基于互联网大数据的区域多层次空间结构分析研究

doi:10.3724/SP.J.1047.2016.00719

Abstract

Abstract:

With the development of Information and Communication Technology (ICT), big data is now becoming an important tool to carry on researches in many fields. In the domain of human geography, big data technology has gained more and more attention, and there are extensive studies carried out which could be categorized into three groups of research hotspots: the residential behavioral spatial pattern, the urban space and the regional structure. But few researches have explored the regional hierarchical spatial structure systematically based on the big data, and the relevant researches are primarily based on the survey data, which has a bottleneck towards the volume and the detailed micro-data acquisition. This study combined the internet big data mined from internet with the GDP and the spatial traffic network data, etc. to identify the regional spatial structure. The gathered data was categorized into three categories: the point data, the line data and the polygon data. They are used to specify the urban overall capacity and the intensity of interactions between city pairs and the serving area respectively. Based on the obtained data, an algorithm was developed to identify the hierarchical regional structure. This method was applied to the Beijing-Tianjin-Hebei region. And a hierarchical regional structure was demonstrated by a multi-way tree created with this algorithm. The established multi-way tree identifies a regional urban ranking system in detail and can be of great help to decision makers in delineating the regional spatial policies. The results shows that Beijing which has the highest overall capacity becomes the core city (root node) and has the largest serving area, but the matured secondary cities around Beijing are still expected to share Beijing's serving functions, and there is a development inequality existing between the north and south part of this region. This study provides a good reference to researches in the domain of human geography with the application of big data.

Key words: big data, inter-city relation, centrality, hierarchical regional structure, Beijing-Tianjin-Hebei region

NIU Fangqu,LIU Weidong. Identifying the Hierarchical Regional Spatial Structure Using Internet Big Data[J].Journal of Geo-information Science, 2016, 18(6): 719-726.DOI:10.3724/SP.J.1047.2016.00719

Figures/Tables 8

Fig.1

Fig.2

Tab.1

Weights of the evaluation indices for city′s overall capacity

评价指标	权重 $w ′ j$
互联网大数据	0.432
POI	0.230
GDP	0.338

Tab.1

Fig.3

Tab.2

Weights of the evaluation indices for city′s socio-economic contacts

评价指标	权重 $w ′ j$
文本大数据	0.273
公路运力	0.353
铁路运力	0.357
交通可达性	0.016

Tab.2

Fig.4

Fig.5

Fig.6

References 16

[1]	Hilbert M, Priscilla L.The word's technological capacity to store, communicate, and compute information[J]. Science, 2011,332(6025):60-65.
[2]	顾朝林. 中国城市经济区划分的初步研究[J].地理学报,1991,46(2):129-141. doi: 10.11821/xb199102001
	[ Gu C L.A preliminary study on the division of urban economic regions in China[J]. Journal of Geographical Sciences, 1991,46(2):129-141. ] doi: 10.11821/xb199102001
[3]	高鑫,修春亮,魏冶.城市地理学的“流空间”视角及其中国化研究[J].人文地理,2012(4):32-37.
	[ Gao X, Xiu C L, Wei Y.Study on the sinicization of “space of flows” basing on the visual angle of urban geography[J]. Human Geography, 2012,4:32-37. ]
[4]	赵渺希,吴康,刘行健.城市网络的一种算法及其实证比较[J].地理学报,2014,69(2):169-183. doi: 10.11821/dlxb201402003
	[ Zhao M X, Wu K, Liu X J.A novel method to approximate intercity networks and its empirical validation[J]. Journal of Geographical Sciences, 2014,69(2):169-183. ] doi: 10.11821/dlxb201402003
[5]	Wall R S, Knaap G.A. Sectoral differentiation and network structure within contemporary worldwide corporate network[J]. Economic Geography, 2011,87(3):267-308. doi: 10.1111/j.1944-8287.2011.01122.x
[6]	Taylor P J, Derudder B, Hoyler M, et al.New regional geographies of the world as practiced by leading advanced producer service firms in 2010[J]. Transactions of the Institute of British Geographers, 2013,38(3):497-511.
[7]	路旭,马学广,李贵才.基于国际高级生产者服务业布局的珠三角城市网络空间格局研究[J].经济地理,2012,32(4):50-54.
	[ Lu X, Ma X G, Li G C.Spatial pattern of regional city network based on international advanced producer services' layout in Pearl River Delta[J]. Economic Geography, 2012,32(4):50-54. ]
[8]	赵渺希,刘铮.基于生产性服务业的中国网络研究[J].城市规划,2012(9):23-28,38.
	[ Zhao M X, Liu Z.Research on China's city network based on production service industry[J]. City Planning Review, 2012,9:23-28,38. ]
[9]	Derudder B, Witlox F.An appraisal of the use of airline data in assessing the world city network: a research note on data[J]. Urban Studies, 2005,42(13):2371-2388. doi: 10.1080/00420980500379503
[10]	O'Connor K, Fuellhart K. Cities and air services: the influence of the airline industry[J]. Journal of Transport Geography, 2012,22:46-52.
[11]	薛俊菲. 基于航空网络的中国城市体系等级结构与分布格局[J].地理研究,2008,27(1):23-33. doi: 10.3321/j.issn:1000-0585.2008.01.003
	[ Xue J F.Hierarchical structure and distribution pattern of Chinese urban system based on aviation network[J]. Geographical Research, 2008,27(1):23-33. ] doi: 10.3321/j.issn:1000-0585.2008.01.003
[12]	汪明锋,宁越敏.城市的网络优势——中国互联网骨干网络结构与节点可达性分析[J].地理研究,2006,25(2):193-203. doi: 10.3321/j.issn:1000-0585.2006.02.002
	[ Wang M F, Ning Y M.The network advantage of cities: an analysis of spatial structure and node accessibility of internet backbones in China[J]. Geographical Research, 2006,25(2):193-203. ] doi: 10.3321/j.issn:1000-0585.2006.02.002
[13]	Taylor P J.New political geographies: global civil society and global governance through world city networks[J]. Political Geography, 2005,24(6):703-730. doi: 10.1016/j.polgeo.2005.01.009
[14]	Hoyler M, Watson A.Global media cities in transnational media networks[J]. Journal of Economic and Social Geography, 2013,104(1):90-108. doi: 10.1111/j.1467-9663.2012.00738.x
[15]	牛方曲,刘卫东,宋涛,等.城市群多层次空间结构分析算法及其应用[J].地理研究,2015,34(8):1447-1460. doi: 10.11821/dlyj201508004
	[ Niu F Q, Liu W, Song T, et al.A multi-level spatial structure analysis algorithm for urban agglomeration study in China[J]. Geographical Research, 2015,34(8):1447-1460. ] doi: 10.11821/dlyj201508004
[16]	甄峰,王波,陈映雪.基于网络社会空间的中国城市网络特征[J].地理学报,2012,67(8):1031-1043. doi: 10.11821/xb201208003
	[ Zhen F, Wang B, Chen Y X.China's city network characteristics based on social network space[J]. Acta Geographica Sinica, 2012,67(8):1031-1043. ] doi: 10.11821/xb201208003
