引入集水区复杂网络的中国地貌识别研究

doi:10.12082/dqxxkx.2023.220712

Abstract

Abstract:

Landform recognition has become a key part of geomorphological research, which has been widely concerned by scholars. The research of geomorphic units based on catchment has become a hotspot in the field of landform recognition. Previous studies have generated a series of new questions, such as whether large-scale landform types can be identified based on local catchment landform features, which landform description methods are more adaptable, and what is the knowledge bottleneck of current landform recognition methods based on the catchment. So, in this paper, we selected sample areas representing five major landform types in China, including karst, loess, periglacial, aeolian, and fluvial. Based on the complex network theory, we took the complex network indicators and the topographic metrics as the basic data sources. Three typical machine learning methods, i.e., LightGBM, XGBoost, and RF, were used to automatically identify the main geomorphic types in China. Results show that both the complex network structure and the terrain features of the catchment have certain explanatory power and recognition effect on landforms, and the overall recognition accuracy is 77.5% and 72.5%, respectively. Among the five geomorphologic types selected, LightGBM, XGBoost, and RF machine learning methods have the highest recognition accuracy (up to 100%) on periglacic geomorphology. Compared to a single geomorphic description data source, the geomorphic recognition effect that combines the two data sources is significantly improved. The overall accuracy using two data sources is 5% and 10% higher than that using the single complex network dataset and the single topographic dataset, respectively. Moreover, LightGBM has better adaptability to the combination of complex network and terrain factor feature sets, and the overall accuracy can reach 82.5%. In general, this study expands the application area and scope of catchment landform recognition methods, and provides a new idea for the research of catchment landform recognition.

Key words: China, landform recognition, watershed, DEM, complex network, terrain feature, machine learning

QI Meng, CHEN Nan, LIN Siwei, ZHOU Qianqian. Geomorphic Recognition of China Considering Complex Network of Catchments[J].Journal of Geo-information Science, 2023, 25(5): 909-923.DOI:10.12082/dqxxkx.2023.220712

Figures/Tables 13

Fig. 1

Fig. 2

Fig. 3

Fig. 4

Fig. 5

Fig. 6

Tab. 1

Description of complex network indicators and related calculation methods

指标名称	指标公式	公式参数说明	地学意义	公式编号
平均度	$k - = 1 n ∑ i = 1 n k i$	$k - 为平均度； k i$ 为复杂网络中第i个网络节点的度数；n是集水区复杂网络中的节点总数	反映了集水区网络中某一类型节点所占的比重	（1）
平均加权度	$K - = ∑ i K i / N$	$K - 为平均加权度； K i$ 为复杂网络中第i条网络边的权重；N为集水区复杂网络中的节点总数	反映了集水区复杂网络中某一类型节点对应边的权重情况	（2）
网络直径	$N D = ∑ i j m a x (d i j)$	$N D$ 为网络直径；集水区复杂网络中节点i到j的距离 $d i j$ 为连接这两个节点间最短路径的边数	表达了网络中各节点之间的距离	（3）
网络密度	$d G = 2 m / [n (n - 1)]$	在集水区复杂网络中，用网络中实际拥有的连线书与最多可能存在的连线总数之比表示 $d G$ 网络密度，m是网络中实际拥有的连接数；n是网络节点总数	反映了集水区复杂网络中各节点间联络的紧密程度	（4）
平均路径长度	$L = 2 N (N - 1) ∑ i > j d i j$	对于一个集水区复杂网络，2个特征点之间存在多条集水区特征点连通且存在多种连通方式，则两个特征节点i与j之间的距离 $d i j$ 就是两节点之间最短路径经过的其他集水区特征节点的平均数量。 $N$ 为网络节点总数， $L$ 为平均路径长度	反映了复杂的集水区网络中节点之间的分离程度	（5）
网络结构熵	$E = - ∑ i = 1 n d (i) ∑ i = 1 n d (i) l n H i$	$E 为网络结构熵； H i$ 为第i个节点的重要度；n为网络节点总数； $d (i)$ 表示第i节点的度	从整体角度衡量了集水区复杂网络系统演化的发展趋势	（6）
分形维数	$d = - l i m r > 0 l n N (r) l n r$	对于任意一个集水区复杂网络，采用边长为r的正方形盒子覆盖，会出现一些盒子是包含图形，其余为空盒子的情况。随着盒子边长的增加，则包含图形的盒子数目逐渐减少。 $d 为分形维数；$ 将边长为r（r=1,2,3,…,M）的正方体覆盖网络，会出现包含图形的盒子和空盒子 $N (r)$ 。在适当的范围内，对r选取一系列不同的值，以 $l n r$ 为横坐标， $l n N (r)$ 为纵坐标，利用最小二乘法对其进行线性回归，对其斜率取负即为集水区复杂网络的分形维数	刻画了集水区复杂网络系统的复杂程度，反映了集水区复杂网络系统的相似性	（7）

