geo-Information Science, 2016, 18(12):1624-1633. ] DOI:10.3724/SP.J.1047.2016.01624 doi: 10.3724/SP.J.1047.2016.01624
[2]	黄发明, 殷坤龙, 蒋水华, 等. 基于聚类分析和支持向量机的滑坡易发性评价[J]. 岩石力学与工程学报, 2018, 37(1):156-167.
	[ Huang F M, Yin K L, Jiang S H, et al. Landslide susceptibility assessment based on clustering analysis and support vector machine[J]. Chinese Journal of Rock Mechanics and Engineering, 2018, 37(1):156-167. ] DOI:10.13722/j.cnki.jrme.2017.0824 doi: 10.13722/j.cnki.jrme.2017.0824
[3]	黄发明, 陈佳武, 唐志鹏, 等. 不同空间分辨率和训练测试集比例下的滑坡易发性预测不确定性[J]. 岩石力学与工程学报, 2021, 40(6):1155-1169.
	[ Huang F M, Chen J W, Tang Z P, et al. Uncertainties of landslide susceptibility prediction due to different spatial resolutions and different proportions of training and testing datasets[J]. Chinese Journal of Rock Mechanics and Engineering, 2021, 40(6):1155-1169. ] DOI:10.13722/j.cnki.jrme.2020.1119 doi: 10.13722/j.cnki.jrme.2020.1119
[4]	刘艳辉, 方然可, 苏永超, 等. 基于机器学习的区域滑坡灾害预警模型研究[J]. 工程地质学报, 2021, 29(1):116-124.
	[ Liu Y H, Fang R K, Su Y C, et al. Machine learning based model for warning of regional landslide disasters[J]. Journal of Engineering Geology, 2021, 29(1):116-124. ] DOI:10.13544/j.cnki.jeg.2020-533 doi: 10.13544/j.cnki.jeg.2020-533
[5]	Dou J, Yunus A P, Tien B D, et al. Assessment of advanced random forest and decision tree algorithms for modeling rainfall-induced landslide susceptibility in the Izu-Oshima Volcanic Island, Japan[J]. Science of the Total Environment, 2019, 662:332-346. DOI:10.1016/j.scitotenv.2019.01.221 doi: 10.1016/j.scitotenv.2019.01.221
[6]	Liu Z Q, Gilbert G, Cepeda J M, et al. Modelling of shallow landslides with machine learning algorithms[J]. Geoscience Frontiers, 2021, 12(1):385-393. DOI:10.1016/j.gsf.2020.04.014 doi: 10.1016/j.gsf.2020.04.014
[7]	Pham B T, Pradhan B, Tien B D, et al. A comparative study of different machine learning methods for landslide susceptibility assessment: A case study of Uttarakhand area (India)[J]. Environmental Modelling & Software, 2016, 84:240-250. DOI:10.1016/j.envsoft.2016.07.005 doi: 10.1016/j.envsoft.2016.07.005
[8]	张洪吉, 赵铮, 陈建华, 等. 面向滑坡危险性评价的深度一维卷积神经网络方法——以四川省芦山县为例[J]. 自然灾害学报, 2021, 30(3):191-198.
	[ Zhang H J, Zhao Z, Chen J H, et al. A deep one-dimensional convolutional neural network method for landslide risk assessment: A case study in Lushan, Sichuan, China[J]. Journal of Natural Disasters, 2021, 30(3):191-198. ] DOI:10.13577/j.jnd.2021.0321 doi: 10.13577/j.jnd.2021.0321
[9]	Wang D, Hao M M, Chen S, et al. Assessment of landslide susceptibility and risk factors in China[J]. Natural Hazards, 2021, 108(3):3045-3059. DOI:10.1007/s11069-021-04812-8 doi: 10.1007/s11069-021-04812-8
[10]	Sur U, Singh P, Meena S R. Landslide susceptibility assessment in a lesser Himalayan Road corridor (India) applying fuzzy AHP technique and earth-observation data[J]. Geomatics, Natural Hazards and Risk, 2020, 11(1):2176-2209. DOI:10.1080/19475705.2020.1836038 doi: 10.1080/19475705.2020.1836038
[11]	纪秋磊, 梁伟, 傅伯杰, 等. 基于Google Earth Engine平台与复杂网络的黄河流域土地利用/覆被变化分析[J]. 生态学报, 2022, 42(6):2122-2135.
	[ Ji Q L, Liang W, Fu B J, et al. Land use/cover change in the Yellow River Basin based on Google Earth Engine and complex network[J]. Acta Ecologica Sinica, 2022, 42(6):2122-2135. ]
