Journal of Geo-information Science >
Study on the Administration and Construction of Urban Agglomeration with Spatiotemporal Big Data: A Progress Review
Received date: 2019-09-16
Request revised date: 2019-12-24
Online published: 2020-08-25
Supported by
National Key Research and Development Program of China(2017YFB0503800)
Copyright
With the development of the new type of urbanization, urban agglomeration plays a key role in modern social-economical development. To date, big data has been considered as a technological breakthrough and applied in many fields in recent years. Spatiotemporal big data mining and data fusion analysis can improve the efficiency of the administration and construction of cities/urban agglomeration in the new era of smart city. In this study, we aimed to review the types, acquisition methods, and analysis techniques of spatiotemporal big data. We investigated researches on urban agglomeration using spatiotemporal big data in order to identify the application of big data. We collected conference and journal articles as well as academic dissertations published in big data and data mining areas between 2004 and 2019. In total, wesummarized ten types of big data which were classified into traditionaltype and newtype categories, five big data acquisition methods including downloading, crawling, purchasing, and data processing, as well as seven most common big data analysis techniques. Five application fields on administration and construction of city/urban agglomeration using big data were concluded through literature review, including demarcation and spatial development monitoring, traffic network monitoring, association and function analysis, industrial coordination analysis, and environment assessment. Moreover, we summarized the bottlenecks of future big data applications, including: (1) difficulties in data management; (2) low-level data sharing; (3) high complexity of data analysis; (4) limitations of research ideas and application fields. In response to the above issues, some suggestions are listed: (1) government should strengthen policy support for more extensive information sharing and efficient information security assurance to create a favorable environment for the development of big data application; (2) constructing adaptable modern network infrastructure to create an all-in-one system which integrates network coordination, simulation, calculation, and administration; (3) building a big data management standard for urban agglomeration to solve the problems triggered by its characteristic of variability and multiformity; (4) promoting the establishment of big data platform to enforce an integrated information sharing mode from regional to national level; (5) adopting the international advanced technologies and methods with some new ideas from the studies on smart cities to build a technical system that is suitable in China. This study finally put forward that the construction of network infrastructure and spatiotemporal big data resources sharing platform could make new patterns of integrated analysis of big data possible, leading to highly effective supervision and strategical development of the city/urban agglomerations in the future.