Tab. 1

Tab. 2

Topographic index meaning and related calculation methods

指标名称	指标公式	公式参数说明	地学含义	公式编号
坡向/° （Aspect）	$A s p e c t = a r c t a n f y f x$	$f x$ 为东西方向上的高程变化率； $f y$ 为南北方向上的高程变化率	描述了集水区上坡面的朝向	（8）
坡度/% （slope）	$s l o p e = a r c t a n f x 2 + f y 2 × 180 π$	$f x$ 为东西方向上的高程变化率； $f y$ 为南北方向上的高程变化率	描述了集水区地表单元的陡缓程度	（9）
粗糙度（SR）	$S R = 1 c o s s l o p e × 3.14 180$	$s l o p e$ 为集水区地形坡度	描述了集水区地势起伏的复杂程度	（10）
坡向变率（SOA）	$S O A = S O A 1 - S O A 2 - \| S O A 1 - S O A 2 \| 2$	$S O A 1$ 为正地形计算的坡向变率； $S O A 2$ 为负地形计算的坡向变率	描述了地表局部范围内坡向的变化情况	（11）
平面曲率（Curve）	$C = f x x f y 2 - 2 f x y f x f y + f y y f x 2 (f x 2 + f y 2) 3 / 2$	$f x$ 为东西方向上的高程变化率； $f y$ 为南北方向上的高程变化率； $f x x$ 是东西方向上的高程变化率的变化率； $f x y$ 是东西方向的高程变化率在南北方向的变化率； $f y y$ 是南北方向的高程变化率的变化率	集水区地形曲面在水平方向的曲率，描述了地面等高线的弯曲程度	（12）
剖面曲率（SOS）	$S O S = f x x f x 2 + 2 f x y f x f y + f y y f y 2 (f x 2 + f y 2) (1 + f x 2 + f y 2) 3 / 2$		描述了坡度的变化程度	（13）
地表切割深度/m （SCD）	$S C D = H m e a n - H m i n$	$H m e a n$ 为集水区高程的平均值； $H m i n$ 为该集水区最小高程值	反映了地表被侵蚀切割的情况	（14）
高程变异系数（ECV）	$E C V = H s t d H m e a n$	$H s t d$ 为集水区高程标准差； $H m e a n$ 为该集水区高程的平均值	反映了地貌特征的差异性	（15）