[12]	王思, 张路路, 林伟彪, 等. 基于MODIS-归一化植被指数的广东省植被覆盖与土地利用变化研究[J]. 生态学报, 2022, 42(6):2149-2163.
	[ Wang S, Zhang L L, Lin W B, et al. Study on vegetation coverage and land-use change of Guangdong Province based on MODIS-NDVI[J]. Acta Ecologica Sinica, 2022, 42(6):2149-2163. ] DOI:10.5846/stxb202104261100 doi: 10.5846/stxb202104261100
[13]	乔治, 蒋玉颖, 贺曈, 等. 土地利用变化模拟研究进展[J]. 生态学报, 2022(13):5165-5176.
	[ Qiao Z, Jiang Y Y, He T, et al. Land use change simulation: Progress, challenges, and prospects[J]. Acta Ecologica Sinica, 2022(13):5165-5176. ]
[14]	Pisano L, Zumpano V, Malek Ž, et al. Variations in the susceptibility to landslides, as a consequence of land cover changes: A look to the past, and another towards the future[J]. Science of the Total Environment, 2017, 601/602:1147-1159. DOI:10.1016/j.scitotenv.2017.05.231 doi: 10.1016/j.scitotenv.2017.05.231
[15]	Chen L X, Guo Z Z, Yin K L, et al. The influence of land use and land cover change on landslide susceptibility: A case study in Zhushan Town, Xuan'en County (Hubei, China)[J]. Natural Hazards and Earth System Sciences, 2019, 19(10):2207-2228. DOI:10.5194/nhess-19-2207-2019 doi: 10.5194/nhess-19-2207-2019
[16]	Liu J, Wu Z, Zhang H W. Analysis of changes in landslide susceptibility according to land use over 38 years in Lixian County, China[J]. Sustainability, 2021, 13(19):10858. DOI:10.3390/su131910858 doi: 10.3390/su131910858
[17]	Persichillo M G, Bordoni M, Meisina C. The role of land use changes in the distribution of shallow landslides[J]. Science of the Total Environment, 2017, 574:924-937. DOI:10.1016/j.scitotenv.2016.09.125 doi: 10.1016/j.scitotenv.2016.09.125
[18]	Reichenbach P, Busca C, Mondini A C, et al. The influence of land use change on landslide susceptibility zonation: The briga catchment test site (Messina, Italy)[J]. Environmental Management, 2014, 54(6):1372-1384. DOI:10.1007/s00267-014-0357-0 doi: 10.1007/s00267-014-0357-0 pmid: 25164982
[19]	叶润青, 李士垚, 郭飞, 等. 基于RS和GIS的三峡库区滑坡易发程度与土地利用变化的关系研究[J]. 工程地质学报, 2021, 29(3):724-733.
	[ Ye R Q, Li S Y, Guo F, et al. RS and GIS analysis on relationship between landslide susceptibility and land use change in Three Gorges Reservoir area[J]. Journal of Engineering Geology, 2021, 29(3):724-733. ] DOI:10.13544/j.cnki.jeg.2020-076 doi: 10.13544/j.cnki.jeg.2020-076
[20]	Rabby Y W, Li Y K, Abedin J, et al. Impact of land use/land cover change on landslide susceptibility in rangamati municipality of rangamati district, Bangladesh[J]. ISPRS International Journal of Geo-Information, 2022, 11(2):89. DOI:10.3390/ijgi11020089 doi: 10.3390/ijgi11020089
[21]	Sur U, Singh P, Rai P K, et al. Landslide probability mapping by considering fuzzy numerical risk factor (FNRF) and landscape change for road corridor of Uttarakhand, India[J]. Environment, Development and Sustainability, 2021, 23(9):13526-13554. DOI:10.1007/s10668-021-01226-1 doi: 10.1007/s10668-021-01226-1
[22]	Bourenane H, Bouhadad Y. Impact of land use changes on landslides occurrence in urban area: The case of the constantine city (NE Algeria)[J]. Geotechnical and Geological Engineering, 2021, 39(6):1-21. DOI:10.1007/s10706-021-01768-1 doi: 10.1007/s10706-021-01768-1
