Accessibility of Beijing Dual Hub Airports from the Perspective of Residential Travel
Received date: 2021-08-27
Request revised date: 2021-12-27
Online published: 2022-07-25
Supported by
Major Program from National Social Science Foundation of China(20&ZD099)
Copyright
For a city with dual hub airports, the relationship between two airports is important for its integrated transport system. Since 2019 Beijing has been a city with dual hub airports, namely Beijing Capital International Airport (PEK, hereinafter referred as “Capital Airport”) and Beijing Daxing International Airport (PKX, hereinafter referred as “Daxing Airport”). Based on the Gaode Map API, which can obtain real-time data precisely, this paper obtains real-travel-time data in both auto mode and public transport mode. It investigates the accessibility spatial pattern of two airports under the two travel modes from the perspective of residential travel so that we can offer suggestions on the integration development of “civil aviation-urban transportation” system. The results show that: ① The use of Daxing Airport has effectively improved the spatial accessibility to airports in Beijing, especially from the south area, making civil aviation service in Beijing tend to be a “north-south equilibrium”. The coverage of the two airports is complementary in 0.5-hour service area by driving and 1 hour service area by public transport, which effectively improves the efficiency of aviation service in Beijing. ② In Beijing, accessibility by auto is higher than that by public transport and accessibility from Capital Airport is higher than Daxing Airport in both travel modes. Under the auto mode, the two airports begin to compete in the coverage within 1 hour journeys. For public transport mode, there is competition within 1.5 hour. ③ Under the public transport mode, the service area and population of the two airports in Beijing need to be improved, as the two airports only serve 1.4% of urban area and 7% of total population in Beijing. So it is important to construct 1 hour service area for residents to access the airports. ④ In the view of intra-urban transfer, accessibility from train stations to the Capital Airport is higher than that of Daxing Airport. Hence, accessibility between Daxing Airport and train stations should be enhanced to support the integration of aviation and high-speed rail travel. Last, we offer suggestions in order to promote the effective integration of airport and urban traffic system in double hub airport cities.
HUANG Jie , SHI Wenqian , CHEN Yu . Accessibility of Beijing Dual Hub Airports from the Perspective of Residential Travel[J]. Journal of Geo-information Science, 2022 , 24(5) : 914 -924 . DOI: 10.12082/dqxxkx.2022.210515
表1 数据来源Tab. 1 Data Source |
数据类型 | 数据来源 | 数据年份 |
---|---|---|
路网数据 | OpenStreetMap(OSM)空间数据集(https://www.openstreetmap.org/) | 2020 |
实时出行数据 | 高德地图API路径规划平台( https://lbs.amap.com/api/webservice/guide/api/direction) | 2020 |
点位坐标 | 高德地图API地理编码平台( https://lbs.amap.com/api/webservice/guide/api/georegeo) | 2020 |
人口密度数据 | WorldPop数据集(https://www.worldpop.org/) | 2020 |
表2 驾车出行模式下机场-机场、火车站-机场出行时间对比Tab. 2 Travel time between airports and train stations by auto mode |
起点 | 终点 | 车程时间/h | 时间差/min | 起点 | 终点 | 车程时间/h | 时间差/min | ||
---|---|---|---|---|---|---|---|---|---|
拥堵时段 | 非拥堵时段 | 拥堵时段 | 非拥堵时段 | ||||||
北京西站 | 首都 机场 | 1.28 | 0.97 | 18.48 | 北京西站 | 大兴 机场 | 0.91 | 0.86 | 2.73 |
黄村站 | 1.58 | 1.37 | 12.7 | 黄村站 | 0.58 | 0.53 | 2.92 | ||
北京东站 | 0.78 | 0.57 | 12.53 | 北京东站 | 0.96 | 0.91 | 3.28 | ||
北京站 | 0.85 | 0.67 | 10.58 | 北京站 | 1.10 | 1.08 | 1.17 | ||
北京南站 | 1.12 | 0.95 | 9.68 | 北京南站 | 0.82 | 0.78 | 2.43 | ||
北京北站 | 0.84 | 0.70 | 8.08 | 北京北站 | 1.10 | 1.09 | 0.88 | ||
大兴机场 | 1.37 | 1.29 | 4.88 | 首都机场 | 1.37 | 1.29 | 4.88 | ||
清河站 | 0.71 | 0.63 | 4.77 | 清河站 | 1.27 | 1.18 | 5.05 | ||
通州西站 | 0.78 | 0.70 | 4.38 | 通州西站 | 1.08 | 1.06 | 1.23 | ||
北京朝阳站 | 0.51 | 0.44 | 4.20 | 北京朝阳站 | 1.14 | 1.07 | 4.50 | ||
昌平北站 | 0.97 | 0.91 | 3.20 | 昌平北站 | 2.03 | 1.79 | 14.30 | ||
顺义西站 | 0.50 | 0.45 | 3.00 | 顺义西站 | 1.60 | 1.58 | 0.88 | ||
均值 | 8.04 | 均值 | 3.69 |
表3 公共交通出行模式下机场-机场、火车站-机场出行时间对比Tab. 3 Travel time between airports and train stations by public transport |
起点 | 终点 | 时间/h | 起点 | 终点 | 时间/h |
---|---|---|---|---|---|
大兴机场 | 首都 机场 | 2.21 | 首都机场 | 大兴 机场 | 2.21 |
北京朝阳站 | 1.19 | 北京朝阳站 | 2.20 | ||
北京东站 | 1.22 | 北京东站 | 2.76 | ||
北京站 | 0.90 | 北京站 | 1.44 | ||
北京北站 | 1.06 | 北京北站 | 2.59 | ||
顺义西站 | 1.52 | 顺义西站 | 2.63 | ||
清河站 | 1.27 | 清河站 | 2.82 | ||
通州西站 | 1.30 | 通州西站 | 2.06 | ||
北京南站 | 1.10 | 北京南站 | 2.53 | ||
北京西站 | 1.17 | 北京西站 | 2.42 | ||
昌平北站 | 1.29 | 昌平北站 | 2.33 | ||
黄村站 | 1.65 | 黄村站 | 2.02 |
[1] |
|
[2] |
|
[3] |
方远平, 闫小培. 西方城市公共服务设施区位研究进展[J]. 城市问题, 2008(9):87-91.