Tab. 2

Fig. 7

Tab. 3

Tab. 4

Tab. 5

Fig. 8

References 49

[1]	MacMillan R A, Shary P A. Chapter 9 landforms and landform elements in geomorphometry[J]. Developments in Soil Science, 2009, 33:227-254. DOI:10.1016/S0166-2481(08)00009-3 doi: 10.1016/S0166-2481(08)00009-3
[2]	Smith M J. Digital mapping[M]// Developments in Earth Surface Processes. Amsterdam: Elsevier, 2011:225-251. DOI:10.1016/B978-0-444-53446-0.00008-2 doi: 10.1016/B978-0-444-53446-0.00008-2
[3]	陈楹, 李安波, 姚蒙蒙, 等. 基于空间结构模式匹配的褶皱地貌类型自动识别[J]. 地球信息科学学报, 2016, 18(11):1500-1512. doi: 10.3724/SP.J.1047.2016.01500
	[ Chen Y, Li A B, Yao M M, et al. Automatic recognition of fold landform types based on spatial structure pattern matching[J]. Journal of Geo-Information Science, 2016, 18(11):1500-1512. ] DOI:10.3724/SP.J.1047.2016.01500 doi: 10.3724/SP.J.1047.2016.01500
[4]	张福浩, 朱月月, 赵习枝, 等. 地理因子支持下的滑坡隐患点空间分布特征及识别研究[J]. 武汉大学学报·信息科学版, 2020, 45(8):1233-1244.
	[ Zhang F H, Zhu Y Y, Zhao X Z, et al. Spatial distribution and identification of hidden danger points of landslides based on geographical factors[J]. Geomatics and Information Science of Wuhan University, 2020, 45(8):1233-1244. ] DOI:10.13203/j.whugis20200126 doi: 10.13203/j.whugis20200126
[5]	曹伟超, 陶和平, 孔博, 等. 青藏高原地貌形态总体特征的GIS识别分析[J]. 水土保持通报, 2011, 31(04):163-167,247.
	[ Cao W C, Tao H P, Kong B, et al. Recongnition of general topographic features in Qinghai- Tibet Plateau based on GIS[J]. Bulletin of Soil and Water Conservation, 2011, 31(04):163-167,247. ] DOI:10.13961/j.cnki.stbctb.2011.04.004 doi: 10.13961/j.cnki.stbctb.2011.04.004
[6]	Zhao W F, Xiong L Y, Ding H, et al. Automatic recognition of loess landforms using Random Forest method[J]. Journal of Mountain Science, 2017, 14(5):885-897. DOI: 10.1007/s11629-016-4320-9 doi: 10.1007/s11629-016-4320-9
[7]	曹伟超, 陶和平, 孔博, 等. 利用最佳地形特征空间进行地貌形态自动识别——以西南地区为例[J]. 武汉大学学报·信息科学版, 2011, 36(11):1376-1380.
	[ Cao W H, Tao H P, Kong B, et al. Topographic Automatic recognition of geomorphology using optimal terrain feature space: A Case Study of Southwest China[J]. Journal of Wuhan University(Natural Science Edition), 2011, 36(11):1376-1380. ] DOI:10.13203/j.whugis2011.11.028 doi: 10.13203/j.whugis2011.11.028
[8]	钟业勋, 魏文展, 李占元. 基本地貌形态数学定义的研究[J]. 测绘科学, 2002, 27(3):16-18,2.
	[ Zhong Y X, Wei W Z, Li Z Y. A reseach on the mathematical definition of the basic landform shape[J]. Developments in Surveying and Mapping, 2002, 27(3):16-18,2. ] DOI:10.3771/j.issn.1009-2307.2002.03.005 doi: 10.3771/j.issn.1009-2307.2002.03.005
[9]	汤国安, 李发源, 熊礼阳. 黄土高原数字地形分析研究进展[J]. 地理与地理信息科学, 2017, 33(4):1-7.
	[ Tang G A, Li F Y, Xiong L Y. Progress of digital terrain analysis in the loess plateau of China[J]. Geography and Geo-Information Science, 2017, 33(4):1-7. ] DOI:10.3969/j.issn.1672-0504.2017.04.001 doi: 10.3969/j.issn.1672-0504.2017.04.001