[23]	Soma A S, Kubota T, Aditian A. Comparative study of land use change and landslide susceptibility using frequency ratio, certainty factor, and logistic regression in upper area of Ujung-loe watersheds south Sulawesi Indonesia[J]. International Journal of Erosion Control Engineering, 2019, 11(4):103-115. DOI:10.13101/ijece.11.103 doi: 10.13101/ijece.11.103
[24]	李远远, 梅红波, 任晓杰, 等. 基于确定性系数和支持向量机的地质灾害易发性评价[J]. 地球信息科学学报, 2018, 20(12):1699-1709. doi: 10.12082/dqxxkx.2018.180349
	[ Li Y Y, Mei H B, Ren X J, et al. Geological disaster susceptibility evaluation based on certainty factor and support vector machine[J]. Journal of Geo-Information Science, 2018, 20(12):1699-1709. ] DOI:10.12082/dqxxkx.2018.180349 doi: 10.12082/dqxxkx.2018.180349
[25]	许冲, 戴福初, 姚鑫, 等. GIS支持下基于层次分析法的汶川地震区滑坡易发性评价[J]. 岩石力学与工程学报, 2009, 28(S2):3978-3985.
	[ Xu C, Dai F C, Yao X, et al. GIS-based landslide susceptibility assessment using analytical hierarchy process in Wenchuan earthquake region[J]. Chinese Journal of Rock Mechanics and Engineering, 2009, 28(S2):3978-3985. ]
[26]	许冲, 戴福初, 姚鑫, 等. 基于GIS与确定性系数分析方法的汶川地震滑坡易发性评价[J]. 工程地质学报, 2010, 18(1):15-26.
	[ Xu C, Dai F C, Yao X, et al. GIS platform and certainty factor analysis method based Wenchuan earthquake-induced landslide susceptibility evaluation[J]. Journal of Engineering Geology, 2010, 18(1):15-26. ]
[27]	杨华阳, 许向宁, 杨鸿发. 基于证据权法的九寨沟地震滑坡危险性评价[J]. 中国地质灾害与防治学报, 2020, 31(3):20-29.
	[ Yang H Y, Xu X N, Yang H F. The Jiuzhaigou co-seismic landslide hazard assessment based on weight of evidence method[J]. The Chinese Journal of Geological Hazard and Control, 2020, 31(3):20-29. ] DOI:10.16031/j.cnki.issn.1003-8035.2020.03.03 doi: 10.16031/j.cnki.issn.1003-8035.2020.03.03
[28]	张俊, 殷坤龙, 王佳佳, 等. 三峡库区万州区滑坡灾害易发性评价研究[J]. 岩石力学与工程学报, 2016, 35(2):284-296.
	[ Zhang J, Yin K L, Wang J J, et al. Evaluation of landslide susceptibility for Wanzhou District of Three Gorges Reservoir[J]. Chinese Journal of Rock Mechanics and Engineering, 2016, 35(2):284-296. ] DOI:10.13722/j.cnki.jrme.2015.0318 doi: 10.13722/j.cnki.jrme.2015.0318
[29]	田乃满, 兰恒星, 伍宇明, 等. 人工神经网络和决策树模型在滑坡易发性分析中的性能对比[J]. 地球信息科学学报, 2020, 22(12):2304-2316. doi: 10.12082/dqxxkx.2020.190766
	[ Tian N M, Lan H X, Wu Y M, et al. Performance comparison of BP artificial neural network and CART decision tree model in landslide susceptibility prediction[J]. Journal of Geo-Information Science, 2020, 22(12):2304-2316. ]
[30]	Pourghasemi H R, Sadhasivam N, Amiri M, et al. Landslide susceptibility assessment and mapping using state-of-the art machine learning techniques[J]. Natural Hazards, 2021, 108(1):1291-1316. DOI:10.1007/s11069-021-04732-7 doi: 10.1007/s11069-021-04732-7
[31]	Wei A H, Yu K N, Dai F G, et al. Application of tree-based ensemble models to landslide susceptibility mapping: A comparative study[J]. Sustainability, 2022, 14(10):6330. DOI:10.3390/su14106330 doi: 10.3390/su14106330
[32]	王世宝, 庄建琦, 樊宏宇, 等. 基于频率比与集成学习的滑坡易发性评价——以金沙江上游巴塘—德格河段为例[J]. 工程地质学报, 2022, 30(3):817-828.
	[ Wang S B, Zhuang J Q, Fan H Y, et al. Evaluation of landslide susceptibility based on frequency ratio and ensemble learning—Taking the Batang-Dege section in the upstream of Jinsha River as an example[J]. Journal of Engineering Geology, 2022, 30(3):817-828. ] DOI:10.13544/j.cnki.jeg.2020-639 doi: 10.13544/j.cnki.jeg.2020-639
[33]	梁柱. 机器学习在浅层滑坡敏感性评价中的综合应用与研究[D]. 长春: 吉林大学, 2021.