[
|
[4] |
宋正娜, 陈雯, 袁丰, 等. 公共设施区位理论及其相关研究述评[J]. 地理科学进展, 2010, 29(12):1499-1508.
[
|
[5] |
叶嘉安, 宋小冬, 钮心毅, 等. 地理信息与规划支持系统[M]. 北京: 科学出版社, 2008.
[
|
[6] |
|
[7] |
|
[8] |
张志学, 李同升. 基于GIS的县级尺度交通可达性研究——以陕西省为例[J]. 人文地理, 2010, 25(1):100-104.
[
|
[9] |
王兰, 周楷宸, 汪子涵. 健康公平理念下社区养老设施的空间分布研究——以上海市中心城区为例[J]. 人文地理, 2021, 36(1):48-55.
[
|
[10] |
宗会明, 黄言. 高速铁路对成渝城市群区域可达性和城市相互作用格局的影响[J]. 人文地理, 2019, 34(3):99-107,127.
[
|
[11] |
董小刚, 乔庆华, 翟亮, 等. 基于改进引力模型的广场公园可达性研究[J]. 地球信息科学学报, 2019, 21(10):1518-1526.
[
|
[12] |
陈洁, 陆锋, 程昌秀. 可达性度量方法及应用研究进展评述. 地理科学进展, 2007, 26(5):100-110.
[
|
[13] |
|
[14] |
|
[15] |
刘贤腾. 空间可达性研究综述[J]. 城市交通, 2007(6):36-43.
[
|
[16] |
|
[17] |
|
[18] |
|
[19] |
|
[20] |
王姣娥, 莫辉辉. 民航机场布局方法探讨[J]. 中国民航飞行学院学报, 2009, 20(6):7-10.
[
|
[21] |
吴威, 曹有挥, 梁双波, 等. 民用机场区域服务能力的结构与空间格局——以长江经济带民用机场体系为例[J]. 地理研究, 2019, 38(6):1512-1526.
[
|
[22] |
许幸, 杨绪彪. 浅谈机场与区域经济的互动关系[J]. 物流科技, 2020, 43(10):118-120.
[
|
[23] |
黄洁, 王姣娥. 枢纽机场的航班波体系结构及其喂给航线的空间格局研究[J]. 地理科学, 2018, 38(11):1750-1758.
[
|
[24] |
金凤君, 王成金. 轴-辐侍服理念下的中国航空网络模式构筑[J]. 地理研究, 2005, 24(5):774-784.
[
|
[25] |
王法辉, 金凤君, 曾光. 中国航空客运网络的空间演化模式研究[J]. 地理科学, 2003, 23(5):519-525.
[
|
[26] |
|
[27] |
唐雅茹. 日本成田机场快线对市郊快线建设的启示[J]. 城市轨道交通研究, 2009, 12(7):5-8.
[
|
[28] |
王倩, 翟文鹏. 珠三角机场群航班时刻优化研究[J]. 河南科技大学学报(自然科学版), 2018,39(1):29-34, 40,6.
[
|
[29] |
朱诺. 北京首都机场国际航空运输市场监测分析[J]. 空运商务, 2020(1):32-37.
[
|
[30] |
北京市规划和自然资源委员会. 北京城市总体规划(2016-2035)[EB/OL]. 2018-01.
[ Beijing Municipal Commission of Planning and Natural Resources. Master Planning of Beijing (2016-2035)[EB/OL]. 2018-01. ]http://ghzrzyw.beijing.gov.cn/zhengwuxinxi/zxzt/bjcsztgh20162035/202001/t20200102_1554613.html
|
[31] |
张文尝, 等. 城市交通与城市发展[M]. 北京: 商务印书馆, 2010.
[
|
[32] |
潘竟虎, 从忆波. 中国民用机场可达性与服务范围测度[J]. 经济地理, 2015, 35(2):46-53.
[
|
[33] |
曹小曙, 廖望. 全球多机场区域空间格局与类型划分[J]. 地理科学进展, 2018, 37(11):1473-1484.
[
|
[34] |
|
[35] |
|
[36] |
|
[37] |
陈杰, 李昂, 符峥, 等. 公交模式对公共服务设施可达性的影响[J]. 地球信息科学学报, 2019, 21(7):983-993.
[
|
/
〈 | 〉 |