[10]	Lin S W, Xie J, Deng J Y, et al. Landform classification based on landform geospatial structure - a case study on Loess Plateau of China[J]. International Journal of Digital Earth, 2022, 15(1):1125-1148. DOI:10.1080/17538947.2022.2088874 doi: 10.1080/17538947.2022.2088874
[11]	朱红春, 汤国安, 李永胜. 黄土沟谷特征点簇及其空间结构模型研究[J]. 地理科学, 2015, 35(9):1170-1175. doi: 10.13249/j.cnki.sgs.2015.09.1170
	[ Zhu H C, Tang G A, Li Y S. The loess gully feature points cluster and its spatial structure model[J]. Scientia Geographica Sinica, 2015, 35(9):1170-1175. ] DOI:10.13249/j.cnki.sgs.2015.09.014 doi: 10.13249/j.cnki.sgs.2015.09.014
[12]	朱红春, 汤国安, 吴良超, 等. 基于地貌结构与汇水特征的沟谷节点提取与分析——以陕北黄土高原为例[J]. 水科学进展, 2012, 23(1):7-13.
	[ Zhu H C, Tang G A, Wu L C, et al. Extraction and analysis of gully nodes based on geomorphological structures and catchment characteristics: A case study in the loess plateau of North Shaanxi Province[J]. Advances in Water Science, 2012, 23(1):7-13. ] DOI:10.14042/j.cnki.32.1309.2012.01.014 doi: 10.14042/j.cnki.32.1309.2012.01.014
[13]	汤国安, 李发源, 杨昕. 黄土高原数字地形分析探索与实践[M]. 北京: 科学出版社, 2015.
	[ Tang G A, Li F Y, Yang X. Exploration and practice of digital terrain analysis on loess plateau[M]. Beijing: Science Press, 2015. ]
[14]	Tao Y, Tang G A, Strobl J. Spatial structure characteristics detecting of landform based on improved 3D Lacunarity model[J]. Chinese Geographical Science, 2012, 22(1):88-96. DOI:10.1007/s11769-012-0516-2 doi: 10.1007/s11769-012-0516-2
[15]	Crofts R S. The landscape component approach to landscape evaluation[J]. Transactions of the Institute of British Geographers, 1975(66): 124. DOI:10.2307/621626 doi: 10.2307/621626
[16]	张红, 何晶, 杨婕, 等. 基于复杂网络的道路网拓扑结构信息度量[J]. 地理与地理信息科学, 2017, 33(2):1-6.
	[ Zhang H, He J, Yang J, et al. Quantitative measurements on topological structural information of road networks based on complex network analyses[J]. Geography and Geo-Information Science, 2017, 33(2):1-6. ] DOI:10.3969/j.issn.1672-0504.2017.02.001 doi: 10.3969/j.issn.1672-0504.2017.02.001
[17]	武鹏飞, 宫辉力, 周德民. 基于复杂网络的官厅水库流域土地利用/覆被变化[J]. 地理学报, 2012, 67(1):113-121. doi: 10.11821/xb201201012
	[ Wu P F, Gong H L, Zhou D M. Land use and land cover change in watershed of Guanting Reservoir based on complex network[J]. Acta Geographica Sinica, 2012, 67(1):113-121. ] DOI:10.11821/xb201201012 doi: 10.11821/xb201201012
[18]	Wu X F, Yu K, Wang X. On the growth of Internet application flows: A complex network perspective[C]// 2011 Proceedings IEEE INFOCOM. IEEE,2011: 2096- 2104. DOI:10.1109/INFCOM.2011.5935019 doi: 10.1109/INFCOM.2011.5935019
[19]	Heckmann T, Schwanghart W. Geomorphic coupling and sediment connectivity in an alpine catchment—Exploring sediment cascades using graph theory[J]. Geomorphology, 2013, 182:89-103. DOI:10.1016/j.geomorph.2012.10.033 doi: 10.1016/j.geomorph.2012.10.033