	[ Liang Z. Comprehensive application and study of machine learning in susceptibility evaluation of shallow landslides[D]. Changchun: Jilin University, 2021. ]
[34]	牛全福, 冯尊斌, 党星海, 等. 黄土区滑坡研究中地形因子的选取与适宜性分析[J]. 地球信息科学学报, 2017, 19(12):1584-1592. doi: 10.3724/SP.J.1047.2017.01584
	[ Niu Q F, Feng Z B, Dang X H, et al. Suitability analysis of topographic factors in loess landslide research[J]. Journal of Geo-Information Science, 2017, 19(12):1584-1592. ]
[35]	王毅, 方志策, 牛瑞卿, 等. 基于深度学习的滑坡灾害易发性分析[J]. 地球信息科学学报, 2021, 23(12):2244-2260. doi: 10.12082/dqxxkx.2021.210057
	[ Wang Y, Fang Z C, Niu R Q, et al. Landslide susceptibility analysis based on deep learning[J]. Journal of Geo-Information Science, 2021, 23(12):2244-2260. ]
[36]	梁杰, 陈嘉豪, 张雪芹, 等. 基于独热编码和卷积神经网络的异常检测[J]. 清华大学学报(自然科学版), 2019, 59(7):523-529.
	[ Liang J, Chen J H, Zhang X Q, et al. One-hot encoding and convolutional neural network based anomaly detection[J]. Journal of Tsinghua University (Science and Technology), 2019, 59(7):523-529. ] DOI:10.16511/j.cnki.qhdxxb.2018.25.061 doi: 10.16511/j.cnki.qhdxxb.2018.25.061
[37]	Swets J A. Measuring the accuracy of diagnostic systems[J]. Science, 1988, 240(4857):1285-1293. DOI:10.1126/science.3287615 doi: 10.1126/science.3287615 pmid: 3287615
[38]	郭子正, 殷坤龙, 黄发明, 等. 基于滑坡分类和加权频率比模型的滑坡易发性评价[J]. 岩石力学与工程学报, 2019, 38(2):287-300.
	[ Guo Z Z, Yin K L, Huang F M, et al. Evaluation of landslide susceptibility based on landslide classification and weighted frequency ratio model[J]. Chinese Journal of Rock Mechanics and Engineering, 2019, 38(2):287-300. ] DOI:10.13722/j.cnki.jrme.2018.0838 doi: 10.13722/j.cnki.jrme.2018.0838
[39]	Friedman J H. Greedy function approximation: A gradient boosting machine[J]. The Annals of Statistics, 2001, 29(5):1189-1232. DOI:10.1214/aos/1013203451 doi: 10.1214/aos/1013203451
[40]	宋英旭. 基于空天地一体化监测的滑坡风险动态评价研究[D]. 武汉: 中国地质大学, 2019.
	[ Song Y X. Dynamic evaluation of landslide risk based on integrated monitoring of satellite, airborne and ground-based data[D]. Wuhan: China University of Geosciences, 2019. ]
[41]	Breiman L. Random forests[J]. Machine Learning, 2001, 45(1):5-32. DOI:10.1023/A:1010933404324 doi: 10.1023/A:1010933404324
[42]	吴润泽, 胡旭东, 梅红波, 等. 基于随机森林的滑坡空间易发性评价:以三峡库区湖北段为例[J]. 地球科学, 2021, 46(1):321-330.
	[ Wu R Z, Hu X D, Mei H B, et al. Spatial susceptibility assessment of landslides based on random forest: A case study from Hubei section in the Three Gorges Reservoir area[J]. Earth Science, 2021, 46(1):321-330. ]
[43]	韦德光, 揭育金, 黄廷淦. 福建省区域地质构造特征[J]. 中国区域地质, 1997, 16(2):162-170.
	[ Wei D G, Jie Y J, Huang T G. Regional geological structure of Fujian[J]. Regional Geology of China, 1997, 16(2):162-170. ]
[44]	中华人民共和国住房和城乡建设部. 工程岩体分级标准:GB/T 50218—2014: 北京: 中国计划出版社, 2015.
	[ Ministry of Housing and Urban-Rural Development of the People's Republic of China. GB/T 50218—2014[S]. Beijing: China Planning Press, 2015. ]
[45]	周侯伯, 肖桂荣, 林炫歆, 等. 基于特征筛选与差分进化算法优化的滑坡危险性评估方法[J]. 地球信息科学学报, 2022, 24(12):2373-2388. doi: 10.12082/dqxxkx.2022.220158
	[ Zhou H B, Xiao G R, Lin X X, et al. Landslide hazard assessment method based on feature screening and differential evolutionalgorithm optimization[J]. Journal of Geo-information Science, 2022, 24(12):2373-2388. ] DOI:10.12082/dqxxkx.2022.220158 doi: 10.12082/dqxxkx.2022.220158