CHEN Fangmiao , HUANG Huiping , JIA Kun . Study on the Administration and Construction of Urban Agglomeration with Spatiotemporal Big Data: A Progress Review[J]. Journal of Geo-information Science, 2020 , 22(6) : 1307 -1319 . DOI: 10.12082/dqxxkx.2020.190524
表1 现代城市群建设与管理中的常用大数据类型Tab. 1 Types of big data in the administration of urban agglomeration |
类型 | 内容 | ||
---|---|---|---|
传统数据 | 基础地理数据 | 地貌、水系、植被等基础地理信息数据;居住地、交通境界、特殊地物地名等要素信息 | |
台站观测数据 | 中国科学院、水利部、农业农村部、生态环境部、自然资源部、国家林业局等部门等建立野外观测台站数据,如对农田、森林、草地、荒漠、沼泽、水体等生态系统以及生态站碳氮水通量等观测数据 | ||
社会经济统计数据 | 年鉴、普查中的城市人口和劳动力统计资料、城市经济发展主要指标统计资料、城市社会发展主要统计资料、城市环境与基础设施资料等 | ||
新型数据 | 遥感数据产品 | 多源遥感数据、遥感产品如土地覆盖、土地利用数据,各类遥感指数如植被指数、水体指数、建筑指数、不透水面指数、裸土指数、亮温及湿度指数等 | |
个体时空定位数据 | 手机信令数据、其他具有全球定位功能的个人终端数据 | ||
APP兴趣与消费数据 | 网购支付(淘宝、京东、亚马逊、当当等);生活消费类主题网站(携程、大众点评、58同城、赶集网、链家网等)数据 | ||
电子地图数据 | 电子地图提供商提供的POI信息、用户使用电子地图时获取到的有关用户位置等信息,如百度、高德、谷歌、搜狗、凯立德、天翼等地图服务产品 | ||
社交应用网络数据 | 微信、微博、QQ空间、人人网、Twitter、facebook、Flikr等社交网络数据 | ||
智能交通数据 | 智能交通设备和系统,如智能公交、电子警察、交通信号控制、卡口、交通视频监控、出租车信息服务管理、城市客运枢纽信息化、GPS与警用系统、交通信息采集与发布和交通指挥类平台等 | ||
物联网传感数据 | 服务于城市治安、交通、生态环境质量管理等的城市传感器网络数据。城市管理方面包括货物流跟踪、环境监测、气象监测、城市路灯控制、城市安防监控、车辆监控调度等。生态方面包括温度、湿度、光照度、空气质量、噪音等物理数据,含氧量、二氧化碳等化学数据,细菌数和植被等生物数据 |
表2 常用城市群时空大数据的获取方法及特征Tab. 2 The methods and characteristics of spatiotemporal big data acquisition for urban agglomeration |
数据来源 | 获取方法 | 获取数据举例 | 特点 |
---|---|---|---|
公开数据库 | 网络下载与收集 | 政府公开的社会经济统计数据、常用的数据公开网站和部分共享遥感数据下载平台 | 数据多可免费,传统统计数据类型较多 |
部分网站平台 | 网络爬取、API接 | 网站的财经数据、公司年报、新媒体数据等有价值的信息,如谷歌地图、Facebook等 | 可获得大量有价值的数据,数据属性明确,部分需要付费 |
专业数据交易平台 | 购买 | 基于交易平台的政务、社会、社交、教育、消费、交通、能源、金融、健康等领域的数据资源 | 需要付费,可根据需求购买 |
派生数据 | 自行加工生产 | 如在已经下载的遥感数据基础上分析获取新的信息与知识 | 根据需要进行数据处理,灵活性强 |
其他 | 如通过合作等方式共享数据 |
表3 常见城市群时空大数据挖掘方法与示例Tab. 3 Methods of spatiotemporal big data mining for urban agglomeration |
挖掘方法 | 内容 | 城市/城市群建设中的应用示例 |
---|---|---|
遥感反演 | 对不同空间分辨率、时间分辨率、波段传感 器的数据进行分析获取更多地表参量信息 | 可用于城市热岛效应分析和生态环境监测;水质综合评价和生态承载力分析;城市群生态质量和生态安全评价[28,29,30] |
时空聚类 | 指基于空间和时间相似度把具有相似行为 的时空对象划分到同一组中,使组间差别尽 量大,而组内差别尽量小 | 可进行精准功能区分类,如城市功能区、生态区等;识别异常区域,如生态功能退化区、受自然灾害影响区等[31,32] |
分类 | 指基于训练样本数据确定未知样本数据类 别的过程 | 可用于土地覆盖/利用遥感分类以及特定土地覆盖类型的提取、网络爬取数据的分类等[33,34] |
关联分析 | 也称关联规则挖掘,指从大量数据中挖掘关 联性、相关性,从而进一步提取不同事物间 关系出现的规律和模式 | 可通过开展产业、用地、人口、功能之间的关联分析,提取相应的规则和知识,从而为土地调控、用地协同和功能疏解提供决策支持[35,36,37] |
机器学习 | 通过多层非线性变换对高复杂度数据建模 的算法的合集,能够处理图像、声音、文本等 多种数据 | 可用于在语言识别、图像分类及目标识别、人脸识别、视频分类和行为识别。在城市群规划中用于面向空间优化利用大数据的挖掘与知识发现技术[23,38-39] |
数据可视化算法 | 指运用计算机图形学和图像处理技术,将数 据转换为图形或图像在屏幕上显示出来,并 进行交互处理的方法 | 可将遥感和地理信息系统提供的抽象化数据可视化,用于城市群时空发展变化的监测[40] |
切片分析 | 指在给定的数据立方体的一个维度上进行的 选择操作 | 可从时间、空间、功能区类别等不同维度对城市群区域土地优化利用大数据等常见时空大数据进行切片分析[41] |
[1] |
|
[2] |
王缉慈. 创新集群三十年探索之旅[M]. 北京: 科学出版社, 2013.
[
|
[3] |
|
[4] |
|
[5] |
|
[6] |
|
[7] |
|
[8] |
|
[9] |
|
[10] |
|
[11] |
|
[12] |
|
[13] |
龙瀛, 崔承印, 茅明睿, 等. 大数据时代的精细化城市模拟: 方法、数据、案例和框架[J]. 人文地理, 2014,29(3):7-13.
[
|
[14] |
|
[15] |
|
[16] |
|
[17] |
|
[18] |
|
[19] |
|
[20] |
|
[21] |
黄慧萍, 李强子. 大数据时代土地利用优化的机遇、数据源及潜在应用[J]. 中国土地科学, 2017,31(7):74-82.
[
|
[22] |
陈曈, 朱志慧. 大数据技术的发展情况综述[J].福建电脑,2017(3):1-4.
[
|
[23] |
崔振. 云计算技术下海量数据挖掘的实现机制[J]. 微型电脑应用, 2019,35(4):129-131.