[20]	Jha S K, Zhao H H, Woldemeskel F M, et al. Network theory and spatial rainfall connections: An interpretation[J]. Journal of Hydrology, 2015, 527:13-19. DOI:10.1016/j.jhydrol.2015.04.035. doi: 10.1016/j.jhydrol.2015.04.035
[21]	Sivakumar B, Puente C E, Maskey M L. Complex networks and hydrologic applications[M]// Advances in Nonlinear Geosciences. Cham: Springer International Publishing, 2017:565-586. DOI:10.1007/978-3-319-58895-7_26 doi: 10.1007/978-3-319-58895-7_26
[22]	Abe S, Suzuki N. Complex-network description of seismicity[J]. Nonlinear Processes in Geophysics, 2006, 13(2):145-150. DOI:10.5194/npg-13-145-2006 doi: 10.5194/npg-13-145-2006
[23]	Phillips J D, Schwanghart W, Heckmann T. Graph theory in the geosciences[J]. Earth-Science Reviews, 2015, 143:147-160. DOI:10.1016/j.earscirev.2015.02.002 doi: 10.1016/j.earscirev.2015.02.002
[24]	Donges J F, Zou Y, Marwan N, et al. Complex networks in climate dynamics[J]. The European Physical Journal Special Topics, 2009, 174(1):157-179. DOI:10.1140/epjst/e2009-01098-2 doi: 10.1140/epjst/e2009-01098-2
[25]	贺卓文, 陈楠. 复杂网络理论在黄土高原沟谷地貌特征研究中的应用[J]. 地球信息科学学报, 2021, 23(7):1196-1207. doi: 10.12082/dqxxkx.2021.200639
	[ He Z W, Chen N. Feature analysis of gully landforms in the loess plateau based on complex networks[J]. Journal of Geo-information Science, 2021, 23(7):1196-1207. ] DOI:10.12082/dqxxkx.2021.200639 doi: 10.12082/dqxxkx.2021.200639
[26]	田剑, 汤国安, 赵明伟. 流域地形景观系统的复杂网络描述[J]. 地理与地理信息科学, 2014, 30(4):22-26.
	[ Tian J, Tang G A, Zhao M W. Complex network description of terrain landscape system on drainage basin[J]. Geography and Geo-Information Science, 2014, 30(4):22-26. ] DOI:10.3969/j.issn.1672-0504.2014.04.005 doi: 10.3969/j.issn.1672-0504.2014.04.005
[27]	林偲蔚, 陈楠, 刘奇祺, 等. 基于DEM小流域复杂网络的黄土高原地貌自动识别研究[J]. 地球信息科学学报, 2022, 24(4):657-672. doi: 10.12082/dqxxkx.2022.210449
	[ Lin S W, Chen N, Liu Q Q, et al. Geomorphological automatic recognition of loess plateau based on complex network of small watershed from DEM[J]. Journal of Geo-information Science, 2022, 24(4):657-672. ] DOI:10.12082/dqxxkx.2022.210449 doi: 10.12082/dqxxkx.2022.210449
[28]	贺中华, 梁虹, 黄法苏, 等. 基于DEM的喀斯特流域地貌类型的识别[J]. 大地测量与地球动力学, 2008, 28(3):46-53.
	[ He Z H, Liang H, Huang F S, et al. Recognition based on Dem of geomorphologic type of Karst drainage[J]. Journal of Geodesy and Geodynamics, 2008, 28(3):46-53. ] DOI:10.14075/j.jgg.2008.03.009 doi: 10.14075/j.jgg.2008.03.009
[29]	Cao M, Tang G A, Zhang F, et al. A cellular automata model for simulating the evolution of positive-negative terrains in a small loess watershed[J]. International Journal of Geographical Information Science, 2013, 27(7):1349-1363. DOI:10.1080/13658816.2012.756882 doi: 10.1080/13658816.2012.756882
[30]	Yang R, Willett S D, Goren L. In situ low-relief landscape formation as a result of river network disruption[J]. Nature, 2015, 520(7548):526-529. DOI:10.1038/nature14354 doi: 10.1038/nature14354