基础数据	数据来源	数据类型	数据年份	分辨率
滑坡空间分布数据	资源环境科学与数据中心 (https://www.resdc.cn/data.aspx?DATAID=290)	矢量	积累至2019年	—
数字高程影像	ASTER Global Digital Elevation Model V003 (https://search.earthdata.nasa.gov/search)	栅格	成像时间为2000年3月1日—2013年11月30日	30 m×30 m
自然地理数据	全国地理信息资源目录服务系统1:100万全国基础地理数据库 (https://www.webmap.cn/commres.do?method=result100W)	矢量	2021年	—
地形数据	从数字高程影像中提取	栅格	—	30 m×30 m
降水量数据	温室数据共享平台(http://data.sheshiyuanyi.com/)	文本	2000—2019年	—
地质数据	地质科学数据出版系统1:100万福建省地质图数据 (http://dcc.cgs.gov.cn/)	矢量	2017年	—
土地利用类型数据	1990—2021年中国30 m年土地覆被数据集及其动态( https://doi.org/10.5281/zenodo.5816591)	栅格	2000—2020年	30 m×30 m

评估因子	高程	坡度	坡向	降水量	工程地质岩组	到断裂距离	到水系距离	到道路距离	20年土地利用变化
高程	1.0000	0.2510	0.0227	0.2012	-0.0861	0.1866	0.2701	0.3308	-0.2536
坡度	0.2510	1.0000	0.0363	0.0839	-0.0454	0.0378	0.0909	0.1345	-0.2725
坡向	0.0227	0.0363	1.0000	0.0047	-0.0061	-0.0003	0.0044	0.0083	-0.0182
降水量	0.2012	0.0839	0.0047	1.0000	0.1787	0.0899	0.0442	-0.0158	-0.0096
工程地质岩组	-0.0861	-0.0454	-0.0061	0.1787	1.0000	-0.1616	-0.0917	-0.0578	0.0961
到断裂距离	0.1866	0.0378	-0.0003	0.0899	-0.1616	1.0000	0.0607	0.1026	-0.0529
到水系距离	0.2701	0.0909	0.0044	0.0442	-0.0917	0.0607	1.0000	0.1630	-0.1508
到道路距离	0.3308	0.1345	0.0083	-0.0158	-0.0578	0.1026	0.1630	1.0000	-0.1626
20年土地利用变化	-0.2536	-0.2725	-0.0182	-0.0096	0.0961	-0.0529	-0.1508	-0.1626	1.0000