[
|
[24] |
|
[25] |
|
[26] |
|
[27] |
吉根林, 赵斌. 面向大数据的时空数据挖掘综述[J]. 南京大学报(自然科学版), 2014,37(1):1-7.
[
|
[28] |
|
[29] |
|
[30] |
|
[31] |
|
[32] |
|
[33] |
|
[34] |
|
[35] |
|
[36] |
|
[37] |
|
[38] |
|
[39] |
|
[40] |
|
[41] |
王振武. 大数据挖掘与应用[M]. 北京: 清华大学出版社, 2017.
[
|
[42] |
|
[43] |
顾立松. 基于遥感调查的珠江三角洲经济区城镇空间发展形态研究[D]. 广州:中国科学院广州地球化学研究, 2004.
[
|
[44] |
美克拉衣·艾克拜尔. 乌鲁木齐城市群的土地利用动态变化分析研究[D]. 乌鲁木齐:新疆大学, 2015.
[
|
[45] |
黄涛. 呼包鄂城市群城市化遥感监测及其模拟预测[D]. 呼和浩特:内蒙古师范大学, 2010.
[
|
[46] |
|
[47] |
孟祥玉. 基于多源数据京津冀城市群边界识别研究[D].北京:中国地质大学(北京), 2017.
[
|
[48] |
舒松. 基于稳定夜间灯光遥感数据的城市群空间模式识别方法研究[D]. 上海:华东师范大学, 2013.
[
|
[49] |
昌亭, 吴绍华. 长三角城市群地域扩张的时空特征—基于“近十年来DSMP/OLS夜间灯光数据”的实证分析[J].现代城市研究,2014(7):67-73.
[
|
[50] |
何春阳, 李景刚, 陈婧. 基于夜间灯光数据的环渤海地区城市化空间模式和过程研究[J]. 地理学报(英文版), 2005,60(3):32-38.
[
|
[51] |
|
[52] |
|
[53] |
李健, 谷正气, 张勇. 高分遥感影像的城市群路网监测原型系统开发[J]. 地理空间信息, 2015,13(2):51-54.
[
|
[54] |
张姝雅. 基于HRRS-GIS的城市群路网评价技术研究及系统实现[D]. 株洲:湖南工业大学, 2015.
[
|
[55] |
龙瀛, 张宇, 崔承印. 利用公交卡刷卡数据分析北京职住关系和通勤交通出行[J]. 地理学报, 2012,67(10):1339-1352.
[
|
[56] |
天津市城市规划设计研究院数字规划技术研究中心. 城市厚数据建设手册V1.2[R]. 天津:天津市规划设计研究院, 2016.
[ Digital Planning Research Center, Tianjin Uban Plannign & Design Institute. Urban big data construction V1.2[R]. Tianjin: Tianjin Uban Plannign & Design Institute, 2016. ]
|
[57] |
谭石柳. 基于铁路交通的长三角城市网络研究[D]. 杭州:浙江师范大学, 2015.
[
|
[58] |
傅毅明, 赵彦云. 基于公路交通流的城市群关联网络研究——以京津冀城市群为例[J]. 河北大学学报(哲学社会科学版), 2016,41(4):91-100.
[
|
[59] |
王海江, 苗长虹, 李欣欣. 流视角下中国铁路交通联系空间模拟与格局解析[J]. 经济地理, 2019,39(1):29-36.
[
|
[60] |
陈斌. 珠三角城市群交通协调发展战略及空间规划实践[C]. 2017年中国城市交通规划年会论文集, 2017.
[
|
[61] |
董志国, 刘红杏, 吴冠中, 等. 基于手机大数据的城市群空间特征研究——以珠三角为例[J].交通与运输,2017(5):32-34.
[
|
[62] |
周永杰, 刘洁贞, 朱锦丰, 等. 基于手机信令数据的珠三角城市群空间特征研究[J].规划师,2018(1):113-119.
[
|
[63] |
刘望保, 石恩明. 基于ICT的中国城市间人口日常流动空间格局——以百度迁徙为例[J]. 地理学报, 2016,71(10):1667-1679.
[
|
[64] |
叶强, 张俪璇, 彭鹏, 等. 基于百度迁徙数据的长江中游城市群网络特征研究[J]. 经济地理, 2017,37(8):53-59.
[
|
[65] |
韩华瑞. 基于新浪微博签到的京津冀城市群居民活动时空特征及范围划界初探[D]. 武汉:武汉大学, 2017.
[
|
[66] |
甄峰, 王波, 陈映雪. 基于网络社会空间的中国城市网络特征——以新浪微博为例[J]. 地理学报, 2012,67(8):1031-1043.