[31]	王乐, 周毅, 李阳. 面向子流域单元的典型黄土地貌分类研究[J]. 干旱区研究, 2019, 36(6):1592-1598.
	[ Wang L, Zhou Y, Li Y. Classification of typical loess landforms in subcatchments[J]. Arid Zone Research, 2019, 36(6):1592-1598. ] DOI:10.13866/j.azr.2019.06.30 doi: 10.13866/j.azr.2019.06.30
[32]	张艳可, 王金亮, 苏怀, 等. 基于CART决策树的双尺度流域单元地貌分类研究——以北回归线(云南段)地区为例[J]. 地理与地理信息科学, 2021, 37(2):84-92.
	[ Zhang Y K, Wang J L, Su H, et al. Study on landform classification of dual-scale watershed units based on CART: A case study of the tropic of cancer (Yunnan section)[J]. Geography and Geo-Information Science, 2021, 37(2):84-92. ] DOI:10.3969/j.issn.1672-0504.2021.02.012 doi: 10.3969/j.issn.1672-0504.2021.02.012
[33]	Li M, Yang X, Na J M, et al. Regional topographic classification in the North Shaanxi Loess Plateau based on catchment boundary profiles[J]. Progress in Physical Geography: Earth and Environment, 2017, 41(3):302-324. DOI:10.1177/0309133317706356 doi: 10.1177/0309133317706356
[34]	Xiong L Y, Zhu A X, Zhang L, et al. Drainage Basin object-based method for regional-scale landform classification: A case study of loess area in China[J]. Physical Geography, 2018, 39(6):523-541. DOI:10.1080/02723646.2018.1442062 doi: 10.1080/02723646.2018.1442062
[35]	刘双琳, 李发源, 蒋如乔, 等. 黄土地貌类型的坡谱自动识别分析[J]. 地球信息科学学报, 2015, 17(10):1234-1242. doi: 10.3724/SP.J.1047.2015.01234
	Li F Y, Jiang R Q, et al. A method of loess landform automatic recognition based on slope spectrum[J]. Journal of Geo-Information Science, 2015, 17(10):1234-1242. ] DOI:10.3724/SP.J.1047.2015.01234 doi: 10.3724/SP.J.1047.2015.01234
[36]	蒋圣. 基于DEM的黄土高原地形纹理研究[D]. 南京: 南京师范大学, 2020.
	[ Jiang S. DEM based research on terrain texture of the loess plateau[D]. Nanjing: Nanjing Normal University, 2020. ] DOI:10.27245/d.cnki.gnjsu.2020.000058 doi: 10.27245/d.cnki.gnjsu.2020.000058
[37]	曹泽涛, 方子东, 姚瑾, 等. 基于随机森林的黄土地貌分类研究[J]. 地球信息科学学报, 2020, 22(3):452-463. doi: 10.12082/dqxxkx.2020.190247
	[ Cao Z T, Fang Z D, Yao J, et al. Loess landform classification based on random forest[J]. Journal of Geo-Information Science, 2020, 22(3):452-463. ] DOI:10.12082/dqxxkx.2020.190247 doi: 10.12082/dqxxkx.2020.190247
[38]	Du L, You X, Li K, et al. Multi-modal deep learning for landform recognition[J]. ISPRS Journal of Photogrammetry and Remote Sensing, 2019, 158:63-75. DOI:10.1016/j.isprsjprs.2019.09.018 doi: 10.1016/j.isprsjprs.2019.09.018
[39]	Cheng W M, Zhou C H, Li B Y, et al. Structure and contents of layered classification system of digital geomorphology for China[J]. Journal of Geographical Sciences, 2011, 21(5):771. DOI:10.1007/s11442-011-0879-9 doi: 10.1007/s11442-011-0879-9
[40]	周成虎, 程维明, 钱金凯, 等. 中国陆地1∶100万数字地貌分类体系研究[J]. 地球信息科学学报, 2009, 11(6):707-724.