评估因子	TOL	VIF
高程	0.1138	8.7844
坡度	0.1715	5.8319
坡向	0.1749	5.7181
降水量	0.2970	3.3674
工程地质岩组	0.3091	3.2353
到断裂距离	0.3979	2.5134
到水系距离	0.3169	3.1551
到道路距离	0.3073	3.2540
20年土地利用变化	0.2533	3.9473

2020年土地利用类型	滑坡比	FR	2000—2020年地类变化	滑坡比	FR
植被区域	0.724	0.809	变为植被区域	0.014	2.541
农田	0.250	2.785	变为农田	0.113	2.812
水体	0.003	0.618	变为水体	0.001	1.073
裸地	0	0	变为裸地	0	0
不透水面	0.023	2.248	变为不透水面	0.010	1.689

项目	LR
项目	2000年土地利用类型	2020年土地利用类型	2000—2020年土地利用变化
训练数据集	0.9024	0.9037	0.9045
测试数据集	0.9042	0.9156	0.9156
完整数据集	0.9028	0.9060	0.9067
AUC值	0.9599	0.9611	0.9611

Landslide Susceptibility Assessment Method Considering Land Use Dynamic Change

RichHTML

PDF (PC)

Like

Knowledge

Abstract

Cite this article

share this article

Figures/Tables 16

References 45

Related Articles 15

Metrics

Comments

Recommended 0

预测模型	主要参数	搜索范围	搜索步长	最优结果
DT	max_depth	[2,10]	2	6
	max_features	[2,8]	1	6
	max_leaf_nodes	[2,8]	1	7
GBDT	n_estimators	[20,300]	20	300
	max_depth	[2,10]	2	6
	max_features	[2,8]	1	8
	max_leaf_nodes	[2,8]	1	7
RF	max_depth	[2,10]	2	10
	max_features	[2,8]	1	5
	n_estimators	[20,300]	20	280

项目	DT	GBDT	RF
训练数据集	0.8829	0.9533	0.9634
测试数据集	0.8815	0.9481	0.9513
完整数据集	0.8826	0.9522	0.9610
AUC值	0.9315	0.9815	0.9922

易发性等级	滑坡点/数	滑坡比	面积比	频率比
极低	46	0.03	0.17	0.18
低	64	0.04	0.11	0.38
中	109	0.07	0.16	0.44
高	241	0.16	0.20	0.78
极高	1078	0.70	0.36	1.95

2020年土地利用类型	滑坡比	FR	2000—2020年地类变化	滑坡比	FR
植被区域	0.740	0.900	变为植被区域	0.021	1.258
农田	0.226	1.639	变为农田	0.099	2.432
水体	0.002	0.321	变为水体	0.000	0.338
裸地	0.000	0.000	变为裸地	0.000	0.000
不透水面	0.032	0.989	变为不透水面	0.013	0.828