[
|
[67] |
蒋大亮, 孙烨, 任航, 等. 基于百度指数的长江中游城市群城市网络特征研究[J]. 长江流域资源与环境, 2015,24(10):1654-1664.
[
|
[68] |
张宏乔. 流空间视角下的城市网络特征分析——以中原城市群为例[J].资源开发与市场,2016(10):1219-1222.
[
|
[69] |
卢佳. 基于腾讯位置大数据的四大城市群内部空间联系格局特征研究[C]. 2017中国城市规划年会论文集, 2017.
[
|
[70] |
王贤文, 王虹茵, 李青纯. 基于地理位置大数据的京津冀城市群短期人口流动研究[J]. 大连理工大学学报(社会科学版), 2017,38(2):105-113.
[
|
[71] |
何志超, 郭青海, 杨一夫, 等. 基于POI 数据的厦漳泉同城化进展评估[J].规划师,2018(4):33-37.
[
|
[72] |
巫细波, 赖长强. 基于POI大数据的城市群功能空间结构特征研究——以粤港澳大湾区为例[J].城市观察,2019(3):44-55.
[
|
[73] |
王魁. 基于物流网站的大数据挖掘系统开发及其应用[D]. 上海:华东师范大学, 2018.
[
|
[74] |
黄金川, 徐君, 黄艳.基于大数据的城市群空间联系网络研究——以京津冀协同区域为例[J].科技经济导刊, 2018, 26(3): 1, 2.
[
|
[75] |
李涛, 周锐, 苏海龙, 等. 长三角区域经济一体化水平的测度:以关系型大数据为基础[C]. 2015年中国城市规划年会, 2015.
[
|
[76] |
吴亚菲. 产业集群与城市群发展的协同效应研究[D]. 上海:上海社会科学院, 2016.
[
|
[77] |
王丽. 基于新增产业用地视角的京津冀地区经济特征分析[J].国土资源情报,2018(2):41-45.
[
|
[78] |
沈静, 向澄, 柳意云. 广东省污染密集型产业转移机制—基于2000-2009年面板数据模型的实证[J]. 地理研究, 2012,31(2):357-368.
[
|
[79] |
张丽屏, 张翔. 创新产业聚集的影响因素分析—基于深圳、佛山企业大数据的空间分析[C].第十七届中国科技年会, 2015: 1-6.
[
|
[80] |
刘勍, 毛克彪, 马莹, 等. 基于农业大数据可视化方法的中国生猪空间流通模式[J]. 地理科学, 2017,37(1):118-124.
[
|
[81] |
陈阳, 朱郁郁. 基于企业大数据的长三角城市体系演化研究[C]. 2016中国城市规划年会,中国城市规划年会, 2016.
[
|
[82] |
苗红. 基于时空数据分析的京津冀现代服务业协同发展策略研究[D]. 武汉:华中师范大学, 2017.
[
|
[83] |
周春艳, 厉青, 王中挺, 等. 2005-2014年京津冀对流层NO2柱浓度时空变化及影响因素[J]. 遥感学报, 2014,20(3):468-480.
[
|
[84] |
|
[85] |
邓孺孺, 曾令初, 解学通, 等. 基于多源数据的城市群区水污染遥感反演——以珠江三角洲为例[J].中国科技成果,2013(14):28-30.
[
|
[86] |
|
[87] |
林金煌, 陈文惠, 祁新华, 等. 闽三角城市群生态系统格局演变及其驱动机制[J]. 生态学杂志, 2018,37(1):203-210.
[
|
[88] |
喻送霞, 杨波, 宾津佑, 等. 长株潭城市群土地资源承载力评价[J]. 中南林业科技大学学报(社会科学版), 2019,13(1):37-44.
[
|
[89] |
陈广东, 王继华, 田君慧. 遥感技术在中原城市群地质灾害危险性区划中的应用[J].低碳世界,2016(5):118-119.
[
|
[90] |
彭佳捷. 基于生态安全的长株潭城市群空间冲突测度研究[D]. 长沙:湖南师范大学, 2011.
[
|
[91] |
|
[92] |
|
[93] |
|
[94] |
|
[95] |
|
[96] |
|
[97] |
张丹丹, 李曼, 傅征博, 等. 城市群地质环境演化空间信息智能服务框架[J].测绘通报,2018(4):131-135.
[
|
[98] |
王国峰, 杜震洪, 何思明, 等. 基于时空大数据的交通灾害评估预警及服务关键技术[R]. 成都山地灾害与环境研究所, 2015.
[
|
[99] |
|
[100] |
|
[101] |
|
[102] |
|
[103] |
|
[104] |
|
[105] |
|
[106] |
|
[107] |
|
[108] |
|
/
〈 |
|
〉 |