	[ Zhou C H, Cheng W M, Qian J K, et al. Research on the classification system of digital land geomorphology of 1∶1000000 in China[J]. Journal of Geo-Information Science, 2009, 11(6):707-724. ] DOI:10.3969/j.issn.1560-8999.2009.06.006 doi: 10.3969/j.issn.1560-8999.2009.06.006
[41]	程维明, 周成虎, 李炳元, 等. 中国地貌区划理论与分区体系研究[J]. 地理学报, 2019, 74(5):839-856. doi: 10.11821/dlxb201905001
	[ Cheng W M, Zhou C H, Li B Y, et al. Geomorphological regionalization theory system and division methodology of China[J]. Acta Geographica Sinica, 2019, 74(5):839-856. ] DOI:10.11821/dlxb201905001 doi: 10.11821/dlxb201905001
[42]	Wang N, Cheng W M, Wang B X, et al. Geomorphological regionalization theory system and division methodology of China[J]. Journal of Geographical Sciences, 2020, 30(2):212-232. DOI:10.1007/s11442-020-1724-9 doi: 10.1007/s11442-020-1724-9
[43]	汪凯, 陈楠. 顾及空间特征的地形特征点提取方法[J]. 测绘科学, 2021, 46(2):192-202.
	[ Wang K, Chen N. Terrain feature point extraction method considering spatial characteristics[J]. Science of Surveying and Mapping, 2021, 46(2):192-202. ] DOI:10.16251/j.cnki.1009-2307.2021.02.028 doi: 10.16251/j.cnki.1009-2307.2021.02.028
[44]	谢轶群, 朱红春, 汤国安, 等. 基于DEM的沟谷特征点提取与分析[J]. 地球信息科学学报, 2013, 15(1):61-67. doi: 10.3724/SP.J.1047.2013.00061
	[ Xie Y Q, Zhu H C, Tang G A, et al. Extraction and analysis of gully feature points based on DEMs[J]. Journal of Geo-information Science, 2013, 15(1):61-67. ] doi: 10.3724/SP.J.1047.2013.00061
[45]	杨晓平, 王萍, 李晓峰, 等. 地形坡度和高程变异系数在识别墨脱活动断裂带中的应用[J]. 地震地质, 2019, 41(2):419-435.
	[ Yang X P, Wang P, Li X F, et al. Application of topographic slope and elevation variation coefficient in identifying the Motuo active fault zone[J]. Seismology and Geology, 2019, 41(2):419-435. ]
[46]	Ke G L, Meng Q, Finley T, et al. LightGBM: A highly efficient gradient boosting decision tree[C]// Proceedings of the 31st International Conference on Neural Information Processing Systems. New York: ACM, 2017:3149-3157.
[47]	Dhaliwal S, Nahid A A, Abbas R. Effective intrusion detection system using XGBoost[J]. Information, 2018, 9(7):149. DOI:10.3390/info9070149 doi: 10.3390/info9070149
[48]	Friedman J H. Greedy function approximation: A gradient boosting machine[J]. The Annals of Statistics, 2001, 29(5):1189-1232. DOI:10.1214/aos/1013203451 doi: 10.1214/aos/1013203451
[49]	张捷, 包浩生. 分形理论及其在地貌学中的应用──分形地貌学研究综述及展望[J]. 地理研究, 1994, 13(3):104-112. doi: 10.11821/yj1994030013
	[ Zhong J, Bao H S. Fractal geomorpholopy──review and propect[J]. Geographical Research, 1994, 13(3):104-112. ] doi: 10.11821/yj1994030013

Geomorphic Recognition of China Considering Complex Network of Catchments

RichHTML

PDF (PC)

Like

Knowledge

Abstract

Cite this article

share this article

Figures/Tables 13

References 49

Related Articles 15

Metrics

Comments

Recommended 0

	岩溶地貌	黄土地貌	冰缘地貌	风成地貌	流水地貌	精准度/%	召回率/%	F1值
岩溶地貌	5	1		1		71	83	77
黄土地貌	1	5		1		71	83	77
冰缘地貌			8			100	80	90
风成地貌				7	1	88	78	83
流水地貌			2		6	75	86	81
总体精度/%	77.5