[1]	LI Yujie, JIANG Hong, LIU Xuanguang. Simulation of Vegetation Gross Primary Productivity and Its Application in Fujian Province of China Using Remote Sensing and CatBoost Algorithm [J]. Journal of Geo-information Science, 2023, 25(9): 1908-1922.
[2]	ZHOU Chao, GAN Lulu, WANG Yue, WU Hongyang, YU Jin, CAO Ying, YIN Kunlong. Landslide Susceptibility Prediction based on Non-Landslide Samples Selection and Heterogeneous Ensemble Machine Learning [J]. Journal of Geo-information Science, 2023, 25(8): 1570-1585.
[3]	CAO Yu, FANG Xiuqin, YANG Lulu, JIANG Xinyuan, LIAO Meiyu, REN Liliang. Downscaling of CCI Soil Moisture in the Xiliaohe River Basin based on Random Forest [J]. Journal of Geo-information Science, 2023, 25(8): 1669-1681.
[4]	YU Qinping, WU Zhenhua, WANG Yabei. A Land Use Change Simulation Model: Coupling of Evolutionary Algorithm and FLUS Model [J]. Journal of Geo-information Science, 2023, 25(3): 510-528.
[5]	QIN Xiaowei, CHENG Bo, YANG Zhiping, LI Lin, DONG Wen, ZHANG Xin, YANG Shuwen, JIN Zongyi, XUE Qing. Identification of Parcel-Scale Crop Types in Southwestern Mountainous Area based on Time Series Remote Sensing Images [J]. Journal of Geo-information Science, 2023, 25(3): 654-668.
[6]	HUANG Shuaiyuan, DONG Youfu, LI Haipeng. Establishment and Comparative Analysis of SRTM1 DEM Error Correction Model in the Loess Plateau [J]. Journal of Geo-information Science, 2023, 25(3): 669-681.
[7]	JIANG Weijie, ZAHNG Chunju, XU Bing, LUO Chenchen, ZHOU Han, ZHOU Kang. AED-Net: Semantic Segmentation Model for Landslide Recognition from Remote Sensing Images [J]. Journal of Geo-information Science, 2023, 25(10): 2012-2025.
[8]	DU Shukun, ZHANG Jing, HAN Zhijun, GONG Maoyu. Armed Conflict Risk Prediction and Influencing Factors Analysis Based on the Random Forest Model at the Grid-month Scale: A Case Study of Indochina Peninsula [J]. Journal of Geo-information Science, 2023, 25(10): 2026-2038.
[9]	WEI Guanjun, GAO Maoning. Particle Filter Data Assimilation Method for Loess Landslide Risk Assessment Combined with TRIGRS Model [J]. Journal of Geo-information Science, 2023, 25(10): 2084-2092.
[10]	PAN Yupiao, ZHAO Xiang, WANG Jing, ZHANG Yiqing, LIU Yaolin. Identifying the Class of the Villages based on SMOTE-RF Algorithm [J]. Journal of Geo-information Science, 2023, 25(1): 163-176.
[11]	LIN Qigen, WANG Leibin, ZHANG Jiahui. Assessment of the Rainfall-Induced Landslide Hazard and Population Exposure in China under 1.5 ℃ and 2.0 ℃ Global Warming Scenarios [J]. Journal of Geo-information Science, 2023, 25(1): 177-189.
[12]	YANG Yang, SHAO Zheping, ZHAO Qiang, PAN Jiacai, HU Yu, MEI Qiang. Geographical Spatial Distribution and Risk Prediction of Maritime Traffic Accidents in Port of Xiamen [J]. Journal of Geo-information Science, 2022, 24(9): 1676-1687.
[13]	WU Yanan, GUO Chang'en, YU Dongping, DUAN Aimin, Liu Yu, DONG Shiwei, SHAN Dongfang, WU Naiming, LI Xican. Spatial Stratification and Evaluation Method of Remote Sensing Classification based on Uncertainty Analysis [J]. Journal of Geo-information Science, 2022, 24(9): 1803-1816.
[14]	NIE Xiangqin, CHEN Hanyue, NIU Zheng, ZHANG Liming, LIU Wei, XING Shihe, FAN Xieyu, LI JiaGuo. Digital SOC Mapping in Croplands Using Agricultural Activity Factors Derived from Time-Series Data in Western Fujian [J]. Journal of Geo-information Science, 2022, 24(9): 1835-1852.
[15]	GAO Wei, TU Wei, LI Mingxiao, FANG Bichen, CHEN Dongsheng, HUANG Zhengdong, HE Biao. Synergistic Simulation of Land and Population in Metropolitan Area With Dynamic Influence Factors [J]. Journal of Geo-information Science, 2022, 24(8): 1502-1511.

项目	LR
项目	2000年土地利用类型	2020年土地利用类型	2000—2020年土地利用变化
训练数据集	0.7239	0.7183	0.7294
测试数据集	0.7331	0.7323	0.7417
完整数据集	0.7258	0.7211	0.7319
AUC值	0.8032	0.7913	0.8082
